Summary of Contents for Risco ProSound

  • Page 1 Installation & Programming Manual Manual de Instalación y de Programación Manuale di Installazione e Programmazione Guide d'installation et de Programmation...
  • Page 3: Table Of Contents

    Ordering Information ................................External Sounder – ProSYS Programming Instructions Introduction ..........................Adding / Deleting the ProSound ..................Installer Menu: Configuring the ProSound Parameters ..........Installer Menu: System ......................User Menu: Diagnostics ...................... User Menu: Sounder Version .................... Event Log Messages ......................
  • Page 4: Prosound - Installation Instructions

    ProSound can be connected to any alarm system, or or it can be installed on the BUS of RISCO Group’s ProSYS/LightSYS integrated security system. When installed in conjunction with the ProSYS/LightSYS a whole new level of remote diagnostics and control becomes available, saving you time and reducing repeat site visits.
  • Page 5: Led Indication

    , sounder is silent. Terminal C+/- open, sounder is activated Defines the operation mode of the sounder. On (BUS): BUS mode configuration. Use this option for connection to the RISCO (Default: Stand Alone) BUS. Off (SA): Stand Alone configuration. Use this option for connection to any panel.
  • Page 6: Terminal Block Wiring

    Off (ST): Standard sound Not Used. Defines the TAMPER output operation (Wall and cover tampering) (Default: EOL) On (NOR): The TAMPER relay output contact opens upon tamper activation. Off (2K2) : EOL configuration:- On Board 2.2 KΩ EOL resistor connected in series with the Tamper Relay Contact.
  • Page 7 Right Terminal Description Speaker Used for the connection of the internal speaker (8Ω 30W). Not used in Stand-Alone configuration. GRN / YEL AUX RED/ COM Input DC power terminals. BLACK The maximum current drain from these terminals is 200mA. In BUS configuration, connect the wires according to the indicated colors.
  • Page 8: Technical Specifications

    Figure 2: BUS Wiring Notes For BOTH Stand Alone and BUS modes: The sounder will not operate when a battery is not connected or no power supply is connected to the PS terminals. After powering-up the sounder, it will not operate for a period of 20 seconds (sound and strobe) in order to avoid accidental activation during installation.
  • Page 9: Ordering Information

    External Sounder – ProSYS Programming Instructions Introduction The following section describes the additional dedicated ProSound software programming options, added to the ProSYS software. Up to 8 sounders can be added to the system and each can be assigned to any partition.
  • Page 10: Installer Menu: System

    Miscellaneous: Siren Quick Keys Parameter [8][2][2] Strobe Blink Defines the number of times that the strobe will blink in a minute . [8][2][2][1]..[5] Strobe Blink options [1]: 20 times per minute. [4]: 50 times per minute [2]: 30 times per minute. [5]: 60 times per minute.
  • Page 11: User Menu: Diagnostics

    Updated System Parameter Alarm ZE Cut [1][2][13] Default: Yes Yes: Produces an alarm if the communication between the main panel and any zone expander or sounder is lost. A report is transmitted to the central station. No: No alarm occurs. The system, however, produces a local trouble indication. User Menu: Diagnostics The diagnostics menu enables to test parameters that reflect the operation of the sounder.
  • Page 12: Event Log Messages

    Event Log Messages The following list details the Outdoor Sounder dedicated event messages, as displayed on the keypad LCD: LCD Text Event Description TAMPER SIREN=X Tamper alarm from sounder ID=X TMP RSTR SIREN=X Tamper restore from sounder ID=X PROX TMP SIREN=X Proximity tamper from approaching sounder ID=X PROX TMP RS S=X Proximity tamper restore from sounder ID =X...
  • Page 13 Sirena de Exterior - Instrucciones de Programación con ProSYS Introducción ........................... Agregar / Borrar la sirena ProSound ................Menú de Instalador: Configuración de los Parámetros de la ProSound ....Menú de Instalador: Sistema ..................... Menú de Usuario: Diagnósticos ..................Menú de Usuario: Versión de la Sirena ................
  • Page 14: Prosound - Instrucciones De Instalación

    ProSound – Instrucciones de Instalación Introducción La Sirena de Exterior de RISCO Group combina alto rendimiento y fiabilidad con un diseño exclusivo, por lo que es el toque final perfecto para sus instalaciones de intrusión e incendio. ProSound puede conectarse a cualquier sistema de alarma, o puede instalarse en el BUS de los sistemas de seguridad integrados ProSYS o LightSYS de RISCO Group.
  • Page 15: Indicación De Los Leds

