Belmont Bel-Cypher N Installation Manual

Digital panoramic radiograph
Hide thumbs

Advertisement

Quick Links

Ｉ０２－１１６７Ｅ
★ ★ ★ ★ Read this installation Manual thoroughly before Installation.
The classification is shown as follows
According to the type of protection against electric shock. :
According to the degree of protection against electric shock.
TAKARA BELMONT CORPORATION.
Bel-Cypher N
Installation Manual
Digital Panoramic Radiograph
Bel-Cypher N
Notice
Class Ⅰ
Type B applied part
:

Advertisement

loading
Need help?

Need help?

Do you have a question about the Bel-Cypher N and is the answer not in the manual?

Questions and answers

Related Manuals for Belmont Bel-Cypher N

Summary of Contents for Belmont Bel-Cypher N

  • Page 1 Ｉ０２－１１６７Ｅ Installation Manual Digital Panoramic Radiograph Bel-Cypher N Notice ★ ★ ★ ★ Read this installation Manual thoroughly before Installation. The classification is shown as follows Class Ⅰ According to the type of protection against electric shock. : Type B applied part According to the degree of protection against electric shock.
  • Page 2 “Bel-Cypher N” X-Ray. The instructions contained in this book should be thoroughly read and understood before attempting to install the “Bel-Cypher N” unit. After the installation is completed, file this manual and refer back to it when performing periodic maintenance.

  • Page 3: Table Of Contents

    8. Methods to install LAN Card for Panoramic Radiography 1 /3 9. Methods to install a TWAIN driver in imaging software 1 / 20 10. Post-Installation Instructions 1 / 5 11. Contact Information 1 / 1 12. Revised record of this manual 1 / 1 Bel-Cypher N...

  • Page 4: Introduction

    6. Repair and repair parts supply Repair and repair parts supply is available for 10 years from discontinued date. mark means “ Attention, consult accompanying documents “. Bel-Cypher N...

  • Page 5: Warning

    Explains an instruction where personal injury or physical damage may occur CAUTION Explains an instruction that should be observed for safety reasons NOTE States descriptions which serve to improve work efficiency and to help user to understand instructions in the manual Bel-Cypher N...
  • Page 6 This X-ray Unit may be dangerous to patient and operator unless safe exposure factors and operating in- structions are observed. Follow the local zoning authority's regulations regarding X-ray room that you are going to install Bel-Cypher N. The floor should have strength of 650N/1 0 0 c m and should be rigid.

  • Page 7: Pre-Installation Instructions

    3 Electrical Requirements 1) Power Supply Bel-Cypher N X-Ray operates on a power supply of 120 VAC. A three wire GROUNDED circuit, sep- arately connected to the central distribution panel with an over current protection device rated for 15 amperes. Recommended wire size is 12 AWG. But if the wire run distance is to exceed 50 feet, 10 AWG is required.

  • Page 8: Specification

    4. Specifications General name Digital Panoramic Radiograph Model Bel-Cypher N Power Voltage 120Vac 60Hz 1φ Power Capacity High Tension High Tension Generator (100kHz) Generator X-ray Tube Voltage 60kV to 80kV (1kV step) X-ray Tube Current 2 to 8mA (2mA step)
  • Page 9 5. Name of each parts and Dimension of equipment １．Names of each parts of equipment １． １． １． Bel-Cypher N...
  • Page 10 2． ． ． ． Dimensions of equipment (with Free Standing Base) Bel-Cypher N...
  • Page 11 Dimensions of equipment (without Free Standing Base) Bel-Cypher N...
  • Page 12 16) Fixing Screws fro Rotation Unit Cover Binder Screw: M3 x 8 (2 pcs.), Nylon Washer: φ3 (2 pcs.) 17) Fixing Screws for Sliding Unit ASSY Binder Screw: M3 x 16 (4 pcs.), Nylon Washer: φ3 (4 pcs.) 18) Power Cable Bel-Cypher N...
  • Page 13 Accessories 2-1. Accessories 1) Head Holding Rods (Panorama) 2) Chinrest (Panorama) 3) Bite Block (Panorama) 4) Ear Rods (TMJ / 4 divisions) Bel-Cypher N...
  • Page 14 2-2. Expendable Supplies Bite Block Cover 3. X-ray Exposure Switch (with Holder) 4. CD containing TWAIN Driver Bel-Cypher N...

