Summary of Contents for Oceanic ATOM 2.0

  • Page 1 CEANIC TOM 2.0 perating Manual (-r04 cover art to be placed on front/back is provided separately)

  • Page 2: Table Of Contents

    CONTENTS WARRANTY, NOTICES, DECOMPRESSION MODEL ....................7 INITIAL ACTIVATION ................................ 8 INTRODUCTION AND GENERAL FEATURES AND DISPLAYS ..................9 INTERACTIVE CONTROL CONSOLE ........................10 OPERATING MODE STRUCTURE ........................... 11 OPERATION AS A DIVE COMPUTER ........................12 PC INTERFACE ................................. 13 SYMBOLS AND ALPHA NUMERIC GRAPHICS ......................
  • Page 3 CONTENTS (continued) DIVE COMPUTER SURFACE SEQUENCE AND OPERATING MODES ..............39 SURFACE MODE ..............................40 Normal Surface Main Display ..........................41 Normal Surface Main Button Operations ......................43 ATOM Battery Status ............................44 Transmitter Status .............................. 45 Normal Surface Secondary Display ........................45 Normal Surface Alternate Display ........................
  • Page 4 CONTENTS (continued) Set TMT1 (Transmitter 1 Link Code) ........................70 Set TMT (Transmitter) 2-3 Use ..........................72 Set TMT2 (Transmitter 2 Link Code) ........................73 Set TMT3 (Transmitter 3 Link Code) ........................75 SERIAL NUMBER (ATOM) ............................77 NORM (Normal Dive) PLAN MODE ......................... 78 FLY MODE .................................
  • Page 5 CONTENTS (continued) SWITCHING GAS MIXES AND BUDDY PRESSURE CHECK ..................119 SWITCHING GAS MIXES (NORM ONLY) ......................120 BUDDY PRESSURE CHECK (NORM ONLY) ......................125 NORM POST DIVE MODES ............................129 TRANSITION PERIOD ............................130 AFTER THE TRANSITION PERIOD ........................131 GAUGE OPERATING MODE ............................

  • Page 6: Warranty, Notices, Decompression Model

    TRADEMARK, TRADE NAME, AND SERVICE MARK NOTICE Oceanic, the Oceanic logotype, the Oceanic 'O' symbol, ATOM, the ATOM 2.0 logo, Air Time Remaining (ATR), Diver Replaceable Batteries, Graphic Diver Interface, Tissue Loading Bar Graph (TLBG), Pre Dive Planning Sequence (PDPS), Set Point, Control Console, Turn Gas Alarm, and OceanLog are all registered and unregistered trademarks , trade names, and service marks of Oceanic.

  • Page 7: Initial Activation

    OTICE STORAGE and INITIAL ACTIVATION Beginning with firmware revision 2E, AT M Watch/Dive Computers are placed in a Deep Sleep mode prior to being shipped from the factory. The intent is to extend storage life of the Battery for up to 7 years, before the unit is initially placed in service.

  • Page 8: Introduction And General Features And Displays

    WARNING: Prior to diving with the ATOM 2.0, you must also read and understand the Oce- anic Dive Computer Safety and Reference Manual, Doc. No. 12-2262, which provides Important Warnings and Safety Recommenda- tions as well as general product information.

  • Page 9: Interactive Control Console

    NTRODUCT ON Welcome to CEANIC and thank you for choosing the AT M 2.0 ! It is extremely important that you read this perating Manual in sequence and understand it completely before attempting to use the AT M 2.0 as a dive computer. It is equally important that you read the ceanic Dive Computer Safety and Reference Manual (Doc.

  • Page 10: Operating Mode Structure

    Mode it is in. WARNING: When Wet Activation is set OFF, the ATOM 2.0 must be in Dive Surface Mode (NORM< GAUG, or FREE prior to the first dive of a new series. Commencing a dive while in Watch modes will not activate Dive Mode unless Wet Activation is set ON.

  • Page 11: Operation As A Dive Computer

    OPERATION AS A DIVE COMPUTER The AT M 2.0, hereafter referred to as the AT M, features 3 Dive Computer (DC) perating Modes, N RM (Fig. 2A) which is used for Air and Nitrox dives, GAUG (Fig. 2B) used for dives in which Nitrogen- xygen calculations are not performed, and FREE (Fig.

  • Page 12: Pc Interface

    PC INTERFACE Interface with a PC is accomplished by connecting the AT M to a PC USB Port using the USB Interface Cable provided. The same Cable is used for Upload and Download. The software program is on the CD provided, together with a USB Driver. The program's Help serves as the user manual and can be printed for personal use.

  • Page 13: Audible Alarm

    AUDIBLE ALARM Most warning situations that activate the Audible Alarm while operating in N RM or GAUG Mode cause the AT M to emit 1 beep per second for 10 seconds, or until the situation is corrected, or it is acknowledged by momentarily pressing and releasing the S button (less than 2 seconds).
  • Page 14  Tissue Loading Bar Graph at the segment Set Point selected.  N RM/GAUG Ascent Rate exceeds 60 FPM (18 MPM) when deeper than 60 FT (18 M), or 30 FPM (9 MPM) at 60 FT (18 M) and shallower. ...

  • Page 15: Backlight

    During the following N RM Dive situations, the 10 second continuous tone will be fol- lowed by a 5 second steady beep that will not turn off when acknowledged -  Ascending above a required Decompression Ceiling Stop Depth for more than 5 minutes (referred to as a Delayed Violation).
  • Page 16  If voltage of the AT M decreases to the Warning level (2.75 volts), the Battery icon will appear on Surface display screens (fig. 3a) as an indication that the Battery should be changed prior to commencing a series of dives. ...
  • Page 17 To check the condition of the AT M or a Transmitter's Battery if N RM or GAUG Mode is selected, depress the S button for 2 seconds while viewing the N RM, GAUG, or FREE Surface Main Display, then release it. ...

