1
A.
*
*
*
The installer must determine the
appropriate fastener for your appli-
cation. If uncertain about mounting
procedures contact Ergomart for
technical assistance.
*Hardware NOT included.
4
A.
Insert inner pipe into base. (A)
Use Knob (C) to allow height adjust-
ment of Unit.
Ergonomic solutions for office and light industrial work environments
POS18-3005
Installation Instructions
www.ergomart.com | 888 420 3200
2
E.
E.
E.
Attach (D or E) using the phillips flat
head screws (F).
5
C.
Increase or decrease resistance to tilt
by adjusting set screw at the point of
articulation using wrench.
©2015 Ergomart. All rights reserved.
E.
D.
H.
3
F.
F.
F.
Carefully place monitor face down on
flat surface. Attach to VESA plate
using Phillips pan head screws (G).
Please call Ergomart at
888 420 3200
with your questions
www.ergomart.com
F.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ERGOMART POS18-3005
Summary of Contents for ERGOMART POS18-3005
-
Page 1: Installation Instructions
POS18-3005 Installation Instructions www.ergomart.com | 888 420 3200 The installer must determine the appropriate fastener for your appli- cation. If uncertain about mounting procedures contact Ergomart for Carefully place monitor face down on technical assistance. Attach (D or E) using the phillips flat flat surface. -
Page 2: Parts List
POS18-3005 Parts List www.ergomart.com | 888 420 3200 ITEM DESCRIPTION / PART NO. QUANTITY LS18-3005 Base LS18-3005 Inner Pipe Knob 75mm VESA Adapter Plate 7VESA75 10-32 x 3/8" (9.525mm) Phillips Flat Head Screw 702281 M4-12 Phillips Pan Head Screw 702096 7/32"...
