13) MOTOR BREAKDOWN

No. Part
1 RDF2021/1
RDF2021/3
2 RDF3014
3 RDF3009
4 RDF4038
5 RDF2019/1
RDF2019/3
6 RDF3010
7 RDF3011
8 RDF3005/1
RDF3005/3
9 RDF3012
10 RDF2020/1
RDF2020/3
11 RDF4040
12 RDF3013
13 RDF4039
Original instructions
Description
Armature Assembly 110v
Armature Assembly 230v
Bearing Sleeve
Field Coil Baffle
Field Coil Screws
Field Coil Assembly 110v
Field Coil Assembly 230v
Motor Frame
Brush Holder
Carbon Brush Set 110v
Carbon Brush Set 230v
Brush Caps
Speed Controller Assembly 110v
Speed Controller Assembly 230v
Speed Controller Screws
End Cap
End Cap Screws
Qty
1
1
1
1
2
1
1
1
2
1
1
2
1
1
2
1
2