  • Page 18: Watch Features And Displays

    WARNING: Prior to diving with the ATOM, you must also read and understand the Oce- anic Dive Computer Safety and Reference Manual, Doc. No. 12-2262, which provides Important Warnings and Safety Recommenda- tions as well as general product information. WATCH FEATURES AND D SPLAYS...

  • Page 19: Local Default Time

    LOCAL DEFAULT TIME (Fig. 7) is the current Time at your home Watch Main Time location and is normally selected as the Local Default Time. The normal Watch screen sequence accessed with momentary presses (less than 2 seconds each) of the M button is - Main Time >...

  • Page 20: Main Time

    While viewing any of the Watch Mode displays, pressing and holding the M button for 2 seconds or if no button is pressed for 2 minutes, operation will revert to the Watch Time screen se- lected to be the Local Default Watch Time (Main or Alternate). information displayed includes: MAIN TIME, >...

  • Page 21: Set Main Time

    SET MAIN TIME This Mode allows the Date and Time of Day to be set which will also serve as the basis for ALTERNATE TIME values. There are 3 Time Set screens - Set Hour Format, Set Time of Day, and Set Date.
  • Page 22  Pressing and releasing the S button momentarily (< 2 seconds) will toggle the flashing setting between 12 and  Pressing the A button momentarily (< 2 seconds) will save the Hour Format Set Point and access the SET TIME screen with the H UR Set Point flashing (Fig.
  • Page 23 Displayed on the screen will be the graphic YEAR, SET DATE Month and Day (or Day and Month if set for metric) with the Set Point flashing (Fig. 13). YEAR  Depressing and holding the S button while the YEAR Set Point is flashing will scroll through the Set Points in 1 year increments at a rate of 4 per second from 2006 to 2049 (with leap year corrections).

  • Page 24: Alternate Time

     Depressing and holding the S button while the Point is flashing will scroll through the Set Points in one day Main Time/Date can also (01) increments at a rate of 4 per second from 1 to 31. be set using the PC Settings Upload program included on the ATOM's OceanLog ...

  • Page 25: Set Alternate Time

     Pressing and releasing the M button momentarily and repeatedly (< 2 seconds) will step through the other Main Watch Modes.  Pressing and releasing the S button (< 2 seconds) will silence and acknowledge the Daily Alarm (if its set and it sounds).

  • Page 26: Countdown Timer

     Depressing and holding the S button while the Set Point is flashing will scroll through the Set Points in increments of 1 Hour at a rate of 4 per second.  Pressing and releasing the A button momentarily (< 2 seconds) will save the Set Point and/or advance to the ALTERNATE TIME screen.

  • Page 27: Set Countdown Timer

    When a set Countdown Time reaches 0:00, the Audible Alarm will beep 10 times and the red LED warning light will flash.  Pressing and releasing the S button (< 2 seconds) will acknowledge and silence the Alarm.  Pressing and releasing the S button (< 2 seconds) will silence and acknowledge the Daily Alarm (if its set and it sounds).

  • Page 28: Chronograph

     Depressing and holding the S button while the MINUTES Set Point is flashing will scroll through the Set Points in 1 minute increments at a rate of 4 per second from :00 to :59 (min).  Pressing and releasing the A button momentarily (< 2 seconds) will save the MINUTES Set Point and/or advance to the C UNTD WN TIMER screen indicated by the graphic FF (flashing) in place of the graphic SEt.
  • Page 29  During the first 4 seconds the 1/100th second values will be displayed, then 2 dashes ( . - - ) will be displayed. The 1/100th values will be recorded and displayed when LAPs are frozen and when later recalled. ...

  • Page 30: Daily Alarm

    Upon descending on a dive, the Chronograph operation will be terminated and reset to 0:00:00.0. DAILY ALARM When set N, the DAILY ALARM will sound the Audible Alarm and flash the Red LED at the Time set every day.  Pressing the M button momentarily 4 times (< 2 seconds each time) while the MAIN TIME screen is displayed will access the DAILY ALARM STATUS screen.

  • Page 31: Set Daily Alarm

     If no button is pressed during a period of 2 minutes, the unit will revert to the Local Default Watch Time screen. , information provided includes (Fig. 24): SET DAILY ALARM > Alarm icon > Graphics ALRM and SEt. >...

  • Page 32: Dive Computer Features And Displays

    WARNING: Prior to diving with the ATOM, you must also read and understand the Oce- anic Dive Computer Safety and Reference Manual, Doc. No. 12-2262, which provides Important Warnings and Safety Recommenda- tions as well as general product information. D VE COMPUTER FEATURES AND D SPLAYS...

  • Page 33: Bar Graph

    BAR GRAPH The AT M features one shared Bar Graph that represents either nitrogen loading, or when accessed, oxygen accumulation. By default the Bar Graph (Fig. 25a), referred to as the Tissue Loading Bar Graph (TLBG), represents your relative no decom- pression or decompression status.
  • Page 34 Displays associated with oxygen and the 2 Bar Graph will be displayed if F 2 for any Gas (1, 2, or 3) has been set at a value other than 'Air' (e.g., a numerical value) and the Alternate screen that displays oxygen related data is accessed. When the oxygen data screen is accessed during a N RM dive, the Bar Graph will show the maximum of either per dive accumu- lated oxygen or 24 hour period accumulated oxygen.

  • Page 35: Alpha / Numeric Displays

    While you cannot provide a guarantee against the occurrence of decompression sickness, you may choose your own personal zone of caution based upon age, physique, excessive weight, etc., to reduce the statistical risk. Within the available N RM Mode parameters that can be set (described later) are a TLBG Alarm and a Conservative Factor which if set N reduces No Decompression times allowed.

