Kramer KDS-8 Quick Start Manual

Scan for full manual
Step 1: Check what's in the box
KDS-8 4K SDVoE TM Transceiver
Quick start guide

Step 2: Get to know your KDS-8

# Feature
1 POWER LED
2 T/R LED
3 SOURCE LED
4 LAN LED
5 VIDEO LED
6 LINK Tx and Rx LEDs
7 OSD Navigation MENU
Buttons
+
-
INFO/ENTER
8 HDMI OUT Connector
9 HDMI IN Connector
10 10GbE (PoE) RJ-45 Connector
KDS-8 Quick Start
KDS-8 Quick Start Guide
This guide helps you install and use your
Go to www.kramerav.com/downloads/KDS-8
upgrades are available.
12V DC power adapter
Function
Lights when the device is powered ON.
Encoder mode: Lights green.
Decoder mode: Lights amber.
Decoder mode: Lights when the HDMI input is live and selected.
Lights when the 1GbE LAN connection is active.
Encoder mode: Lights when HDMI input signal is detected.
Decoder mode:
Genlock mode – Lights when streaming video is detected.
•
FastSwitch mode – Lights constantly.
•
Lights to indicate data transmission and reception activity over the 10GbE
streaming connection.
Press to enter the OSD menu, or to exit menu items.
When in OSD:
Press to move up
or adjust
selections.
When in OSD:
Press to move
down or adjust
selections.
When in OSD menu: Press to confirm a selection or to go deeper into a menu item.
Not in a menu: Press to activate the Information OSD.
Encoder mode: Connect to a video acceptor for local viewing of the video source
connected to HDMI IN.
Decoder mode: Connect to a video acceptor for viewing the video streamed from
the encoder.
Encoder mode: Connect to a video source for streaming.
Decoder mode: Connect to a video source for a local video input.
Connect to another SDVoE
KDS-8
for the first time.
to download the latest user manual and check if firmware
When not in OSD:
Press and hold both buttons simultaneously for 10
•
seconds to change the mode from encoder to
decoder or decoder to encoder.
Decoder mode: Press one of the buttons to toggle
•
the video source between 10GbE (PoE) and
HDMI IN.
TM
TM unit or to another device for streaming video.
P/N: 2 9 0 0 - 3 0 1 2 4 0 QS
4 rubber feet
Rev: 2
