The PIO modes are selected in the BIOS setup (refer to Chapter 3). The
Autoconfigure will attempt to classify the drive connected if the drive supports the
auto ID command. If you experience problems, change the PIO to standard.
P2 Connector
P3 Connector
P3 connects a single 3.5-inch floppy drive. Only one drive is supported. Power for this
drive is not supplied by the XVME-973.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Chapter 4 – 978 PCI Ethernet Controller Module
Pin A B
1 RES (NC) +5V
2 RES (NC) GND
3 RES (NC) RES (NC)
4 RES (NC) RES (NC)
5 RES (NC) RES (NC)
6 RES (NC) RES (NC)
7 RES (NC) RES (NC)
8 RES (NC) RES (NC)
9 RES (NC) RES (NC)
10 RES (NC) RES (NC)
11 RES (NC) RES (NC)
12 RES (NC) GND
13 RES (NC) +5V
14 RES (NC) RES (NC)
15 RES (NC) RES (NC)
16 RES (NC) RES (NC)
17 RES (NC) RES (NC)
18 RES (NC) RES (NC)
19 GND RES (NC)
20 FRWC* RES (NC)
21 IDX* RES (NC)
22 MO1* GND
23 HDRQ RES (NC)
24 FDS1* RES (NC)
25 HDACK* RES (NC)
26 FDIRC* RES (NC)
27 FSTEP* RES (NC)
28 FWD* RES (NC)
29 FWE* RES (NC)
30 FTK0* RES (NC)
31 FWP* GND
32 FRDD* +5V
Pin Signal Pin
1 GND 18
C
HDRESET*
HD0
HD1
HD2
HD3
HD4
HD5
HD6
HD7
HD8
HD9
HD10
HD11
HD12
HD13
HD14
HD15
GND
DIOW*
DIOR*
IORDY
ALE
IRQ14
IOCS16*
DA0
DA1
DA2
CS1P*
CS3P*
IDEATP*
FHS*
DCHG*
Signal
FDIRC*
5-3