  • Page 36: Time And Date Displays

    During a No Decompression Safety Stop, the set Stop Depth (Fig. 30a) is displayed and during a Decompression condition, the required is displayed. Ceiling Stop Depth Time and Date Displays Time of Day and NORM/GAUG Mode displays shown in hour:minute format (i.e., 1:16 represents 1 hour and 16 minutes, not 116 minutes!).

  • Page 37: Temperature Display

    Temperature Display can be viewed on the surface and Ambient Temperature during dives by accessing a Secondary Display (Fig. 32a). The lowest Temperature recorded during each N RM/GAUG dive is recorded in the L G for that dive. NOTE: Each display represents unique pieces of information.

  • Page 38: Dive Computer Surface Sequence And Operating Modes

    WARNING: Prior to diving with the ATOM, you must also read and understand the Oce- anic Dive Computer Safety and Reference Manual, Doc. No. 12-2262, which provides Important Warnings and Safety Recommenda- tions as well as general product information. D VE COMPUTER SURFACE SEQUENCE OPERAT NG MODES...

  • Page 39: Surface Mode

    DIVE COMPUTER (DC) OPERATING MODES As described on page 12, the AT M features 3 selectable DC perating Modes -  N RM - for Normal Air or Nitrox dives  GAUG - for dives with no Nitrogen/ xygen calculations ( nce a dive is made in GAUG Mode, the AT M is locked into that perating Dive Mode for 24 hours after the dive.

  • Page 40: Normal Surface Main Display

    If a dive has been conducted within the past 24 hours, the SURF MAIN screen for that perating Mode (N RM, GAUG, or FREE) will be displayed. At any time while operating in Surface Modes, the AT M will enter Dive Mode upon descent to 5 FT (1.5 M). ...
  • Page 41 When the 10 minute Surface Time has elapsed, the Local Default Watch TIME screen (Main or Alternate Time) will replace the Surface Mode display. The SURF MAIN screen can then be accessed by pressing the M button for 2 seconds. , information provided includes (Fig.

  • Page 42: Normal Surface Main Button Operations

    - Button perations: NORM SURF MAIN  Pressing the L button will activate the Backlight.  Pressing and releasing the A button repeatedly (< 2 seconds each time) will step through the N RM Surface Sequence - SURF > PLAN > FLY > SAT > L G > HIST RY. ...

  • Page 43: Atom Battery Status

     Depressing and holding the S button for 2 seconds while viewing the N RM Surface screen will activate the AT M's Receiver and access a series of screens that will indicate the Status of the system's Batteries and Pressures of the Tanks in use.

  • Page 44: Transmitter Status

    , information includes: TRANSMITTER STATUS > Graphics TMT1 (then TMT2 and TMT3), identifying the reporting Transmitter, and bAt. > Graphic Good or Lo, or NotAvAil (Fig. 38A/38B) > Battery icon, if a Low Battery Warning Condition exists. Flashing if an Alarm Condition exists. >...

  • Page 45: Normal Surface Alternate Display

    , information includes (Fig. 40): NORM SURF ALTERNATE > Bar Graph representing xygen accumulation with the 2BG icon. > LINK symbol, if the AT M's Receiver is successfully Linked with a Transmitter. > Altitude Level graphic SEA (or EL2 through EL7). >...

  • Page 46: Normal And Gauge Surface Set Modes

    NORM AND GAUG SURFACE SET MODES The AT M reverts to the last Settings NORM/GAUG Set Mode Sequence: entered/saved when SURF MAIN > SET F > SET A > SET U > AT M Serial Number. 24 hours elapse without a dive or Access and step through of the sequence is gained by repeated after a dive.

  • Page 47: Set Fo2 For Norm Nitrox Dives

    Setting FO2 for NORM Nitrox Dives: For each value of F 2, the Maximum perating Depth (M D) that can be achieved for the P 2 Alarm Set Point limit previously set, will be displayed. When the F 2 50% DEFAULT is set N and F 2 GAS 1 is set for a numerical value, 10 minutes on the surface after that dive, the F 2 for GAS 1 will be displayed as 50 and further dives will be calculated based on 50% 2 for oxygen calculations and 21% 2 for Nitrogen calculations (79% Nitrogen) unless the F 2 for GAS 1 is set before the dive.
  • Page 48 Maximum perating Depths affected by the P 2 limit set will not be displayed when F 2 for GAS 1 is set to AIR. Internally, the AT M keeps track of the oxygen loading so that if F 2 for GAS 1 is subsequently set for a numerical value, the oxygen loading for previous AIR dives will be accounted for in the next Nitrox dive (during that dive period and series of repetitive dives).

  • Page 49: Set Fo2 Gas 1

    information includes: SET FO2 GAS 1, > Graphic GAS1 > P 2 Alarm Set Point with graphic P 2 > Symbol F 2 and F 2 Set Point value, flashing > Tank 1 icon representing GAS 1 > Symbol NITR X (if set for a numerical value). >...

  • Page 50: Set Fo2 Gas 2

     Depressing and holding the M button for 2 seconds or if no button is pressed for a period of 2 minutes operation will revert to the N RM or GAUG SURF MAIN screen. information includes: SET FO2 GAS 2, >...

  • Page 51: Set Fo2 Gas 3

     Pressing and releasing the A button momentarily and repeatedly (< 2 seconds) will step through the other SET F screens.  Depressing the A and S buttons simultaneously for 2 seconds will save the setting and revert back to the SET F screen.

  • Page 52: Set Fo2 50% Default

     Depressing and holding the S button will resume the scroll through 100%, then stop at AIR (or 21 or the GAS2 setting).  Pressing and releasing the S button (< 2 seconds) will advance F 2 in increments of 1% per press of the button. ...

  • Page 53: Set A Group (Norm/Gaug Alarms)

     Pressing and releasing the A button momentarily (< 2 seconds) will save the setting and revert to the SET F screen.  Pressing and releasing the A button momentarily and repeatedly (< 2 seconds) will step through the other SET F screens.