    Define el modo de funcionamiento de la sirena. (Por defecto: OFF) ON (BUS): Configuración Modo BUS. Use esta opción cuando conecte la sirena al BUS RISCO. OFF (SA): Configuración Modo ”Stand-Alone”. Use esta opción para conectar la sirena a cualquier otra central.
  • Page 16: Cableado Del Bloque De Terminales

    Sonido de la sirena. (Por defecto: OFF) ON (FR): El sonido se ajusta al estándar NFA2P francés OFF (ST): Sonido estándar Sin usar. Define el funcionamiento de la salida de TAMPER (Tamper de Tapa y Pared): (Por defecto: OFF) ON (NOR): La salida de relé de TAMPER se abre en caso de sabotaje. OFF (2K2): Configuración RFL (EOL): Resistencia (interna incorporada en placa) de fin de línea (EOL) de 2,2 KΩ...
  • Page 17 C+/- Se utiliza para disparar la sirena. El terminal se comporta de acuerdo a la configuración del DIP1 SW3. STB (Entrada Terminal a negativo: la luz estroboscópica está activada. estroboscópico) Terminal abierto: la luz estroboscópica está desactivada. Terminales Descripción Derecha Speaker Se utiliza para la conexión del altavoz interno (8Ω...
  • Page 18: Especificaciones Técnicas

    Terminales Descripción Derecha Speaker Usado para la conexión del altavoz interno (8Ω 30W). BUS YEL/ BUS En configuración BUS conecte los cables según los colores indicados (YEL = Amarillo, GRN = Verde). Figura 2 – Cableado en modo BUS Notas para AMBOS modos BUS y “Stand-Alone”: La sirena no funcionará...
  • Page 19: Información Para Pedidos

    Introducción La siguiente sección describe las opciones de programación de la sirena ProSound, incluidas en el software de la ProSYS. Se pueden añadir hasta 8 sirenas ProSound al sistema, y cada una de ellas puede asignarse a cualquier partición. Recomendamos leer y comprender totalmente los Manuales de Instalación y de Usuario de ProSYS, antes de programar la sirena ProSound.
  • Page 20 El tiempo que la luz estroboscópica parpadeará cuando el sistema se arme. Nota: Si el aviso de armado en la luz estroboscópica de la sirena está definido como NO (ver la sección Agregar / Borrar la Sirena ProSound), este parámetro será ignorado. [8][2][4] LED de la Sirena Define el modo de funcionamiento LED2 de estado.
  • Page 21: Menú De Instalador: Sistema

    Varios: Sirena Teclas Rápidas Parámetro El sistema no realizará una prueba de carga de la batería. [8][2][6][2] Cada 24 Horas (Predeterminado) El sistema realizará una prueba de carga de la batería cada 24 horas. Menú de Instalador: Sistema Nuevos Parámetros del Sistema [1][2][35] Predeterminado: No Tamper de Proximidad Audible...
  • Page 22: Mensajes Del Registro De Eventos

    Si ocurre un problema de comunicación con la sirena, aparecerá el mensaje “PROBLEMA DE COMUNICACIÓN. Mensajes del Registro de Eventos La siguiente lista muestra los mensajes de eventos de la Sirena ProSound, según aparecen en el teclado LCD: Texto en el LCD Descripción del Evento...
  • Page 23 ................ ProSound - Istruzioni per l’installazione Introduzione ........................... Caratteristiche Principali ..................... Installazione ........................... Indicatori LED ........................Predisposizione microinterruttori ..................Cablaggio morsettiere ......................Caratteristiche Tecniche ..................... Come Ordinare ..........................Sirena da esterno - Istruzioni per la programmazione tramite sistema ProSYS Introduzione ...........................
  • Page 24: Prosound - Istruzioni Per L'installazione

    ProSound - Istruzioni per l’installazione Introduzione ProSound è la sirena autoalimentata di RISCO Group che oltre alla qualità ed affidabilità ha una estetica esclusiva che dà il tocco finale a qualsiasi impianto antifurto. ProSound può essere connessa a qualsiasi sistema d’allarme o può essere collegata al BUS 485 dei sistemi d’allarme ProSYS e LightSYS.
  • Page 25: Indicatori Led