  • Page 15: Installation Procedure

    Put waste cloth on packing vinyl Pillow Pillow on the pillows to avoid scratch 2． ． ． ． Remove pillar cover from Pillar Assy (1): Bind M3 × 6 2 sets (2): Nylon washer φ3 2 sets Pillar cover Bel-Cypher N Pillar assy...
  • Page 16 6 sets. Free Standing Base Type Floor Type 4． ． ． ． Attach the Wall Bracket to upper part of the Pillar by 2 flat head cap screws cap screw (1): M6 × 12 2 sets Wall bracket Bel-Cypher N...
  • Page 17 6． ． ． ． Lift Sliding Unit, set 2 counter weight and adjusting weight(s) in upper counter weight frame, then attach the cover. (1): Screw M4 × 10 2 sets Adjusting weight Counter Weights (2) Opening Cover Steel Rod Bel-Cypher N...
  • Page 18 2 sets Counter Weights (2) Opening Cover Steel Rod (1): Screw M4 × 10 2 sets 8． ． ． ． Attach pillar cover. (1): Bind Screw M3 × 6 2 sets (2): Nylon washer φ3 2 sets Pillar cover Bel-Cypher N...
  • Page 19 9 Move the equipment to where you place Bel-Cypher N, place two holes of th e wall bracket on the screw thread of the concrete strike anchors. Tighten M8 nuts. Confirm that the apparatus is securely fixed. When coach bolts ( ( ( ( diameter = 8mm, length = 40mm) ) ) ) are used ①...
  • Page 20 Run the supplied earth wire from the hole located at the bottom of the column to the grounding terminal in the X-Ray room. Connect Earth Wire to facility Earth Ground in accordance with National Electric Code and local codes. Secure the conductor with a screw and a spring washer. Refer to the figure below. Bel-Cypher N...
  • Page 21 Align rotation unit by using taper pins. 11. 2. Insert taper pins with a hammer. 11. 3. Tighten and Fix hexagon bolts. Hook Rotation Unit ASSY (1): Taper Pin 2sets. φ5X25 (2): hexagon bolts 4sets. φ8X25 (3): Spring 4sets. φ8 (4):Flat 4sets. φ8 Bel-Cypher N...
  • Page 22 12. Remove Carriage Holder from Rotation unit Assy Take the carriage holder off the rotation unit assembly. φ8 (1): Nut 4sets. φ8 (2): Spring Washer 4sets. Cap screw M6 4sets (3): Bel-Cypher N...
  • Page 23 13． ． ． ． Connect the wire harness from Sliding Unit to the PC board of Rotation Unit. Bel-Cypher N...
  • Page 24 14． ． ． ． Connect the wire harness from Rotation Unit to wire harness from Sliding Unit. Bel-Cypher N...
  • Page 25 15. 1. Align positioning pins of Chinrest Unit ASSY to positioning holes of Sliding Unit ASSY. 15. 2. Attach Chinrest Unit by cap screw ①M5×20 (4 sets), Spring washer ②φ5 (4 sets) & ③Flat washers φ5 (4 sets). Bel-Cypher N...
  • Page 26 M3 X 8 2 sets. Slowly rotate arm to 90 degrees position. Turn the ball screw in order to bring rota- tion unit to forward end. (1) Bind Screw M3×16 2 sets (2) Bind Screw M3×8 2 sets Bel-Cypher N...
  • Page 27 Connect (CNSM) Fix by a cap screw M6×40. 18． ． ． ． Put the rotating unit cover on rotating Unit, Put Frankfurt plane knob Attaches cover. Fix with two truss screws M3×8. Frankfurt plane knob Bel-Cypher N...
  • Page 28 19． ． ． ． Attach the Upper Cover on the Pillar Pillar cover Hole Spiral code 20． ． ． ． Insert Chinrest and Head Holding Rods or Ear Rods to Chinrest ASSY. Head Holding Rods Chinrest Unit Bel-Cypher N...

