- Page 1 PowerLuber grease gun Model 1440CLR, series “D” Date of issue May 2015 404179C Form number Section Page...
-
Page 2: Table Of Contents
Contents Intended use The PowerLuber was exclusively designed to Intended use . . . . . . . . . . . . . . . . . . . . . . pump and dispense lubricant using 14 .4 V bat- tery power. -
Page 3: Safety Instruction
Safety instruction 2.4 Do not abuse the cord. Never use the cord for carrying, pulling or unplug- General power tool safety warnings ging the power tool. Keep cord away from heat, oil, sharp edges or mov- ing parts. Damaged or entangled cords increase the risk of electric shock. - Page 4 3.6 Dress properly. Do not wear loose 4.7 Use the power tool, accessories and clothing or jewellery. Keep your hair, tool bits etc. in accordance with clothing and gloves away from mov- these instructions, taking into ing parts. Loose clothes, jewellery or account the working conditions and long hair can be caught in moving parts.
-
Page 5: Safety Of Others
Safety of others* W A R N I N G This appliance is not intended for use by per- sons (including children) with reduced physi- Do not use any hose that has not been cal, sensory or mental capabilities, or lack of approved by Lincoln . -
Page 6: Labels On Tools
Vibration* W A R N I N G The declared vibration emission values stated in the technical data and the declara- To reduce the risk of injury, the tion of conformity have been measured in user must read the instruction accordance with a standard test method manual. -
Page 7: Protecting The Environment
Protecting the Safety instructions for environment battery and charger Save these instructions This manual contains important safety and Separate collection. This product operating instruction for the Lincoln model must not be disposed of with 1410 battery charger . normal household waste. Should you find one day that your Lincoln product needs replacement, or if it is of no fur- D A N G E R... - Page 8 Charger Do not attempt to charge Before using this battery charger, read all damaged batteries . instructions and cautionary markings on battery charger, battery pack, and product using battery . Do not expose C A U T I O N battery to fire .
-
Page 9: Electrical Safety
Electrical safety 10 Do not store the charger or battery packs in locations (such as a metal tool shed, or a car in the summer) where the temperature may reach or exceed 122 °F (50 °C) , which can lead to deterioration of the storage battery . -
Page 10: Tool Use And Care
Tool use and care Specifications PowerLuber Model 1440CLR Do not continue to hold down trigger if grease Operating power 14 .4 V gun is stalled . This could damage the motor or Maximum operating pressure Low output 7,000 psi (482 bar) cause fire . -
Page 11: General Description
Fig. 1 PowerLuber general components Item Description Pump assembly 1230 30 in . (76 cm) hose Vent valve Bulk valve Coupler Grease tube 1401 battery Inspection General description The Lincoln PowerLuber is a battery operated Visually inspect for damaged, loose or missing grease gun developed for manual lubrication parts . -
Page 12: Operation
Operation Fig. 2 Changing “L” or “H” Mode († fig. 2) To change the mode of operation Notice To prevent damage to the gears in the transmission, the motor must be com- pletely stopped before changing the lever to the “L” or “H” (low or high) mode of operation . - Page 13 Installing grease cartridge To fill the gun from bulk container 1 Unscrew the grease tube assembly from the Remove pump assembly from grease tube PowerLuber . assembly . 2 Pull back on follower handle and latch Pack lubricant into cavity of the pump follower rod groove into slot on tube cap .
- Page 14 To fill the gun with a filler pump Expelling air pockets 1 Engage the follower rod with the follower by 1 Withdraw the follower rod from the grease rotating the follower handle . tube assembly cap and engage it with the 2 Insert the gun vent/bulk fill valve (11) into follower by rotating the follower handle .
-
Page 15: Charger Operation
Charger operation Fig.5 Make sure power circuit voltage is the same as 1401 that shown on the charger specification plate . Notice Charge battery pack for the first time for a minimum of 12 hours . 1410 Plug the charger into an appropriate outlet before inserting battery pack . -
Page 16: Important Charging Notes
Important charging notes Leaving the battery pack in the charger The battery pack can be left on maintenance charge in the charger indefinitely . The charger Longest life and best performance can be ob- will keep the battery pack fully charged . tained if the battery pack is charged when the As a battery pack approaches the dis- air temperature is between 65 and 75 °F... -
Page 17: Exploded Views
Charger troubleshooting If the battery pack does not charge properly: Check current at receptacle by plugging in a lamp or other appliance . Check to see if the receptacle is connected to a light switch which turns power off when you turn out the lights . Move charger and battery pack to a loca- tion where the surrounding air tempera- ture is approximately 65°F –... -
Page 18: Service Parts List
Fig. IPB1... - Page 19 Service parts IPB1 Item Description Part number Coupler 5852 Flexible hose 30 in . (76 cm) w/gasket 1230 Gasket (hose) 271884 Vent valve 286315 Vent/bulk valve 286134 Pump assembly 286305 Thermal protector 286253 Spring selector 286113 Gear selector 286097 Stroke indicator 286108 Battery 14 .4V 1401...
- Page 20 Fig.IPB2 33.5, 34.2 33.4 33.3 33.2, 34.1 33.1 32.1 34.3, 41.2 32.2 31.1 32.3 36.1 37, 36.2 32.4 32.5 31.2, 32 32.6 31.3 32.7 32.8 32.9 41.1 34.3, 41.2 Assembly note: Seal lips on seal (37) must be pointed toward the grease side of the pump unit block.
- Page 21 Service parts IPB2 Item Description Part number Seal 271889 Driver assembly 286285 Roller 286111 Stud 286110 Yoke 286107 Also included in Driver Assembly Kit 286285 . Service kits IPB2 Item Description Part number Check valve kit 280162 30 .1 Copper gasket 30 .2 Spring 30 .3...
-
Page 22: Troubleshooting
Troubleshooting Condition Possible cause Corrective action Motor fails to run . Battery needs charging . Recharge battery . Faulty wiring to motor . Remove battery, disassemble handle and check wiring for loose connection . Thermal protector trips . Wait five minutes . PowerLuber fails to dispense grease . - Page 23 Declaration of Conformity as defined by Declaration of conformity according to Machinery Directive 2006/42/EC.* EMC directive 2014/30/EU. * We declare that the model of the Battery We declare that the model of the Charger in the version supplied by us complies PowerLuber Grease Gun 1400, 1442, 1442E, with the provision of the above mentioned 1444, 1444E .
-
Page 24: Warranty
Lincoln industrial standard exclusion or limitation of incidental or conse- quential damages, therefore the above limita- warranty tion or exclusion may not apply to you . This warranty gives you specific legal rights . Standard limited warranty You may also have other rights that vary by Lincoln warrants the equipment manufac- jurisdiction . - Page 25 Special limited 5 year warranty limited oil meters, limited fluid control valves, aod (air-operated diaphragm pumps) Lincoln warrants the 712 series control valves, 912 series lube meters, electronic lube meters (980, 981, 982 series), our uni- versal inline digital meters (812/813 series), and our AOD pump offering to be free from defects in material and workman- ship for five (5) years following the date of...
- Page 26 This page left intentionally blank...
- Page 27 This page left intentionally blank...
- Page 28 SKF’s global footprint provides SKF customers with uniform quality standards For inclusion in the SKF BeyondZero portfolio, a product, service or solution and worldwide product availability. Our local presence provides direct access must deliver significant environmental benefits without serious to the experience, knowledge and ingenuity of SKF people.
