In-Wall/Wall Plate Stereo Amplifier with Bluetooth/Aux(3.5mm) /
Microphone (1/4") Input, USB Charge & USB/ SD Card Reader
Specification
1.Rated Output Power.............................. ..... 2CHx30Watts( RMS, 8 Ohm)
Max Output Power.....................................2CHx100Watts(RMS, 8 Ohm)
2.Rated Input Level/Impedance
Audio Input.................................................................230mV/47Kohm
Microphone Input............................................................7mV/600Ohm
3.Tone Control
Bass F=100Hz..........................................................................+10dB
Treble F=10Khz........................................................................ +10dB
4.Separation
Master Channel .......................................................................≥45dB
5.Frequency Response
Master Channel F=20Hz-20KHz.................................................+1.5dB
6.Signal To Noise
Master Channel .......................................................................≥81dB
7.Speaker System
Master Channel ...............................................................4Ohm/8Ohm
8.Input Power ...................................................AC 110/60Hz; 230V/50Hz
9.Power Consumption.................................................................. 200W
10. Unit Size(WxHxD) Inch..........................................12.60"x2.95"x7.48"
11. Unit Weight..............................................................................8.8lb
TEL: 718.535.1800
1600 63RD STREET, BROOKLYN NY 11204
FAX: 718.236.2400
PT506BT
with Bluetooth
Stereo Powered Amplifier with Bluetooth/AUX (3.5mm)/
Micrphone (1/4") Input/FM Tuner/USB Charge & USB/SD
Card Reader
Advertisement
Related Manuals for Pyle PT506BT
Summary of Contents for Pyle PT506BT
- Page 1 7.Speaker System Master Channel ……………………………………………………...4Ohm/8Ohm 8.Input Power ………………………………….………..AC 110/60Hz; 230V/50Hz 9.Power Consumption…………………………………………………..……. 200W 10. Unit Size(WxHxD) Inch……………………………………12.60"x2.95"x7.48" 11. Unit Weight………………………………………………………….……..8.8lb PT506BT with Bluetooth Stereo Powered Amplifier with Bluetooth/AUX (3.5mm)/ Micrphone (1/4") Input/FM Tuner/USB Charge & USB/SD Card Reader TEL: 718.535.1800 FAX: 718.236.2400...
- Page 2 Input/FM Tuner/USB Charge & USB/SD Card Reader Features and Controls: Instruction Pyle's Bluetooth Stereo Amplifier is the perfect solution for all of your audio FRONT PANEL needs. Using the latest sound amplification technology and an impressive 200 Watt power output, this receiver is designed to deliver pure stereo sounds from a wide range of connected music sources.
- Page 3 Stereo Powered Amplifier with Bluetooth/AUX (3.5mm)/Micrphone (1/4") Stereo Powered Amplifier with Bluetooth/AUX (3.5mm)/Micrphone (1/4") Input/FM Tuner/USB Charge & USB/SD Card Reader Input/FM Tuner/USB Charge & USB/SD Card Reader Connection Diagram 6.MASTER ( L & R) Volume Control Separate Left and Right Channel Volume Control Let You Control the Level of Each Channel, and it doesn’t Affect the Volume of Microphone.
- Page 4 Stereo Powered Amplifier with Bluetooth/AUX (3.5mm)/Micrphone (1/4") Stereo Powered Amplifier with Bluetooth/AUX (3.5mm)/Micrphone (1/4") Input/FM Tuner/USB Charge & USB/SD Card Reader Input/FM Tuner/USB Charge & USB/SD Card Reader Features: Help & Troubleshooting •Compact Tabletop Stereo Amplifier Receiver If you experience any of the following difficulties while using the unit, use this •Built-in Bluetooth for Wireless Audio Streaming trouble shooting guide to help you remedy the problem, should any problem Compatible with All Your Favorite Bluetooth Devices (iPhones,...