  • Page 29: Methods To Install Lan Card For Panoramic Radiography

    8． ． ． ． Methods to install a LAN Card for Panoramic radiograph 1. Change User Accounts and Safety Rem: If Operating System is Windows XP, skip this section. 1) Start Control Panel, click “User Accounts and Family Safety” 2) Choose ”Change your Windows password” Bel-Cypher N...
  • Page 30 5 ) After user account control setting is changed, O/S requests to reboot PC. If you need to add an expanded LAN card, go to next section (install LAN card without rebooting PC.) If you are not going to add an expanded LAN card, reboot PC. Bel-Cypher N...
  • Page 31 2. Install expanded LAN card 1. Turn the power of user supplied personal computer off, and unplug the power cable. 2. Open the cover of PC. Insert an expanded LAN Card supplied with Bel-Cypher N. 3. Close the cover of PC.
  • Page 32 8 Install wizard comes up, Click「Next >」 9. License agreement screen comes up、choose「I accept the terms in the license agreement」then click「Next >」 10. Setup Options screen comes up, do not make change, click「Next >」 Bel-Cypher N...
  • Page 33 12. When below screen is shown, click「Continue Anyway」 13. After installation is completed, click「Finish」 14. Connect LAN cable of Bel-Cypher N to the PC. * Make sure to connect LAN cable of Bel-Cypher N directly to expanded LAN Card. Bel-Cypher N...

  • Page 34: Methods To Install A Twain Driver In Imaging Software

    9． ． ． ． Methods to install a TWAIN driver in imaging software 1. Set IP address 1) Open「Control Panel」 2) Choose「Network and Internet」 3) Choose「Network and Sharing Center」 4) Choose「Change adapter settings」 Bel-Cypher N...
  • Page 35 Right click LAN Connection that is connected to Bel-Cypher N. Choose property. If you use the LAN card supplied with Bel-Cypher, open 「Intel(R) Gigabit CT Desktop Adapter」 5) Double click 「Internet Protocol Version 4(TCP/IPv4)」in「The connection uses the fol- lowing items:」...
  • Page 36 2.Set Jumbo Packet 1) Go to「Control Panel」→「System and Security」→「Device Manager」 2) Right click LAN Connection that is connected to Bel-Cypher N. Then choose property. If you use the NIC supplied with Bel-Cypher, right click 「Intel(R) Gigabit CT Desktop Adapter」and choose property.
  • Page 37 3.DCAM-API Install 1) Run「setup.exe」in「Common」→「DCAM-API」of Library CD 2) click「Install」 3) Click「Next >」 4) Check「I accept the terms of the license agreement」, then click「Next >」 Bel-Cypher N...
  • Page 38 6) When below screen is shown, click「Finish」to finish installation 4.Install DirectX 1) Run 「DXSETUP.exe」in 「Common」→「DXInst」of Library CD 2) When below screen is shown, check「I accept the agreement」then click「Next >」 3) When below screen is shown, click 「Next >」 Bel-Cypher N...
  • Page 39 1) Turn the power of PC ON. ※If the driver is not installed automatically, then run 「Setup.bat」stored in a CD 2) Set Bel-Cypher N TWAIN Driver of Install Disc. 3) .NET Framework 3.5 SP1 setup display such as Fig 2-1 starts automatically.
  • Page 40 5) The dialogue such like Fig. 2-3 is displayed. .NET Framework 3.5 SP1 and Visual C++ Run time is installed. Fig 2-3 Visual C++ Run time Install screen 6) After the installation was completed, the dialogue such like Fig. 2-4 Bel-CypherN TWAIN Set- up Wizard starts. Click “Next” Fig 2-4 Bel-CypherN TWAIN Setup Wizard Bel-Cypher N...
  • Page 41 Fig 2-5 “Select Installation Folder” screen 8) The dialogue such like Fig. 2-6 is displayed. Click “Next” Fig 2-6 Confirm Installation screen 9) The dialogue such like Fig. 2-7 is displayed. Bel-CypherN TWAIN is installed. Fig2-7 Installing Bel-CypherN TWAIN screen Bel-Cypher N...
  • Page 42 10) The dialogue such like Fig. 2-8 is displayed. Click “Close” Fig 2-8 Installation Complete screen 11) Installation is completed Bel-Cypher N...
  • Page 43 」、「6.2 Chan 」、「 」、「 ge IPaddress of Bel-Cypher N」 」 」 」 &「 「 「 「 6.3 Change IP address of NIC」 」 」 」 according to th e order Below are default IP address and default subnet mask Default IP address / Subnet mask for sensor IP address：169.254.87.181...
  • Page 44 5) Click「DeviceDiscovery」 6) When IP address for sensor is displayed, click「Open」 7) When 「Open Success」is displayed, then click「IP Change」 8) IP address change screen comes up. Bel-Cypher N...
  • Page 45 14) Click 「×」on upper right corner to close GigE_IP_Tool_*_**.exe(if OS is 64bit, GigE_IP_Tool_*_**_x64.exe) 15) Below message will be shown, click「ＯK」 16) Wait at least two seconds, then turn on the power of Bel-Cypher N after closing GigE_IP_Tool_*_**.exe(or GigE_IP_Tool_*_**_x64.exe) Bel-Cypher N...
  • Page 46 2) When above TWAIN screen is shown, click L, M or S, then hit 「Ctrl」 + 「Alt」 + 「i」 simultaneously 3) IP address set up screen comes up 4) Enter new IP Adress and SubnetMask ※ ※ ※ ※ Set IP address and Subnet Mask as Bel-Cypher N is included within sensor network. Bel-Cypher N...
  • Page 47 5) Click「Settings」 6) When「Turn on the the power of the X-ray equipment again.」is displayed, then turn off and on the power of Bel-Cypher N Bel-Cypher N...
  • Page 48 6.3.Change IP address of NIC ※ ※ ※ ※ Change IP address of NIC, after you changed IP address of Bel-Cypher N and IP address of sensor. 1) Go to 「Control Panel」→「Network and Internet」→「Network and Sharing Center」→ 「Change adapter settings」...
  • Page 49 ※ ※ ※ ※ Use LAN cable of category 5e or better Caution! If you run software that force heavy load to PC, transfer & acquisition of image could be interrupted. Please schedule to run Windows update or virus scan update to be performed outside of clinic hours. Bel-Cypher N...
  • Page 50 Below HUBs are used for validation HUB(100Mbps) HUB(1000Mbps) Model name Switch-S8LN GS105 Part Number MN21080NK GS105-300JPS Manufacturer Panasonic NETGEAR Data transfer method IEEE 802.3 (10BASE-T) IEEE 802.3i (10BASE-T) IEEE 802.3u (100BASE-TX) IEEE 802.3u (100BASE-TX) IEEE 802.3ab (1000BASE-T) Auto-negotiation function Bel-Cypher N...

