Summary of Contents for Ferno Megasus
- Page 1 Language: Language: English English Megasus Trolley User Manual To comply with BS EN 1789: 2007, the four-point harness MUST be used as a patient restraint and the Megasus MUST be secured with the two-part locking device.
- Page 2 (see page 2, safe working loads) to and from an ambulance. The Megasus Trolley can also be used to transport a bariatric patient of up to 400Kg, when in the lowest position. This is accommodated by extended cot sides and...
-
Page 3: Safe Working Load
Checking the trolley The following routine checks are recommended before the start of each shift's use of the Megasus Trolley. 1. Does the trolley have a properly installed mattress and patient restraining system? Check the mattress for damage; if any damage is found, it must be replaced. -
Page 4: Important Notes
To make full use of the Megasus trolley and its features, a two part 255 mm gauge track lock system, mounted towards the centre of the vehicle should be used. -
Page 5: Operating Procedure
1. Raise/lower the trolley to a suitable height. 2. Proceed with the transfer as aforementioned. PLEASE NOTE: Cot sides are not intended to be used to either manoeuvre or lift the trolley; damage may result from this practice. FERNO/MAN/03/10/202UK MEGASUS... - Page 6 Height Adjustment – Do not raise the trolley when located in the vehicle lock. The height adjustment must not be raised when the trolley is loaded above 200 1. The height adjustment of the Megasus is achieved by a simple hydraulic pumping action.
- Page 7 TROLLEY TOP UNTIL IT IS SECURED IN THE RETAINING CLIPS AS DAMAGE TO THE HANDLE WILL OCCUR IF IT IS INCORRECTLY STOWED. NEVER ROTATE THE PUSH/PULL HANDLE OVER THE TOP OF THE TROLLEY AS DAMAGE COULD OCCUR WHEN THE BACKREST IS LOWERED. FERNO/MAN/03/10/202UK MEGASUS...
-
Page 8: Important Note
5. Guide the trolley on to the tail lift, head end first making sure the cotslides clear all lift components. 6. Operate the tail lift as per manufacturer’s instructions. IMPORTANT NOTE Ensure the trolley is secure at all times when on board the tail lift FERNO/MAN/03/10/202UK MEGASUS... - Page 9 (diagram E). Test for security & safety. 3 Installation of Foot End Lock Assembly Install foot end lock assembly in exactly the same way as above adjacent to the positional guide plate at the foot end. FERNO/MAN/03/10/202UK MEGASUS...
- Page 10 Test for security and safety. PEGS TRACKING DEVICE LOCKED 3 Installation of Foot End Lock Assembly Install foot end lock assembly in exactly the same way as above adjacent to the positional guide plate at the foot end. FERNO/MAN/03/10/202UK MEGASUS...
- Page 11 6. Fasten the two leg restraints and adjust to ensure patient comfort. 7. To release the harness, press release button. NOTE: To remove the four-point harness, unclip two side brackets and un-loop the shoulder straps from cross bar located underneath the Back rest. FERNO/MAN/03/10/202UK MEGASUS...
- Page 12 DO NOT use the extended cotslides to support the full weight of the patient. Fitting Cot Side Pads To fit the Side Pads to the Trolley, first extend the Cotslides as above and place the side pads onto the extended Cotslides. FERNO/MAN/03/10/202UK MEGASUS...
- Page 13 Headrest The Megasus is provided with a detachable headrest that affords support particularly in the patient seated position. The black push button, located at the top of the backrest, allows the fitting and removal of the headrest.
- Page 14 Raise the legrest to the desired angle and release the lever to lock it in position. Support the legrest while making adjustments. NOTE: Potential pinch point - care should be taken during operation FERNO/MAN/03/10/202UK MEGASUS...
-
Page 15: Cleaning And Lubrication
Lubrication Your Ferno Megasus trolley will work efficiently and safely only when it is well lubricated. You MUST lubricate all moving and sliding parts after every inspection or preventative maintenance programme, or if there is inadequate lubrication for the moving parts to operate easily and quietly. -
Page 16: Warranty And Service
Warranty and Service Ferno (UK) Ltd. standard terms and conditions apply to all sales. A copy is available on request. These contain full details of warranty terms and do not limit the statutory rights of the customer. For service, maintenance and any questions regarding this, or any other Ferno... -
Page 17: Technical Data
Technical Data Product Name Megasus Trolley Overall Length (without headrest) 1925 mm Folded Length (Head End Only, inc. base) Overall Width (Top Frame) 570 mm Overall Width (Sides Extended) 955 mm (755mm intermediate position) Maximum Height (excluding mattress) 880 mm... - Page 18 Tel: + 44 (0) 1274 851999 Fax: + 44 (0) 1274 851111 e-mail: service@ferno.co.uk Registered number: 1007475 England As our policy is one of continuous development Ferno (UK) Ltd reserves the right to change the specifications without notice. Stock Code: 2003-0127...