  • Page 54: Set Audible Alarm

    SET AUDIBLE ALARM This option allows the Audible Alarms and the associated red warning LED function to be disabled. Some cautionary situations will cause the Audible alarm to sound and the LED to flash even if this feature is set to FF. information includes (Fig.

  • Page 55: Set Depth Alarm

    information includes (Fig. 49): SET DEPTH ALARM > Graphic DPTH > Symbols MAX and FT (or M) > Set Point graphic value, flashing.  Pressing and releasing the S button momentarily (< 2 seconds) will step through the Set Points from 30 to 330 FT (10 to 100 M) in 10 FT (1 M) increments at a rate of 1 Set Point per press of the button.

  • Page 56: Set Edt (Elapsed Dive Time) Alarm

    SET EDT (ELAPSED DIVE TIME) ALARM Information includes (Fig. 50): > Graphic EDT > Symbols DIVE and TIME. > Set Point value (hr:min), flashing.  Pressing and releasing the S button momentarily (< 2 seconds) will increase the Set Point from 0:10 to 3:00 (hours:minutes) in 5 minute (:05) increments.

  • Page 57: Set Tlbg (Tissue Loading Bar Graph) Alarm

    SET TLBG (TISSUE LOADING BAR GRAPH) ALARM Setting the TLBG Information includes (Fig. 51): Alarm to activate > Graphic TLBG before the AT M > TLBG Set Point (segments), flashing. enters DEC is highly recommended.  Pressing and releasing the S button momentarily (< 2 seconds) will decrease the Set Point from All 5 segments (Deco) to 1 in increments of 1 segment.

  • Page 58: Set Dtr (Dive Time Remaining) Alarm

    SET DTR (DIVE TIME REMAINING) ALARM Whichever Time (No Information includes (Fig. 52): Decompression, 2, > Graphic DTR or Air Time Remain- > Symbols AIR, TIME, NDC, and 2. ing) decreases to the > Set Point value, flashing. Alarm Set Point will activate the Alarm.

  • Page 59: Set Turn Pressure Alarm (Tmt1)

    (for Transmitter 1 only) SET TURN PRESSURE ALARM The TURN Pressure Information includes (Fig. 53): Alarm only applies > Graphic TURN to TMT 1. > Set Point FF or a numeric value, flashing. > Symbol PSI (or M)  Pressing and releasing the S button momentarily (< 2 seconds) will step through the Set Points from FF to 1000 to 3000 PSI (70 to 205 BAR) in 250 PSI (5 BAR) increments.

  • Page 60: Set End Pressure Alarm

    information includes (Fig. 54): SET END PRESSURE ALARM The END Pressure > Graphic END Alarm will activate > Set Point numeric value, flashing. when Pressure in the > Symbol PSI (or M) Tank being used at the time (TMT 1, 2 , ...

  • Page 61: Set Po2 Alarm

    information includes (Fig. 55): SET PO2 ALARM Setting the P 2 > Graphics P 2 and AtA Alarm to activate > Set Point value, flashing. before reaching the > Symbol MAX Max allowed limit of 1.60 ATA is highly  Pressing and releasing the S button momentarily (< 2 recommended.

  • Page 62: Set U Group (Utilities)

    SET U GROUP (UTILITIES) TMT is the abbrevia- tion for Transmitter. Set U Sequence: BUD is the abbrevia- SET U > Wet Activation > Units > Safety Stop > Conservative tion for Buddy. Factor > Backlight Duration > Sampling Rate > TMT 1 > TMT 2-3 USE >...

  • Page 63: Set Wet Activation

    information includes (Fig. 57): SET WET ACTIVATION Prior to the first dive > Graphic WET of a repetitive > Set Point graphic N (or FF) flashing. series, WET Activa- tion must be set N  Pressing and releasing the S button will toggle between N for the AT M to and FF.

  • Page 64: Set Units Of Measure

    information includes (Fig. 58): SET UNITS UNITS set will apply > Graphic UNIT to N RM, GAUG, > Set Point symbols/graphics PSI, F, and FT (or BAR, C, and and FREE Modes. M), flashing.  Pressing and releasing the S button will toggle between Imperial (F, FT, PSI) and Metric (C, M, BAR).

  • Page 65: Set Norm Safety Stop

    information includes (Fig. 59): SET NORM SAFETY STOP Refer to page 106 > Graphic SAFE for a description of > Symbols ST P and TIME. the No Decompres- > Safety Stop Time Set Point, flashing. sion dive mode Safety Stop feature. >...

  • Page 66: Set Conservative Factor

     Depressing and holding the M button for 2 seconds or if no Use the Conserva- button is pressed for a period of 2 minutes operation will tive Factor option to revert to the N RM or GAUG SURF MAIN screen. help reduce your exposure to Decom- information includes (Fig.

  • Page 67: Set Backlight Duration

    NOTE: When the Conservative Factor is set ON, The Backlight will the No Deco Limit times are reduced to values not remain n for equivalent to those that would be available at the additional the next higher 000 foot (915 meter) Altitude. Duration time set if Refer to the tables on Pages 166/167.

  • Page 68: Set Sampling Rate

    HINT: To change the Duration while operating in SAMPLING RATE is FREE Mode, first access the NORM SURF Mode. the frequency (time interval) at which information includes (Fig. 62): SET SAMPLING RATE data is sampled and > Graphic SAMP stored in memory for >...

  • Page 69: Set Tmt1 (Transmitter 1 Link Code)

    information includes (Fig. 63): SET TMT 1 TMT 1 is the Default > Graphics TMT1 and N (or FF) flashing. Transmitter while on > Set Point (Transmitter's Serial Number (Link Code). the Surface, prior to a dive and 10  Pressing and releasing the S button momentarily (< 2 minutes after a dive.
  • Page 70  Pressing and releasing the S button momentarily and repeatedly (< 2 seconds each time) will increase the Third Digit from 0 to 9 in increments of 1.  Depressing and holding the S button will scroll through the Set Points at a rate of 4 per second.