    Quando il microinterruttore viene impostato su On (BUS), i MIC1, 2 e 3 (A1, A2, A3) del banco DIP1 vengono utilizzati per predisporre l’indirizzo ID della sirena sul BUS RISCO. L’indirizzo ID della sirena va impostato come per tutti gli altri accessori BUS. MIC5...
  • Page 26: Cablaggio Morsettiere

    NOTA: Configurazione in modalità BUS: Questo microinterruttore deve essere impostato su On (TMF) affinchè il tamper della sirena venga gestito sul BUS RISCO. Cablaggio morsettiere Modalità Stand Alone La tabella che segue spiega le connessioni che vanno effettuate nella procedura di cablaggio della sirena:...
  • Page 27 PROX Connettere questi morsetti ad un ingresso di zona per gestire una segnalazione dal circuito di antiavvicinamento della sirena. (Uscita antiavvicinamento / antischiuma) NOTA: E’ anche possibile collegare questi morsetti in serie ai morsetti di manomissione (TAMPER). TRBL (Uscita di L’uscita di anomalia “TRBL”...
  • Page 28 Morsettiera Descrizione sinistra PS +/- Usare questi morsetti per collegare un alimentatore esterno da 13.8Vcc, 1.6A alla sirena. NOTA: La corrente massima che la sirena può richiedere a questi morsetti è 1.6A rispetto ai soli 200 mA richiesti tramite i morsetto “AUX RED” e “COM BLK”. Quando un alimentatore è...
  • Page 29: Caratteristiche Tecniche

    BUS 4 fili Compatibilità ProSYS II° livello IMQ Livello di Prestazione Come Ordinare Sirena in policarbonato da esterno, coperchio lampeggiante di ProSound 200P colore ambra, fornita con circuito antiavvicinamento. Sirena in policarbonato da esterno, coperchio lampeggiante di ProSound 200 colore ambra.
  • Page 30: Sirena Da Esterno - Istruzioni Per La Programmazione Tramite Sistema Prosys

    Introduzione Questo manuale descrive le opzioni di programmazione relative la sirena ProSound aggiunte al software delle centrali ProSYS. Le centrali ProSYS possono gestire fino a 8 sirene ProSound assegnate a una o più partizioni del sistema. Si consiglia di leggere attentamente il manuale di Installazione e Programmazione ProSYS nonché quello Utente prima di programmare la Sirena ProSound.
  • Page 31 Varie: Sirena Tasti Rapidi Parametro [8][2][1][1] Sempre spento Il lampeggiante è disabilitato. [8][2][1][2] Segue Sirena (Default) Il lampeggiante viene attivato quando viene attivata la sirena. [8][2][1][3] Segue Allarme Il lampeggiante viene attivato quando si è verificata una condizione di allarme nella partizione alla quale la sirena è...
  • Page 32: Menù Tecnico: Sistema

    5. Usare i tasti per scorrere tra i risultati del test. NOTA: La diagnostica può anche essere effettuata tramite il software di Teleassistenza RISCO Group, in locale o in remoto. Manutenzione: Diagnostica Sirena Tasti Rapidi Parametro Diagnostica Sirena...
  • Page 33: Messaggi Della Memoria Eventi

    Manutenzione: Diagnostica Sirena Tasti rapidi Parametro Versione Sirena [4][0][4] Il menu versione sirena fornisce le seguenti informazioni di ogni sirena collegata al sistema: Codice prodotto Versione Software Data Software Checksum Software NOTA: Se si verifica un problema di comunicazione con la sirena, il messaggio “ANOMALIA DI COMUNICAZIONE !”...
  • Page 35 ..........Sirène externe –– Mode de programmation du ProSYS Introduction ..........................Ajout / Suppression du ProSound..................Menu Installateur : Paramétrage du ProSound ............. Menue Installateur : Système .................... Menu Utilisateur : Diagnostics ................... Menu Utilisateur : Version Sirène ..................Messages du Journal (Historique des évènements) ............
  • Page 36: Prosound - Mode D'installation

    La sirène ProSound peut être connectée à tout système d'alarme, ou installée sur le système BUS de sécurité intégréeProSYS de RISCO Group. L'installation avec le ProSYS/LightSYS permet l'accès à toute une gamme nouvelle de diagnostics et contrôle à...
  • Page 37: Réglage Des Commutateurs Dip (Dip-Switchs)

