ERGOMART DS9109 Series Installation Instructions

1
A
A
A
Install self-stick bumper feet as shown.
4
Slide yoke (J) onto pole. Tighten yoke
thumbscrew when adjusted to desired
height.
7
G
H
Insert tilter mechanism pin into yoke.
Align dog washer(G) with bottom of tilter
mechanism pin and attach with flat head
screw (H).
Ergonomic solutions for office and light industrial work environments
DS9109

Installation Instructions

www.ergomart.com | 888 420 3200
2
A
I
Insert pole (K or L) into base (I), aligning
the slot in the pole with the set screw in
the base.
5
J
Attach the VESA adapter (D) to the tilter
mechanism (C) using four 10-32 x 3/8"
flat head screws (E).
8
Locate set screw on bottom of tilter
mechanism by tilting monitor upward.
Use 7/32 Allen wrench (B) to adjust
rotation resistance to desired level.
©2017 Ergomart. All rights reserved.
K or L
C
D
E
E
E
E
B
7/32"
DS9109S DS9109D
3
7/32"
B
Tighten set screw using Allen wrench
(B).
6
F
F
F
F
Attach VESA adapter to monitor using four
M4 x 12mm screws (F). Some monitors
may require a spacer kit. See page 2 for
details.
9
Use cable clip (M) to secure cables to pole.
PAGE 1 OF 2