  • Page 71: Set Tmt (Transmitter) 2-3 Use

    information includes (Fig. 64): SET TMT 2- USE > Graphics TMT and 2-3 USE. > Set Point graphic SELF (or bud) flashing.  Pressing and releasing the S button momentarily (< 2 seconds) will toggle between SELF and bud.  Pressing and releasing the A button momentarily (< 2 seconds) will accept the setting and/or advance to SET TMT 2 (or BUD 1) with N or FF flashing.

  • Page 72: Set Tmt2 (Transmitter 2 Link Code)

    information includes (Fig. 65): SET TMT 2 (or BUD 1) > Graphics TMT2 (or BUD1) and N (or FF) flashing. > Set Point (Transmitter's Serial Number (Link Code)).  Pressing and releasing the S button momentarily (< 2 seconds) will toggle between N and FF. ...
  • Page 73  Pressing and releasing the S button momentarily and repeatedly (< 2 seconds each time) will increase the Third Digit from 0 to 9 in increments of 1.  Depressing and holding the S button will scroll through the Set Points at a rate of 4 per second.

  • Page 74: Set Tmt3 (Transmitter 3 Link Code)

    information includes (Fig. 66): SET TMT (or BUD 2) > Graphics TMT3 (or BUD2), and N (or FF) flashing. > Set Point (Transmitter's Serial Number (Link Code)).  Pressing and releasing the S button momentarily (< 2 seconds) will toggle between N and FF. ...
  • Page 75  Pressing and releasing the S button momentarily and repeatedly (< 2 seconds each time) will increase the Third Digit from 0 to 9 in increments of 1.  Depressing and holding the S button will scroll through the Set Points at a rate of 4 per second.

  • Page 76: Serial Number (Atom)

    N RM SURF MAIN screen. NOTE: The Serial Number and Firmware Revi- sion will be requested in the event that you contact Oceanic regarding the ATOM. Enter them in the Records section provided in the back of this Manual.

  • Page 77: Norm (Normal Dive) Plan Mode

    NORM PLAN MODE Oceanic strongly recommends that you review the Pre Dive Planning Se- quence (PDPS) prior to every NORM dive to help you Plan your dive as required to avoid exceeding no decompression or oxygen exposure limits. This is especially important for repetitive dives when the PDPS indicates adjusted dive times that are available for the next dive, based on residual nitrogen or oxygen accumulation (whichever is in control) following the last dive and surface interval.
  • Page 78 NOTE: When the Conservative Factor is set ON, DEPTH No Decompression Dive times are reduced to the HR:MIN values of the next 000 foot (915 meter) higher 4:20 (4:43) (12) 2:17 (2:24) Altitude. (15) 1:21 (1:25) (18) (:59) If F 2 for GAS1 is set for a numerical value (21 to 50%), the (21) (:41) NITR X graphic and Maximum perating Depth defined by the...
  • Page 79 information includes (Fig. 68): PLAN MODE LEAD-IN > Graphic PLAN. > P 2 Alarm Set Point and graphic P 2, if set for Nitrox. > F 2 icon and F 2 Set Point for GAS 1. > Tank 1 icon representing GAS 1. >...

  • Page 80: Fly Mode

    FLY MODE Time to Fly is not a Time to Fly is a counter that begins counting down 10 minutes calculation, it is a after surfacing from a dive from 23:50 to 0:00 (hr:min). 24 hour countdown timer provided for Two hours after a dive, the AT M's operation reverts to the your post dive Watch Local Time screen (Main or Alternate, whichever one was...

  • Page 81: Sat Mode (Norm)

     Pressing and releasing the A button momentarily (< 2 seconds) will advance to SAT M DE.  Depressing and holding the M button for 2 seconds will revert to the N RM SURF MAIN screen.  If no button is pressed during a 2 minute period, operation will revert to the N RM SURF MAIN screen.

  • Page 82: Norm/Gaug Log Mode

     Depressing and releasing the A button momentarily and Time to Desaturate repeatedly 3 times (< 2 seconds each time) while viewing is a calculation the N RM SURF MAIN screen will access SAT M DE. based upon calcu- (N RM SURF > PLAN > FLY > SAT) lated residual nitrogen.
  • Page 83 After exceeding 24 dives, the most recent Dive completed will be added to the L G and the oldest deleted. Dives will be numbered 1 to 24 starting at #1 each time a new series of dives begins. After it shuts ff 24 hours after a dive, the first dive of the next new series will be #1. ...
  • Page 84  If that was a Nitrox dive, pressing and releasing the S FREE Dives are not button again will display that dive’s L G DATA 2 screen recorded in the L G, ( xygen Data). If in GAUGE M DE (Violated or User they are stored in Selected), this screen will not be displayed.
  • Page 85 information includes (Fig. 73): LOG DATA 1 > Alpha graphic N -D, DEC , GAUG, or VI L. > TLBG with the maximum accumulation segment flashing, others fixed up to end-of-dive accumulation. All segments flashing for delayed and full violation. >...

  • Page 86: History Mode (Norm/Gaug)

    (if a Nitrox dive) information includes (Fig. 74): LOG DATA 2 > Graphic 2. > 2 bar graph segments representing xygen accumulated at the end of the dive and symbol 2BG. > Value of Max P 2 achieved (ATA) and graphic P 2. >...
  • Page 87  10 minutes after a Non Violation Dive, pressing and releasing the A button momentarily and repeatedly 5 times (< 2 seconds each time) while the N RM SURF MAIN screen is displayed will access the HIST RY M DE (N RM SURF >...
  • Page 88 screen information includes (Fig. 76): HISTORY 2 > Graphic SEA (or EL 2 through EL 7), Altitude conducted. > Temperature, lowest recorded of all dives. > Maximum Depth achieved during all dives with symbols FT (or M) and MAX.  Pressing and releasing the S button momentarily (< 2 seconds) button will advance to the N RM SURF MAIN screen.
  • Page 89 OVERVIEW OF DISPLAYED SYMBOLS AND ICONS SY BOLS EANING BAR (or) PSI Selected Tank's Pressure Units STOP TI E (or) DIVE TI E Ceiling Stop Time or Elapsed Dive Time (hr:min) or Dive # AIR TI E (or) - Air Time Remaining (hr:min) TI E NDC (or) - No Decompression Dive Time Remaining (hr:min) TI E O2 (or) -...