    Marche (ON - BUS) : configuration en mode BUS. Utilisez cette option lorsque la Définition par défaut : sirène est connectée au BUS RISCO. autonome Arrêt (OFF - SA) : configuration autonome. Utilisez cette option pour relier la sirène à une centrale quelconque.
  • Page 38: Câblage Du Bloc De Connexion

    Non utilisé Définit le mode de fonctionnement de la sortie de Protection anti-sabotage Définition par Marche (ON – NOR): Le contact du relais de l’autoprotection s’ouvre lors d’une : EOL) autoprotection. défaut Arrêt (OFF – 2K2): Configuration EOL: :- Sur la carte une résistance de 2,2kΩ est en série avec le contact du relais d’autoprotection.
  • Page 39 Connecteur de Description droite Speaker (Haut- Sert à la connexion du haut-parleur interne (8Ω 30W). parleur) BUS Green / Pas utilisé en configuration autonome. Yellow (connexions BUS vert/jaune) Blocs de connexion électriques CD. AUX RED/ COM Le courant maximum qui peut être extrait de ces blocs de connexion est de 200mA. BLACK (connexions En configuration BUS, reliez les fils point par point en respectant les couleurs...
  • Page 40 Reliez ces blocs de connexion seulement en configuration BUS, point par point en respectant les couleurs indiquées. Remarques pour les DEUX Stand Alone et BUS modes : La sirène ne fonctionnera pas en l'absence de connexion de la pile ou de l'alimentation électrique aux terminaux PS.
  • Page 41: Spécifications Techniques

    Toutes centrales Compatibilité ProSYS BUS à 4 fils, jusqu'à 300m de la centrale principale Information de Commande ProSound 200P Sirène extérieure en polycarbonate, couvercle de lentille ambre, avec protection anti-approche ProSound 200 Sirène extérieure en polycarbonate, couvercle de lentille ambre...
  • Page 42: Sirène Externe -- Mode De Programmation Du Prosys

    ProSYS. Le système peut recevoir jusqu'à 8 sirènes, chacune pouvant être attribuée à n'importe quelle partition. Avant de programmer le ProSound, il est recommandé de lire et de bien comprendre les instructions du guide d'installation et d'utilisation du ProSYS. Il est également conseillé de lire attentivement le chapitre consacré à...
  • Page 43 Divers : Sirène (DIVERS:SIRENE-BUS) Touches rapides Paramètre Le flash s'active lorsque la sonnerie de la sirène est déclenchée. [8][2][1][3] Suivre Alarme Le flash s'active lorsqu'une alarme se produit dans les partitions reliées à la sirène sélectionnée. [8][2][2] Clignotement du Flash Définit le nombre de fois où...
  • Page 44: Menue Installateur : Système

    Menue Installateur : Système Nouveaux paramètres de système [1][2][35] Réglage par défaut : Autoprotection de proximité sonore (SAB. PROX. AUN) Oui : une violation anti-approche de proximité déclenchera la sirène. Non : une violation anti-approche de proximité ne déclenchera pas la sirène et sera considérée par le système comme une panne.
  • Page 45: Menu Utilisateur : Version Sirène

    Menu Utilisateur : Version Sirène [4] pour accéder au menu Maintenance. 28. Du menu Utilisateur, appuyez sur 29. Tapez le code Installateur (ou Sub-installateur) et appuyez sur 30. Appuyez sur [0][4] pour accéder au menu Version Sirène : Maintenance : Diagnostics Sirène Touches rapides Paramètres Version Sirène...
  • Page 47 RISCO Group Limited Warranty RISCO Group and its subsidiaries and affiliates ("Seller") warrants its products to be free from defects in materials and workmanship under normal use for 24 months from the date of production. Because Seller does not install or connect the product and because the product may be used in conjunction with products not manufactured by the Seller, Seller cannot guarantee the performance of the security system which uses this product.
  • Page 48 Contacting RISCO Group RISCO Group is committed to customer service and product support. You can contact us through our website www.riscogroup.com or as follows: United Kingdom Brazil Tel: +44-(0)-161-655-5500 Tel: +55-11-3661-8767 E-mail: support-uk@riscogroup.com E-mail: support-br@riscogroup.com Italy China (Shanghai) Tel: +39-02-66590054 Tel: +86-21-52-39-0066 E-mail: support-it@riscogroup.com...