  • Page 51: Post-Installation Instructions

    ①Make sure the main power is off. Remove covers from Rotation Unit. (Figure 1) ②Cover radiation aperture with lead ③Turn on the power of PC that is connected to Bel-Cypher N. Hit Ctrl + Alt + T simultaneously to get into Test mode.
  • Page 52 2.2. 1. Cover radiation aperture with lead. 2.2. 2. Set exposure condition by referring the Operation Manual. 1) Exposure Orbit → Panorama 5) Manual Exposure 6) Tube Voltage: 60kV 7) Tube Current: 2mA 2.2.3. Irradiate X-Ray and confirm the operation. Bel-Cypher N...
  • Page 53 Are there any problems when the power plug is insert- Heat □ OK □ NG Allophone □ OK □ NG □ OK □ NG Off-flavor □ OK □ NG Does the Power Code have a scratch or a crack? Bel-Cypher N...
  • Page 54 6-1) Are all positioning beams turned on by depressing forward / back- □ OK □ NG ward switch of Focus Beam? 6-2) Dose Forward / backward operation of Focus Beam on ARM work □ OK □ NG by depressing forward / backward switch? Bel-Cypher N...
  • Page 55 5 minutes later after the last operation? After power is turned off automatically, Will power turn on again □ OK □ NG normally? 5. Externals □ OK □ NG Are there scratches or cracks? □ OK □ NG Are all covers secured with screws? Bel-Cypher N...
  • Page 56 11. Contacting information Belmont Equipment A Division of TAKARA BELMONT USA, Inc. 101 Belmont Drive Somerset, NJ 08873 Toll Free (800) 223-1192 Toll Free Fax (800) 280-7504 www.belmontequip.com TAKARA COMPANY, CANADA, LTD. 2706 South Sheridan Way Mississauga, Ontario, Canada L5J 2M4...
  • Page 57 12. Revision data of this manual This manual was created on Oct 2008. Revised July 2014 Document number ：B02-T170 Bel-Cypher N...
