ERGOMART TRS2718-BB103 Installation Instructions

1
Insert arm into completely attached
and assembled mount
4
D.
D.
L.
D.
D.
Attach slider VESA plate to LCD with
screws (D).
6
K.
J.
I.
Use clip in forearm and the
cable cap (I) to manage cords.
Increase resistance to rotation at
articulation points by tightening small
sets screws using wrench (H.)
DO NOT OVER TIGHTEN.
Ergonomic solutions for office and light industrial work environments
TRS2718-BB103

Installation Instructions

www.ergomart.com | 888 420 3200
2
P.
A.
B.*
*B is optional
Attach tilter head to backbar (P).
Please call Ergomart at
888 420 3200
with your questions
VESA
Plate Slot
www.ergomart.com
7
WARNING: DO NOT adjust arm unless in horizontal position with the
arm loaded fully with monitor, keyboard etc. Attempting to do so in
other positions WILL damage arm.
(2)
(1) Push arm down to horizontal position
(2) Rotate wrench CLOCKWISE to weaken arm.
Once adjusted correctly arm should float LCD.
©2015 Ergomart. All rights reserved.
3
O.
Tilter Head
C.
Pattern
C.
C.
C.
Using the carriage bolt and the plastic
knob, fasten the VESA plate to backbar.
Position a 1.25" plastic washer on each
side of the backbar.
5
Slide tilter pin into end of arm, secure
using dog washer (E&F).
(1)
J.
K.
N.
L.
L.
Plate Slot
E.
F.
VESA
