Connecting a secondary display

The DisplayPort and HDMI ports on the rear of the computer allow you to connect secondary displays to the
computer.
You can connect up to two displays in one of the following configurations:
Two displays daisy-chained to the DisplayPort
One display connected to the DisplayPort and one to the HDMI port
If you are adding a display that has a DisplayPort or an HDMI port, then no video adapter is required. If you are
adding a display that does not have a DisplayPort or HDMI port, you can purchase a video adaptor from HP for
your configuration.
DisplayPort adapters, HDMI adapters, and video cables are purchased separately. HP offers the following
adapters:
DisplayPort to VGA adapter
DisplayPort to DVI adapter
HDMI to VGA adapter
HDMI to DVI adapter
To connect a display:
1.
Turn off power to the computer and the display that you are connecting to the computer.
2.
If your display has a DisplayPort port, connect a DisplayPort cable directly between the DisplayPort port
on the rear of the computer and the DisplayPort port on the display.
If your display has an HDMI port, connect an HDMI cable directly between the HDMI port on the rear of
the computer and the HDMI port on the display.
3.
If your display does not have a DisplayPort port, connect a DisplayPort video adapter to the DisplayPort
port on the computer. Then connect a cable (VGA or DVI, depending on your application) between the
adapter and a display.
If your display does not have an HDMI port, connect an HDMI video adapter to the HDMI port of the
computer. Then connect a cable (VGA or DVI, depending on your application) between the adapter and a
display.
4.
Turn on power to the computer and the display.
NOTE:
Use the graphics card software or the Windows Display Settings to configure the display as a
mirrored image of the computer display or an extension of the computer display.
8
Chapter 2 Setup
