Vertical XCELERATOR IP Quick Start Manual

Quick Start Guide

P/N 7552-00

START HERE

It is strongly recommended that you follow
these step by step instructions to set up
and quickly start to use your Xcelerator IP
gateway.
INSTALLING THE XCELERATOR IP GATEWAY
If the Xcelerator IP gateway is to be wall mounted, print a
copy of the wall mount template from the documentation CD
for use in lining up the screw mounts with the mounting holes
in the gateway. To mount the Xcelerator IP on a table or other
flat surface, insert the Xcelerator IP gateway unit into the
provided stand.
Next, mount the antenna to the threaded connection on the
upper side of the Xcelerator IP gateway chassis. Once
mounted, the antenna must be fully extended for proper
operation as depicted in the diagram.
POWER THE XCELERATOR IP GATEWAY
Once the Xcelerator IP has been mounted, attach the AC power adapter to the "Power In" connector on the interface
panel of the gateway. Plug the AC power adapter into a grounded 120VAC power source. Move the ON/OFF switch
to the ON position.
A blue LED above "Power" on the front of the Xcelerator IP will indicate the gateway is powered and ready to
continue with the installation of the unit.
STARTING TO USE THE XCELERATOR IP
On new installations, or if the system is defaulted, the Xcelerator IP will start with a configuration Wizard to assist
with the installation. Refer to the Administrator Guide for details on the programming of the Xcelerator IP.
All manuals and user guides at all-guides.com
UNPACKING THE BOX CONTENTS
You will need the following parts to complete the installation of your Xcelerator IP
XCELERATOR IP GATEWAY
Attach a PC or laptop to the Xcelerator IP via one of the Ethernet ports or via
a wireless connection.
Open your internet browser and type in 192.168.1.1. This is the default
address of the Xcelerator IP Admin interface. The default password is
"admin" and the default user name is "admin".
AC POWER ADAPTER
ANTENNA
GATEWAY STAND
Documentation
DOCUMENTATION CD
