This binder is suitable for encasing a raw edge of a stretch fabric with a tape.
WARNING:
Turn the power switch off when attaching this binder.
Note:
For sewing with a single needle, use the left needle.
1. PREPARATION
Replace the presser foot with the binder foot.
Cut a 1-5/8" (4.2 cm) wide strip of the stretch fabric along the
direction of stretch.
(1)
Direction of stretch
(2)
1-5/8" (4.2 cm)
Note:
The finished width of the bound tape should be approximately 1/2" (1.2 cm).
2. SETTING THE BASE PLATE
Place the base plate on the machine, inserting the boss on the under side of the base plate into the
left hole in the looper cover. Match the oval hole in the base plate with the right screw hole in the
looper cover and fix the base plate with the setscrew.
(3)
Base plate
(4)
Boss
(5)
Left hole
(6)
Oval hole
(7)
Right screw hole
(8)
Setscrew
ELNA 434
TAPE BINDER WIDE
42 – 12 mm (for 3 needles)
ENGLISH
1/3
