CABLE TIE INSTALLATION TOOL OPERATING INSTRUCTIONS
© Panduit Corp. 2013
Pan-Ty, Dome-Top Barb Ty, Sta-Strap, Dura-Ty, Contour-Ty, and In-Line Cable Ties
of Standard, Heavy-Standard, Light-Heavy, and Heavy cross sections.
1
2
A
B
STD:
.19"
(4.8mm)
HVY-STD:
.25"
(6.3mm)
LHVY:
.30"
(7.6mm)
HVY:
.30 - .35"
(7.6 - 9mm)
GTH
(Mil. Std. No.: MS90387-2)
FOR INSTALLING:
A
C
0 - 4
4 - 6
5 - 6
Tel: +31 546-580-452 • Fax: +31 546-580-441
E-mail: emeatoolservicecenter@panduit.com
5 - 8
Page: 1 of 2

TOOL MAINTENANCE: GTH

This tool requires no special operator
maintenance.
REPLACEMENT KITS and
ACCESSORIES: (Sold Separately)
D: KGTHTL – Tension Locking Kit
E: KGTHBLD – Blade Replacement Kit
F: WH24287C02 – Blade Guard
WH25092A01 – Extended Blade Guard

Technical Support:

Tel: 888-506-5400, ext. 83255
E-mail: techsupport@panduit.com
Technical Support: Panduit Europe
EMEA Service Center, Almelo, Netherlands
EU Website: www.panduit.com/emea
www.panduit.com
PA24634A01
Rev. 05 3-2013
