BayTech MSP Series Quick Start Manual

Redundant
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
2019
MSP and MSPr Redundant Series
QUICK START
 COPYRIGHT 2019
Bay Technical Associates, Inc
1/1/2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MSP Series and is the answer not in the manual?

Questions and answers

Related Manuals for BayTech MSP Series

Summary of Contents for BayTech MSP Series

  • Page 1 2019  MSP and MSPr Redundant Series  QUICK START  COPYRIGHT 2019  Bay Technical Associates, Inc  1/1/2019 ...
  • Page 2 This is the bare minimum for Outlet Control, follow these steps exactly. If this is a new unit shipped directly from Baytech, follow the steps. If this is a previously own unit, perform a factory reset to clear out any users and passwords still in the unit.

  • Page 3: Ethernet Configuration

    This is the bare minimum for Ethernet Control. If this is a new unit shipped directly from Baytech, follow the steps. If this is a previously own unit, perform a factory reset to clear out any users and passwords still in the unit.

  • Page 4: Password Setting

    Status Screen: Once the serial connection is made using the terminal software, the screen will display the inherent state of the outlets, Current and Maximum Detected Current both in Amps, circuit breaker, Internal temperature of the unit, and external temperature sensors if connected. The number of outlets displayed depends on the MSP model.

  • Page 5: Manage User

    Figure 3: Outlet Password MSP>password Enter new Password: ***** Re-Enter new Password: ***** Type Help for a list of commands MSP> Power Controller Configuration Menu: To select the configuration menu, type “config” at the prompt. NOTE: If the unit displays with the following message, “Configuration mode in use” A user in the other port is in the “Configuration”...
  • Page 6 Figure 6: Outlet Assignment ------------------------------------------- User Assigned Outlets | C1,1| C1,2| C1,3| C1,4| ------------------------------------------- engineer ------------------------------------------- 1)...Add Outlet(s) Add individual Outlets (X, X, X, X) 2)...Remove Outlet(s) Remove individual Outlets 3)...Add All Outlets Add all outlets to above user 4)...Remove All Outlets Remove all Outlets from the above user Change Circuit Group Move to next Circuit Group of Outlets Enter Request:...

  • Page 7: Access Control

    Figure 10: Network Access Control Telnet Login Prompt Enable/Disable..1 Serial Login Prompt Enable/Disable..2 Figure 11: Network Login Prompts Universal RPC login: Password: The default user and password is “root/baytech”, all lower case.

  • Page 8: Manage Users

    Manage Users Add/delete users and change their passwords. Usernames and passwords are case sensitive and alphanumeric. The root user can not be removed. Figure 12: Network Manage User User Management Menu To change user password or port access, enter number of user. To add/delete user, select appropriate menu choice.
  • Page 9 Quick Start for MSPr100 ATS part  Connect to your unit and type the attention character 5-times at the prompt. You should see the following menu. At the Prompt Type ‘1’ and press Enter. Module: 1 Attention Character: MSPr100 ( 2,1)..1 Status........S Configure........C Unit Reset.........RU Logout........T Enter Request : You should see a similar screen.
  • Page 10 If you get the following response, type “n” and press Enter, if you want the unit to automatically switch-back to the primary source. It will tell you the current delay time and you can change the delay time. Disable switch back to primary (Y/N)? N Current delay switch back to primary source time is(0= minimum): 0 Seconds Change delay switch back time (Y/N)?y...
  • Page 11 Network Menu Options Select each menu option, press ‘Enter, then select next option and press ‘Enter’, i.e. {Network Status: (C/1), type ‘C’ (Configure) at prompt and press ‘Enter’, type ‘1’ (Status) at prompt, and press ‘Enter’. PD Unit (2,1): (1) Type config Manage Users: (1) Change Outlet Name: (2)
  • Page 12 Under Voltage Alarm Threshold: (C/10/2) Over Voltage Alarm Threshold: (C/10/3) Low Current Alarm Threshold: (C/10/4) Environmental Sensors: (C/10/5) Outlet Groups: (C/10/6) Temperature units (degrees C/F): (C/10/7) RPC Cascade Mode: (C/10/8) Power Factor Threshold: (C/10/9) Firmware / Config Download: (C/11) Enable Firmware Upgrade: (C/11/1) Enable SSL Cert Upload: (C/11/2) Enable Configuration File Upload: (C/11/3) Restore Configuration Defaults: (C/11/4)
