- Page 1 System 40 Custom Coaxial RF Signal Routing Systems Instruction Manual Contains Operating and Servicing Information...
- Page 2 WARRANTY Keithley Instruments, Inc. warrants this product to be free from defects in material and workmanship for a period of 1 year from date of shipment. Keithley Instruments, Inc. warrants the following items for 90 days from the date of shipment: probes, cables, rechargeable batteries, diskettes, and documentation.
- Page 3 System 40 Custom Coaxial RF Signal Routing Systems Instruction Manual ©1999, Keithley Instruments, Inc. All rights reserved. Cleveland, Ohio, U.S.A. Third Printing, March 2000 Document Number: 40MWS-901-01 Rev. C...
- Page 4 Revision B (Document Number 40MWS-901-01) ................March 1999 Revision C (Document Number 40MWS-901-01) ................March 2000 All Keithley product names are trademarks or registered trademarks of Keithley Instruments, Inc. Other brand and product names are trademarks or registered trademarks of their respective holders.
- Page 5 (IEC) Standard IEC 664, digital multimeter measuring circuits The types of product users are: (e.g., Keithley Models 175A, 199, 2000, 2001, 2002, and 2010) are Installation Category II. All other instruments’ signal terminals are Responsible body is the individual or group responsible for the use Installation Category I and must not be connected to mains.
- Page 6 NOT as safety earth ground connections. leads, and input jacks, must be purchased from Keithley Instru- ments. Standard fuses, with applicable national safety approvals, If you are using a test fixture, keep the lid closed while power is ap- may be used if the rating and type are the same.
-
Page 7: Table Of Contents
System 40 installation guidelines ........ - Page 8 System 40 rack assembly parts ........
-
Page 10: Installation
Installation Introduction System 40 Custom Coaxial RF Signal Routing Systems provide an integrated signal routing solution designed and built to cus- tomer specifications. The System 40 typically includes a Keithley Model 7001 or 7002 switch control unit, microwave coaxial switches, a power supply, and a 19-inch rack mount assembly. The IEEE-488 compatible switch controller operates the coaxial switches and provides an easy to read display of switch status. -
Page 11: Fixed Rack Installation
10-32x5/8 PPH panel to rails. Parts list Table 1-1 lists the supplied parts required to rack mount a typical System 40 chassis. Rack preparation 1. Select a location in the rack. 2. Hold up the system at the selected location in the rack. The four slotted mounting holes in the front panel dictate the location of the captive nut fasteners on the front rack rails. -
Page 12: Shelf Mount
Shelf mount Rack preparation 1. Select a position in the rack. In most cases, the weight of the System 40 dictates a position in the lower half of the rack. The System 40 typically takes up 10.5” of vertical space. - Page 13 7020-MWS\QCC switch card, installed in the 7001/2 mainframe, to the System 40 chassis mounted RF switch terminals using a ribbon cable terminated with a 96-pin DIN connector. One piece System 40’s may be shipped from the factory with this cable connected, two piece systems must be connected after rack installation. The ribbon cable 96-pin DIN connector label identifies the mating 7020-MWS connector.
-
Page 14: Operation
Operation Introduction System 40 Custom Microwave Switch Systems are derived from the Keithley Model 7116-MWS. Because each System 40 is unique, the 7116-MWS will be used to represent a typical configuration for switch system operating principles and troubleshoot- ing procedures. -
Page 15: Operating Instructions
Operation Operating instructions To select an input channel, the Model 7001 must close two switches at the same time. Table 2-1 lists which Model 7020-MWS digital outputs must be activated to select each respective RF input. The table also shows 7001 channels used to select the inputs. Table 2-1 Model 7001 channels and memory locations for 1x16 multiplexer 7020-MWS Digital Outputs... -
Page 16: Switch Life
The life of a switch is usually specified in cycles, that is the number of times it switches from one position to another and back. System 40 RF switches have lives from one-million to ten-million (1,000,000 to 10,000,000) cycles per switch position without noticeable performance degradation. -
Page 17: Model 7020-Mws 96-Pin Din Connector Pinout
Operation Model 7020-MWS 96-pin DIN connector pinout Figure 2-2 96-pin DIN connector pinout View from pin side of connector 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 Table 2-2 Output channel terminal identification Output... -
Page 18: Table 2-3 Input Channel Terminal Identification
Operation Table 2-3 Input channel terminal identification Input Connector Input Connector channel pin no. channel pin no. IN21 IN22 IN23 IN24 IN25 IN26 IN27 IN28 IN29 IN10 IN30 IN11 IN31 IN12 IN32 IN13 IN33 IN14 IN34 IN15 IN35 IN16 IN36 IN17 IN37 IN18... -
Page 19: Table 2-5 Model 7020-Mws 50 Pin Header Connector Pinout
Operation Table 2-5 Model 7020-MWS 50 pin header connector pinout Output channel terminal identification Output Connector Output Connector channel pin no. channel pin no. OUT1 OUT21 OUT2 OUT22 OUT3 OUT23 OUT4 OUT24 OUT5 OUT25 OUT6 OUT26 OUT7 OUT27 OUT8 OUT28 OUT9 OUT29 OUT10... -
Page 20: Model 7020-Qcc 96-Pin Din Connector Pinout
Operation Model 7020-QCC 96-pin DIN connector pinout Table 2-7 Output channel terminal identification Output Connector Output Connector channel pin no. channel pin no. OUT1 OUT21 OUT2 OUT22 OUT3 OUT23 OUT4 OUT24 OUT5 OUT25 OUT6 OUT26 OUT7 OUT27 OUT8 OUT28 OUT9 OUT29 OUT10 OUT30... -
Page 21: Table 2-9 Miscellaneous Terminal Identification
Operation Table 2-9 Miscellaneous terminal identification Connector Terminal pin no. VEXT1 VEXT1 +5.3V VEXT2 VEXT2 +5.3V... -
Page 22: Service
The following paragraphs contain troubleshooting and replacement parts information. Schematic diagrams and component lay- out drawings for the System 40 chassis are in the as-built documentation package. Refer to Model 7001 and 7020 manuals for further information about these components. -
Page 23: Ordering Information
NOTE: See Table 2-1 for information on closing channels. Ordering information To place an order or to obtain information concerning replacement parts, contact your Keithley representative or the factory. When ordering parts, be sure to include the following information: • Model numbers 7020-MWS, and 7001/2, System 40 •... - Page 24 Service Form Model No. Serial No. Date Name and Telephone No. Company List all control settings, describe problem and check boxes that apply to problem. Intermittent Analog output follows display Particular range or function bad; specify IEEE failure Obvious problem on power-up Batteries and fuses are OK Front panel operational All ranges or functions are bad...
- Page 25 Keithley Instruments, Inc. 28775 Aurora Road Cleveland, Ohio 44139 Printed in the U.S.A.
