BayTech DS62 Quick Start Manual

Data switch
Hide thumbs Also See for DS62:
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

See also: Owner's Manual , Manual
2019
DATA SWITCH DS62/DS62‐MD4
QUICK START
 COPYRIGHT 2019
Bay Technical Associates, Inc
1/1/2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS62 and is the answer not in the manual?

Questions and answers

Related Manuals for BayTech DS62

Summary of Contents for BayTech DS62

  • Page 1 2019  DATA SWITCH DS62/DS62‐MD4  QUICK START  COPYRIGHT 2019  Bay Technical Associates, Inc  1/1/2019 ...

  • Page 2: Serial Connection

    QUICK START: DS62/DS62­MD4 SERIES  This is the bare minimum for Ethernet Control. If this is a new unit shipped directly from Baytech, follow the steps. If this is a previously own unit, perform a factory reset to clear out any users and passwords still in the unit.
  • Page 3 Network setup : You should see the menu to the right. Ethernet Address....00:C0:48:06:77:6D Default ‘DHCP’ is enabled. To enter a IP Address...... 0.0.0.0 STATIC IP address DHCP must be Subnet Mask..... 0.0.0.0 Default Gateway....0.0.0.0 disabled. Connection Inactivity Timeout (mins): Disabled Type ‘7’...
  • Page 4 Baytech device to your network using an Ethernet cable. 23. You should be prompted for a user name and password, similar to (Figure 5) At this point you have enough basic configurations needed to operate this Baytech unit.
  • Page 5 (3 ,1)..5 Status......S Configure.......C Unit Reset......RU Logout......T Enter Request : Figure 2: Network Configuration Copyright(C) Bay Technical Associates 2008 DS62 Ethernet Host Module Revision F 2.25.06 Module 1 Hardware 1.00 Serial number 22222 colilo version 1.05.01 Status......1 Status of all network options Serial Port Configuration..2...

  • Page 6: Access Control

    Modem Login Prompt Enable/Disable...3 DS62-MD4 only Figure 5: Network Login Prompt DS62 login: The default user and password is “root/baytech”, all lower case. Password: Manage Users Add/delete users and change their passwords. Usernames and passwords are case sensitive and alphanumeric. The root user can not be removed.
  • Page 7 Baud Rate: (C/2/2) Word Size: (C/2/3) Stop Bits: (C/2/4) Parity: (C/2/5) RTS/DTR Line Driver Inactive State: (C/2/6) Modem DCD Connection Mode (DS62-MD4 ONLY): (C/2/7) Serial Port Device Name: (C/3) Attention Character: (C/4) Disconnect Timeguard: (C/5) Connect Port ID Echo: (C/6)
  • Page 8 Enable Firmware Upgrade: (C/11/1) Enable SSL Cert Upload: (C/11/2) Enable Configuration File Upload: (C/11/3) Restore Configuration Defaults: (C/11/4) Get Current Configuration File: (C/11/5) Display Configuration Error Log: (C/11/6) Enable Rel Ctl. Firmware Upgrade: (C/11/7) MMP11 (2 ,1)..1 Modem Configuration Menu (DS62-MD4 ONLY): (C/12)
  • Page 9 Modem Port Configuration (DS62-MD4 ONLY): (C/12/1) Rings to Auto Answer (DS62-MD4 ONLY): (C/12/2) Modem Connectivity Timeout (DS62-MD4 ONLY): (C/12/3) Modem Inactivity Timeout (DS62-MD4 ONLY): (C/12/4) Modem Device Name (DS62-MD4 ONLY): (C/12/5) PPP Configuration (DS62-MD4 ONLY): (C/12/6) Country Code (DS62-MD4 ONLY): (C/12/7)

This manual is also suitable for:

Ds62-md4