  • Page 90: Overview Of Dive Mode Information

    WARNING: Prior to diving with the ATOM, you must also read and understand the Oce- anic Dive Computer Safety and Reference Manual, Doc. No. 12-2262, which provides Important Warnings and Safety Recommenda- tions as well as general product information. OVERV EW OF D VE MODE NFORMAT ON...
  • Page 91 Poor Reception Distance (greater than 6 feet/2 meters) Best Reception Area Poor Poor Reception Reception Area Area Poor Poor Reception Reception Area Area Transmitter Signal Reception Guide...

  • Page 92: Positioning Of The Atom

    POSITIONING OF THE ATOM The Transmitters (TMTs) emit low frequency signals that radiate outward in semicircular patterns that are parallel to the length dimension of the TMT. A coiled antenna inside the AT M receives the signals when it is positioned within a zone parallel to or at a 45 degree angle to the TMT as illustrated on page 92.

  • Page 93: Dive Time Remaining (Dtr)

    An interruption of the TMT Link may also occur while the AT M is in an area within 3 to 4 feet (1 meter) of a running Dive Propulsion Vehicle. The Link will be restored within 4 seconds after the Vehicle is shut off or the AT M is moved out of that area.

  • Page 94: No Decompression Dive Time Remaining (Ndc)

    No Decompression Dive Time Remaining (NDC) No Decompression Dive Time Remaining is the maximum amount of time that you can stay at your present Depth before entering a Decompression situation. It is calculated based on the amount of Nitrogen absorbed by hypothetical tissue compart- ments.

  • Page 95: Oxygen Accumulation Time Remaining (Otr)

    Oxygen Accumulation Time Remaining (OTR) When the AT M is set for Nitrox operation, xygen Accumula- tion (saturation or exposure) during a dive, or 24 hour period, appears graphically as the 2 Bar Graph (Fig. 80a) when the Alternate #2 ( 2) screen is accessed. As time remaining before reaching the xygen Exposure Limit decreases, segments are added to the 2 Bar Graph.

  • Page 96: Air Time Remaining Alarm

    Air Consumption and Depth are continuously monitored and Air Time Remaining reflects any change in circumstances. For example, when a buddy starts breathing from your ctopus or you suddenly find yourself swimming against a strong current and begin breathing more rapidly, the AT M will recognize the change and adjust the Air Time Remaining accordingly.

  • Page 97: Variable Ascent Rate

    You should immediately initiate a controlled Ascent while moni- toring your Tank Pressure. However, there is no reason to panic, the AT M has allowed for the Air necessary for a safe Ascent including the No Deco Safety Stop, if set n, and any Decompression Stops required.

  • Page 98: Elapsed Dive Time

    At 60 FT (18 M) and shallower, the Warning will be given when Ascent Rates exceed 25 FPM (7.5 MPM). Ascent Rate Alarm At depths deeper than 60 FT (18 M), an Alarm will sound when Ascent Rates exceed 60 FPM (20 MPM).
  • Page 99  Dive Main > Alternate 1 (ATR) > Alternate 2 ( 2 Data, if set for Nitrox) A Secondary Display can be accessed by pressing the button for 2 seconds. It will also automatically revert to the Dive Main Display after 5 seconds. ...

  • Page 100: Norm Type Dive Modes (Air/Nitrox)

    WARNING: Prior to diving with the ATOM, you must also read and understand the Oce- anic Dive Computer Safety and Reference Manual, Doc. No. 12-2262, which provides Important Warnings and Safety Recommenda- tions as well as general product information. NORM TYPE D VE MODES...

  • Page 101: Wet Contacts

    WET CONTACTS The Wet Contact Dive Mode Activation feature is active any time WET ACTIVATI N is set N. The AT M is configured with contacts that will automatically activate Dive Mode when the space between the contacts is bridged by a conductive material (immersed in water) and it senses a Depth of 5 FT (1.5 M).

  • Page 102: Norm No Decompression Dive Mode

    NORM NO DECOMPRESSION DIVE MODE When the Wet Activation feature is set N, the AT M will enter WARNING: The the N RM No Decompression Dive Mode any time you de- Wet Activation feature will not scend to 5 FT (1.5 M). function unless it is Set ON (a user When the Wet Activation feature is set FF, the AT M will not...
  • Page 103  While the N RM DIVE MAIN screen is displayed, press/ During the time that an release the A button (< 2 sec) to view N RM DIVE ALT 1. Alarm is sounding,  While the N RM DIVE ALT 1 screen is displayed, press/ Alternate, Secondary, release the A button (<...
  • Page 104 (if set for Nitrox), NORM DIVE NO DECO ALT 2 DISPLAY Information includes (Fig. 89) - > 2 Bar Graph and symbol 2BG ( 2 accumulated) > TMT Link icon, if a TMT is active and linked > Graphic GAS1 (or 2 or 3) >...

  • Page 105: Norm Dive No Deco Safety Stop

    NORM DIVE NO DECO SAFETY STOP Upon ascending to 5 FT (1.5 M) below the Safety Stop Depth set on any No Decompres- sion dive in which Depth exceeded 30 FT (9 M), a short beep will be emitted and a Safety Stop at the Depth set will appear on the display with a countdown timer that begins at the Safety Stop Time set and counts down to 0:00 (min:sec).

