Run the Getting Started Wizard

3
To use your Digi TransPort WR41, you must first activate the device with your cellular carrier. This process involves supplying the carrier with the MEID number
a
from your device, which is printed on the label on the bottom of the router.
b If your PC is configured to automatically get an IP address, it can get an IP address from the TransPort WR41. Otherwise, make sure your PC can connect to the
network 192.168.1.0 (255.255.255.0).
c
open a web browser. Enter 192.168.1.1
On the PC,
The first page of the Getting Started Wizard is displayed. This wizard guides you through initial configuration for your TransPort device.
d
To run the wizard, click Get Started.
To manually configure the TransPort device, click Skip Wizard.

View the TransPort LEDs and startup states

4
POWER LED:
Off: No power
Green: TransPort device is powered
LAN LED: Illuminates steady when there is a network connection to the LAN port and flashes when data is transmitted or received.
WN LED:
Wi-Fi models: Illuminates steady if Wi-Fi activity is present.
Non-Wi-Fi models: Flashes to show which network mode the unit is operating in:
Off: No service
1 blink: GPRS mode
2 blinks: EDGE mode
3 blinks: UMTS mode
4 blinks: HSDPA mode
5 blinks: HSUPA mode
6 blinks: LTE mode
LINK LED: Illuminates steady when a wireless WAN data connection has been established.
SIM LED: Illuminates steady when a valid SIM card is installed.
ACT LED: Flashes to indicate that data is being transferred over the wireless WAN network.
SIGNAL LEDs: Indicate strength of cellular signal.
3 LEDs: Excellent
2 LEDs: Good
1 LED: Fair
0 LEDs: Poor or No signal
SERIAL LED: Illuminates steady if a terminal is connected to the SERIAL port and the DTR signal is on. Flashes when data is transmitted or received.
5

Next steps

After the Getting Started Wizard completes, the TransPort web interface is displayed. For additional configuration,
Digi TransPort Users Guide and Application Notes provided on the TransPort Documentation page on the Digi website (www.digi.com/support).
use the web interface and refer to the
