Connect
† The Pre-amp Output is internally wired in parallel with the Insert Send.
‡ The External and iJack Inputs are internally summed together.
4
Power Switch
Mains Inlet
Pre-amp 2
Pre-amp 1
Output †
Output †
Insert †
Insert †
Microphone
Microphone
and DI Inputs
and DI Inputs
External Input ‡
Monitor Output