  • Page 106: Decompression Dive Mode

     Press/release the A button to view the N RM MAIN and ALT Displays  Press/hold the A button (2 sec) to view Temperature/Time  Press/release the L button to activate the Backlight  Press/release the S button to acknowledge/silence Alarms DECOMPRESSION DIVE MODE The AT M is designed to help you by providing a representa- tion of how close you are to entering Decompression.
  • Page 107  nce you are within 10 FT (3 M) of, and below, the Required Stop Depth, the UP Arrow will be removed. At any time during the dive -  Depress the L button to activate the Backlight.  Press/release the S button to acknowledge/silence Alarms. ...
  • Page 108 DECO STOP MAIN Display (Default), information provided includes (Fig. 94) - > Tissue Loading Bar Graph (all segments indicating DEC ) > Graphic message DEC > ST P > xxF or xxM, scrolling > TMT Link icon and Tank Pressure with the PSI (or BAR) icon, if a TMT is active and linked >...
  • Page 109 information includes (Fig. 95) - DECO STOP ALT 1 DISPLAY, > Tissue Loading Bar Graph (all segments) > Graphic TMT1 (or 2 or 3), Link icon, and Tank Pressure with the PSI (or BAR) icon, if a TMT is active and linked >...

  • Page 110: Violation Modes

    information includes (Fig. 97)- DECO SECONDARY DISPLAY, > Day of the Week graphic (M N, TUE, etc.) > Temperature with icon and graphic F (or C) > Time of Day (hr:min:sec)  This will be the Default Watch Time (Main or Alternate). ...
  • Page 111 If you descend below the required Decompression Ceiling before 5 minutes have elapsed, the AT M will continue to function in Decompression Dive Mode. In this case, no off gassing Credit will be given, and for each minute above the Ceiling 1 minutes of will be added to Required Stop Time.
  • Page 112 (Fig. 100) DELAYED VIOLATION #2 The AT M cannot calculate Decompression times for Stop Depths much greater than 60 FT (18 M) and offers no indication of how much time spent underwater would result in the need for a greater Stop Depth. If the Decompression obligation requires a Ceiling Stop Depth between 60 FT (18 M) and 70 FT (21 M), the TLBG will flash and the graphic message DEC >...
  • Page 113 Upon ascending above 330 FT (100 M), the Current Depth display will be restored, however Max Depth will only display 3 dashes for the remainder of that dive. Also, the Log for that dive will display 3 dashes as the Max Depth achieved. IMMEDIATE VIOLATION AND VIOLA GAUGE MODE If a Decompression Ceiling Stop Depth much greater than 60 FT (18 M) is required, an Immediate Violation Mode will be entered.
  • Page 114 The AT M will also enter an Immediate Violation Mode (Viola- tion Gauge Mode) 5 minutes surfacing from a dive in which a Delayed Violation occurred. does not allow Violation Gauge Mode on the Surface access to the SET F, PLAN, FLY, and SAT features/screens. The countdown timer that appears when you try to access Time to Fly does not represent Time to Fly.

  • Page 115: High Po2

    HIGH PO2 When partial pressure of oxygen (P 2) becomes equal to, or f a High PO2 greater than, 0.2 ATA less than the P 2 Alarm Set Point (a SET condition occurs A Group setting); the red LED warning light will flash, the Au- while in Deco dible Alarm will sound, and the message HIGH >...

  • Page 116: High Oxygen Accumulation

    HIGH OXYGEN ACCUMULATION Refer to page 167 for The 2 Bar Graph displays either oxygen accumulated during a Chart of NOAA that nitrox dive, or during the repetitive nitrox dives you conduct Oxygen Exposure during that 24 hour period, whichever of the two is greater at Limits.

  • Page 117: Summary Of Warning And Alarm Messages

    SUMMARY OF NORM/GAUG WARNING AND ALARM MESSAGES MESSAGE MEANING DEC > ST P > xxF (M) Entry into Decompression Mode. D WN > T > xxF (M) Above a Required Decompression Stop Depth. DEC > ST P > 60F (18M) Deco Stop greater than 60 FT (18 M) required. HIGH >...

  • Page 118: Switching Gas Mixes And Buddy Pressure Check

    WARNING: Prior to diving with the ATOM, you must also read and understand the Oce- anic Dive Computer Safety and Reference Manual, Doc. No. 12-2262, which provides Important Warnings and Safety Recommenda- tions as well as general product information. SW TCH NG GAS M XES BUDDY PRESSURE CHECK...

  • Page 119: Switching Gas Mixes (Norm Only)

    SWITCHING GAS MIXES (NORM only) During N RM Dives, the AT M can be manually switched from GAS 1 to GAS 2 to GAS 3, changing F 2 displays and calculations from the F 2 value set for GAS 1 to the F 2 value set for GAS 2 to the F 2 value set for GAS 3, and if TMTs (Transmitters) are used, changing Pressure related displays and calculations from TMT 1 to TMT 2 to TMT 3.
  • Page 120 Due to the possibility that sufficient air may not be available in When a switch is the Switch From tank to complete the dive, the Switch to the made to another prohibitive Mix can still be made. If the Switch is made to the GAS, there may be prohibitive Mix while in N RM N DEC DIVE Mode, the a delay of 5 to 15...
  • Page 121 GAS 1 SWITCH PREVIEW DISPLAY Information includes (Fig. 108) - > TLBG, representing Nitrogen Loading. > Graphic GAS1 > F 2 Set Point for GAS 1 and the symbol F 2 > Tank icon representing GAS 1 > Symbol NITR X >...
  • Page 122 TO SWITCH FO2 FROM GAS 1 TO GAS 2 If the ATO is not  Depressing the M button for 2 seconds while viewing the Switched to the new GAS 2 Switch Preview Display will manually Switch the Gas being breathed, AT M's F 2 from GAS 1 to GAS 2 and the AT M's Air Time Remaining Receiver from TMT 1 to TMT 2 (if active).
  • Page 123 GAS SWITCH PREVIEW DISPLAY Information includes (Fig. 111) - > TLBG, representing Nitrogen Loading. > Graphic GAS3 > F 2 Set Point for GAS 3 and the symbol F 2 > Tank icon representing GAS 3 > Symbol NITR X >...

