Routing Audio Signals

While video signals are routed from the HDMI input on the transmitter to the HDMI output on
the receiver, audio signals can be routed:
•

Routing Audio Signals from TP-594Txr

•
Routing TP-594Rxr Audio Signals
Routing Audio Signals from TP-594Txr
TP-594Txr provides two audio signal sources: the HDMI audio input and the analog balanced
audio (when set as source).
•
Routing an Analog Audio Source to the Receiver
•
Routing HDMI Audio Source to the Receiver
•
Routing a Priority-Selected Audio Source to the Receiver
•
Routing an Analog Audio Source to the Receiver for Auto-play when No Video Signal is
Present on page 15.
Routing an Analog Audio Source to the Receiver
To route the analog audio source to the receiver:
1. Connect an audio source to the AUDIO 5-pin terminal block connector.
2. If required, connect an HDMI source to the HDMI connector.
3. In the TP-594Txr
page appears.
4. Under Audio Settings:
▪
Set Audio Embedding Selection Mode to Manual.
▪
Set Audio Embedding Selection Priority to Analog.
▪
View the active audio Current Selection (Analog in this example).
When Audio Embedding Selection Priority on the
be output via the analog AUDIO port.
Figure 8: TP-594Txr Video and Audio Page – Analog Audio to Receiver Settings
5. In the TP-594Rxr
page appears.
TP-594Txr, TP-594Rxr – Routing Audio Signals
on page 16.
Navigation pane, click Video & Audio. The Video and Audio settings
Navigation pane, click Video & Audio. The Video and Audio settings
on page 12.
on page 12.
on page 13.
on page 14.
TP-594Txr is set to Analog, ARC cannot
