Technical Specifications - multivac Home C 010 Instruction Manual

11

Technical specifications

Machine technical specifications
Mains voltage
Rated power
Machine dimensions (width x
height x length)
Usable chamber size (width x
height x length)
Maximum size of the film pouch
(width x length)
Sealing length
Weight approx.
Suction power of the vacuum
pump
Minimum technically achievable
vacuum pressure
Noise emission
Installation conditions and ambient conditions
Ambient temperature
Storage temperature
Max. relative air humidity during
operation or storage of the ma-
chine.
Requirements for the location of
the machine
Minimum distance from all side
panels and rear panel of the ma-
chine
Free space above the machine
19.09.2018
Technical specifications
220V to240V 50 Hz / 60 Hz
0.1kW
310 mm (12 1/4 in) x 225 mm (9
in) x 480 mm (19 in)
200 mm (7 3/4 in) x 230 mm (9
in) x 100 mm (3 15/16 in)
200 mm (7 3/4 in) x 300 mm (11
3/4 in)
210 mm (8 1/4 in)
12.2 kg (27 lb)
2.5 m³/h (11 gal/min)
< 15 mbar (0.2 psi)
< 70dB
10 °C (50 °F) to 30 °C (86 °F)
-25 °C (-13 °F) to 80 °C (176 °F)
85% non-condensing
• Level surface
• Horizontal surface
• Sufficient load bearing capa-
city
100 mm (4 in)
300 mm (12 in)
31 / 36
