Hubbell Facade Flood Installation Instructions

WARNING
DISCONNECT POWER DURING INSTALLATION AND BEFORE SERVICING.
READ ALL INSTRUCTIONS COMPLETELY BEFORE STARTING INSTALLATION
SAFETY PRECAUTIONS
Before starting the installation, disconnect the power by turning off the
circuit breaker. Turning the power off by using the light switch is not
sufficient to prevent electrical shock.
Read all warnings and information on carton(s) and product(s).
This luminaire is suitable for wet locations in ambience of 25 degrees C max.
These instructions do not attempt to cover all installation and maintenance
situations. If additional information is required, contact your nearest Hubbell
representative for assistance.
Warning:
Improperly installed fixtures can cause shock, electrocution and fire hazards.
Install and maintain with qualified personnel to meet all applicable Codes and
Ordinances. Turn power OFF prior to installation or performing any maintenance.
Ground properly and use appropriate wire connectors. Input voltage must range
between 114 ­126 VAC, 60Hz. Follow lamp and other equipment manufactures'
instructions. Installing electricians are responsible for evaluating local
conditions and ensuring safe operation.
GENERAL INSTALLATION INFORMATION
1. Use weatherproof J­box (by others) for wet locations. Use a weatherproof pipe
joint compound (by others) for all wire entries and plugged entries. Allow a
minimum of 6 (152mm) of supply wire to extend outside of J­box.
2. Knuckle threads are ½ ­ 1/4 NPS.
3. HID lamps normally take 2 to 5 minutes to reach full brightness. For Metal
Halide units, a +/­ 5% line voltage variation is needed to minimize lamp
colour shift.
4. If you ordered accessories, review field installed accessories now.
Installation:
Turn power OFF.
1. Depress door latches (A) and open door.
2. Un­package lamp and screw lamp tightly into socket
3. Close door and push Door Latches into locked position.
4. Insert fixture wires through J­box cover and thread cover onto Knuckle (B).
5. Make wire connections: Neutral to White; Hot to Black; Ground to Green and
secure cover fixture assembly to JBox (C).
6. Aiming: Rotate the fixture to desired direction and tighten the Locknut (D)
against the J­box cover. Loosen the Adjustment Bolt (E) on the knuckle, pivot
the fixture to the desired angle and re­tighten the adjustment bolt.
7. If you aim the fixture up, remove the stainless steel Drain Hole Screw (F)
located above the knuckle on the back.
Hubbell Canada LP, Lighting Division
870 Brock Road South, Pickering, ON, L1W 1Z8
Tel. (905) 839­1138
INSTALLATION INSTRUCTIONS
Façade Flood
For more information, visit our website: www.hubbellonline.com
