1
Insert arm pin into completely attached
and assembled mount.
4
E.
F.
Slide tilter pin into end of arm.
7
Increase resistance to rotation at
articulation points by tightening small
set screws.
DO NOT OVERTIGHTEN.
Ergonomic solutions for office and light industrial work environments
SAA7000 MONITOR ARM
Installation Instructions
www.ergomart.com | 888 420 3200
2
A.
Attach VESA plate to tilter head.
5
Adjust vertical tilt resistance on tilter
head.
8
I.
©2016 Ergomart. All rights reserved.
3
B.
C.
C.
C.
C.
Attach tilter head/VESA plate to
Monitor.
* Some monitors may require a spacer
hardware kit. See page 3 for details.
6
G.
Put arm in horizontal position and
rotate wrench CLOCKWISE to WEAKEN
arm until monitor stays wherever it is
placed. See page 2 for more detailed
instructions.
Please call Ergomart at
D.
D.
D.
D.
G.
888 420 3200
with your questions
www.ergomart.com
PAGE 1 OF 3
