  • Page 1 2019  DATA SWITCH DS71‐MD4  COPYRIGHT 2019  Bay Technical Associates, Inc  10/1/2019 ...

  • Page 2: Table Of Contents

    Table of Contents    COMPLIANCE STANDARD ................................  5   CONNECTION DESCRIPTION  ................................  6   EIA‐232 SERIAL CONNECTION ................................  6   INTERNAL MODEM COMMUNICATIONS ............................  6   MODEM LED DESCRIPTIONS ................................  6   EXTERNAL MODEM COMMUNICATIONS ............................  6   INSTALLATION  ....................................  7   UNPACKING ....................................  7    ................................  7 REPARING THE  NSTALLATION    POWER ........................................  7   CABLING  ......................................  8  ...
  • Page 3   EXIT...................................... 27   LOGOUT ...................................... 27   FACTORY DEFAULT PROCEDURE .............................. 27   BASIC TROUBLESHOOTING ................................ 28   BAYTECH PRODUCT WARRANTY .............................. 29    ......................................  2 9 XCEPTIONS    ................................  2 9 ECH  XTENDED  ARRANTY    ....................................  3 0 ECHNICAL  UPPORT   ......................................  3 0 EPAIR  OLICY   :  ................................  3 1 ETURN ...
  • Page 4               DS71‐MD4 Serial & 56K Modem Host Module                  Replaces DS71‐MD3, 33.6K modem         ...

  • Page 5: Compliance Standard

    Web Site, www.baytech.net. BayTech manufactures many remote site management power products and data switches. If you would like information on any of these products, please contact BayTech Customer Service at the above numbers or visit our web site.

  • Page 6: Connection Description

    BayTech's DS71-MD4 host communication modem module provides an interface that controls user access to the DS Series data switch and other DS Series connected modules. The DS71-MD4 is a system data controller that directs operations between the base unit, system modules and externally connected devices.

  • Page 7: Installation

    Inspect equipment carefully for damage that may have occurred in shipment. If there is damage to the equipment or if materials are missing, contact BayTech Customer Support at 228-563-7334 or call toll free inside the United States at 800-523-2702. At a minimum, you should receive the following: 1.

  • Page 8: Cabling

    (Circuit Breaker rated not to exceed the amperage rating of the unit) shall be incorporated in the fixed wiring between the power source and the Baytech unit. For PLUGGABLE EQUIPMENT, the socket-outlet shall be installed near the equipment and easily accessible. The outlets providing power to the unit shall be protected against over current, short circuit and earth fault by suitable rated protective devices.
  • Page 9 Adapter signals Listed are the pin specifications for the BayTech cable and adapters and the terminal COM ports: Serial 1: Port Pin out Table Signal RS-232 RS-232 Port COM Port COM Port Signal Port (DS) (RPC) DE-9 Pin DB-25 Pin RJ08X007 Standard Rollover Cable –...

  • Page 10: Adapters

    After logging in successfully, invoke the main menu by sending the attention character five times (;;;;;). NOTE: Password feature is case sensitive. (Default is user/password is root/baytech) NOTE: All screen shots are valid for Firmware F2.21. Not all options are available for all...

  • Page 11: Quick Start: Ds71-Md4 Series

    QUICK START: DS71­MD4 SERIES  If this is a new unit shipped directly from Baytech, follow the steps. If this is a previously own unit, perform a factory reset to clear out any users and passwords still in the unit. Configuration:  1. Connect to the Serial port (EIA232) using the supplied rollover flat cable and adapter.
  • Page 12 DS-RPC (3)....3 Exit........X,CR Enter Request : Figure 3: DS71-MD4 Configuration Copyright(C) Bay Technical Associates 2006 DS71-MD4 Data Switch Series - V90 Modem Host Module Revision F.1.06.00 Module 1 Status ........1 Serial Port Configuration .....2 Port Device Name ......3 Port Select Code ......4 Attention Character ....5...
  • Page 13 Figure 4: Login Setup Login Setup: Header .......1 Access Control ....2 Menu ......3 Manage Users ....4 Auto Connect ....5 Dial Back Number .....6 Assign User Ports ....7 Exit ......X,CR Enter Request : Figure 5: Manage User User Management Menu: ”admin” ......1 Add New User ......A Delete User ......D Change User ......C...

  • Page 14: Figure 7: Assign User Ports

    Figure 7: Assign User Ports Assigned User Ports: +----+----------* +-M2-+-M3-+ |User| Name \|1234|1234| +----+------------*----+----+ 1 | admin |1234|1234| 2 | john +----+------------*----+----+ Enter User number:2 Assigned User Ports: +----+----------* +-M2-+-M3-+ |User| Name \|1234|1234| +----+------------*----+----+ 2 | john |..|..| +----+------------*----+----+ Add Port(s)......1 Remove Ports(s)......2 Add All Ports......3 Remove All Ports.......4...

  • Page 15: Main Menu

    Detail Operations and Configurations  NOTE: Depending on the DS-Series model, the menus may vary according to the number of DS74 modules installed in the unit. If this is not an initial set-up and Password has already been enabled, you are prompted to login. After logging in successfully, invoke the main menu by sending the attention character five times (;;;;;).

