1.2

System Components

The EzSensor device installer should check the following items listed in the table below before
system installation. If the serial numbers of the individual parts do not match, do not install the
system. Contact your local distributor or agent for support.
This device should be connected with the product which is complied with IEC 60601-1.
<Table 2. EzSensor system components>
No
1. Sensor Module*
2. Control Board Box
3. USB PC Interface Cable (3M)
4. Holder for Sensor
5. Silicon cover*
6. Wrap* (Hygienic Sleeves)
7. S/W Installation CD
8. EzSensor Manual
* Patient applied part (Inside Patient environment)
1. Sensor Module:
Consists of a special CMOS sensor specifically designed for use in radiography and
enclosed in a hermetically sealed ergonomic capsule. The sensitive surface of the
sensor is covered with a thin layer of scintillating phosphorous, through which X-ray
radiation is converted into light and then into an electric charge.
8
Components Remarks
EasyDent + EzSensor Driver
Document