  • Page 16: Configuration Menu

    (4) power outlets. Enter Request : DS71­MD4 CONFIGURATION MENU:  Menu 3: DS71-MD4 Configuration Copyright(C) Bay Technical Associates 2006 DS71-MD4 Data Switch Series - V90 Modem Host Module Revision F.1.01.01 Module 2 Status ......1 Current status of DS71-MD4 module Serial Port Configuration..2 Change port config, 9600, 8, 1, none Port Device Name....3...
  • Page 17 Status Assigned User Ports: +----+----------* +-M3-+-M4-+-M5-+ continued. |User| Name \|1234|1234|1234| +----+------------*----+----+----+ 1 | admin |1234|1234|1234| +----+------------*----+----+----+ User Dialback Phone number +----+-----------+-----------------+----------+ |User| Name Phone number | Dialback | +----+-----------+-----------------+----------+ 1 | admin | Disabled | +----+-----------+-----------------+----------+ Dialback Delay......10 seconds Access Control: Serial Port access: 1)...Prompt for User Name: Disabled 2)...Prompt for Password : Disabled...

  • Page 18: Serial Port Configuration

    Serial Port Configuration  Select 2), from the Network Configuration Menu configures Handshaking, Baud Rate, Word Size, Stop Bits, and Parity through either the serial or modem ports using the menus. RTS and DTR Line Drivers can only be configured through the phone line via a modem Xon/Xoff, RTS and DTR Line Drivers can only be configured through the phone line via a modem.

  • Page 19: Word Size

    Word Size  The word size is the measurement of the actual data bits in a transmission. Which setting you choose depends on what information you are transferring. For example, standard ASCII has values from 0 to 127 (7 bits). Extended ASCII uses 0 to 255 (8 bits). If the data being transferred is simple text (standard ASCII), sending 7 bits of data per packet is sufficient for communication.

  • Page 20: Xon/Xoff

    Baytech and other devices. Baytech units will send an XOFF character when it can't take any more data and when it can once again take more data, will send an XON character to the transmitter.

  • Page 21: Attention Character

    The unit displays: (blank) Select 2), to echo the module and port number. The unit displays: BAYTECH For further information check: http://www.baytech.net/ 02,1 Select 3), to echo the port name. The unit displays: BAYTECH For further information check: http://www.baytech.net/ DS71-MD4...

  • Page 22: Login Setup Menu

    IMPORTANCE: Before you enable the password for either Serial Port or Network access, verify the admin password is known, or you could create a lockout condition. If the password lockout condition occurs, you will need to reset the DS71-MD4 host module to the factory defaults Default username/password is (root/baytech), all lower case.

  • Page 23: Menu

    Menu  Select 3, from the Login Setup Menu, this allows the admin to Menu Mode :Enabled enable or disable the Menu on start up. If disabled, the header Enable ? (Y/N, CR for no change): appears upon login without the main menu. To invoke the main menu when disabled, enter the attention character five times (;;;;;).

  • Page 24: Dial-Back Numbers

    Dial­Back Numbers  Menu 7: Dial Back Select 6, from the Login Setup Menu, this User Dialback Phone number Dialback Delay:10 seconds feature allows user to dial in, hang up and +----+-----------+-----------------+----------+ the unit dials the assigned number back |User| Name Phone number | Dialback | when using a secure phone line.

  • Page 25: Local Modem Option

    Select 2, to remove individual ports. Enter Module and Port number in format M:P or M,P (0=All): 2:3 Assigned User Ports: Unit responds with module-2 and +----+----------* +-M2-+-M3-+ |User| Name \|1234|1234| Port-3 de-selected +----+------------*----+----+ 2 | cat |1. .|1. .| +----+------------*----+----+ Assigned User Ports: Select 3, to add all ports.

  • Page 26: I/O Modules Reset

    Unit ID  Select U, for “Unit ID” This option is used to change the Host Module’s name. Type “Y” to change the name, up to 63 characters, Unit ID :DS71-MD4 Change It ? (Y/N) : Y (alpha and numeric characters only.

  • Page 27: Unit Reset

    If you are connected via the modem, you will lose the connection. Wait 20 seconds then reconnect. NOTE: You must be connected to the DS71-MD4 Main Menu to reset the unit. This will not default the unit to factory defaults.

  • Page 28: Basic Troubleshooting

    This verifies the Chassis, Host module, and the I/O port is working. i. Move pc cable to next DS74 port and repeat steps (c-h). If you have done all of the above steps that are possible and still have problems, contact Baytech Technical Support at 228-563-7334.

  • Page 29: Baytech Product Warranty

    BayTech. BayTech will pay return costs for delivery within the Continental United States. All repair and return shipments must be approved by BayTech and must be accompanied by an RA (return authorization) number. Please refer to our Repair and Return Policy below.

  • Page 30: Technical Support

    Technical Support  BayTech offers Tech Support for the lifetime of the product. A staff of Applications Engineers is on duty to assist with installation, set up or operation issues. Support is available from 8:00 a.m. to 5 p.m. (CST or CDT), Monday through Friday at the phone numbers or website provided below.

  • Page 31: Return Authorization Process

    Return Authorization Process:  a. Contact BayTech via Phone, Fax, or Email to get a Return Authorization (RA) Number. IMPORTANT: BayTech will not accept any returns without an RA number. b. Package the unit carefully in its original packaging or similar packaging. The warranty does not cover damage sustained during shipment.