  • Page 124: Buddy Pressure Check (Norm Only)

    BUDDY PRESSURE CHECK (NORM only) During N RM Dives, the AT M can be used to check (display) Tank Pressure of 1 or 2 buddies whose TMT Link Codes (Serial Numbers) have been entered as TMT 2 and TMT 3 in the AT M's SET U menu.
  • Page 125  Pressing and releasing the M button momentarily (< 2 seconds) while the TMT 2-3 USE screen is displayed (with the setting BUD) will start a Search for BUDDY 1 (TMT 2) displaying the graphics BUD and SEArCH (Fig. 113) for a maximum of 5 seconds.
  • Page 126 TO BUDDY PRESSURE CHECK ON SURFACE A Buddy Pressure Check can be performed when on the Surface by accessing the TMT Status Check screens while the N RM SURF MAIN screen is being displayed.  Depressing and holding the S button for 2 seconds will activate the AT M's Receiver and access the TMT Status screens and Pressures of the Tanks reporting.
  • Page 127 TMT 2-3 USE TMT 2-3 USE NORM DIVE << or >> Set for SELF Set for BUD MAIN 2 sec < 2 sec < 2 sec Switches from GAS 1 Gas 3/TMT 3 to Gas 1/TMT 1 2 sec PREVIEW SEARCH SWITCHING (after 3 sec)

  • Page 128: Norm Post Dive Modes

    WARNING: Prior to diving with the ATOM, you must also read and understand the Oce- anic Dive Computer Safety and Reference Manual, Doc. No. 12-2262, which provides Important Warnings and Safety Recommenda- tions as well as general product information. NORM POST D VE MODES...

  • Page 129: Transition Period

    POST DIVE SURFACE MODE When you ascend to 4 FT (0.6 M), the AT M will enter Surface Mode and begin counting your Surface Interval. TRANSITION PERIOD If you descend during the first 10 minutes after surfacing (re- ferred to as the Transition Period), time underwater will be considered a continuation of that dive.

  • Page 130: After The Transition Period

    To view that dive's Log during the Transition Period  Press and release the A button (< 2 seconds) to access the Preview screen (Fig. 120).  Press the S button to view the Log 1 screen (Nitrogen data).  Press the S button again to view the Log 2 screen ( xygen data), if a Nitrox dive.
  • Page 131 To activate the Backlight  Press the L button at any time. (refer to page 78) - To access NORM PLAN Mode  Press the A button 1 time while N RM SURF MAIN is displayed. The Planning Sequence now displays adjusted No Decompression Limits based on residual nitrogen and accumulated oxygen calculated to be remaining from the previous dives.

  • Page 132: Gauge Operating Mode

    WARNING: Prior to diving with the ATOM, you must also read and understand the Oce- anic Dive Computer Safety and Reference Manual, Doc. No. 12-2262, which provides Important Warnings and Safety Recommenda- tions as well as general product information. GAUGE OPERAT NG MODE...

  • Page 133: Gaug Surface Displays

    GAUGE MODE When Gauge Mode (GAUG) is selected as the perating Mode, the AT M will operate as a Digital Depth Gauge/Timer without performing nitrogen and oxygen calculations.  To access GAUG perating Mode while Watch MAIN TIME is displayed, press the M button 2 times (2 seconds each time), or while the N RM SURF MAIN screen is displayed, press the M button 1 time for 2 seconds.

  • Page 134: Gaug Dive Displays

     Press/release the A button to access Fly, Log, and History. GAS 1 and T T 1 are  Press/hold the A button for 2 seconds to view the common the Defaults for GAUG Secondary Display (Temperature and Time of Day). ode, GAS 2/3 and ...
  • Page 135  Press/release the A button to access the GAUG ALT display.  Press/hold the A button for 2 seconds to view the common Secondary screen (Temperature and Time of Day) for 5 seconds.  Press/release the S button acknowledge/silence Alarms. ...

  • Page 136: Free Dive Operating Mode

    WARNING: Prior to diving with the ATOM, you must also read and understand the Oce- anic Dive Computer Safety and Reference Manual, Doc. No. 12-2262, which provides Important Warnings and Safety Recommenda- tions as well as general product information. FREE D VE OPERAT NG MODE...

  • Page 137: Free Surface Displays

    FREE DIVE MODE When FREE (Free Dive Mode) is selected as the perating Mode, the AT M will operate as a Digital Depth Gauge with select features. Nitrogen loading is calculated based upon a default F 2 of AIR and the amount remaining during 24 hours is carried over between FREE and N RM perating Modes.
  • Page 138  Press the L button to activate the Backlight. FREE Mode uses the  Depress the A button for 2 seconds to access the common N RM/GAUG Secondary screen (Temperature and Time of Day) for 3 settings for - seconds then the FREE SURF ALT Display for 3 seconds. ...

  • Page 139: Free Countdown Timer (Cdt)

     Press the L button to activate the Backlight. The display will revert to the FREE SURF MAIN screen after 5 seconds or if the A button is pressed momentarily. FREE MODE COUNTDOWN TIMER (CDT) Pressing the A button momentarily (< 2 seconds) while viewing the FREE SURF MAIN screen will access the FREE SURF CDT STATUS screen.
  • Page 140  An N/ FF toggle is prevented when S is operated to The Set Point for the acknowledge/silence the Daily Alarm. Watch CDT does  Press the L button to activate the Backlight. not affect the FREE  Pressing the A button momentarily (< 2 sec), or depressing CDT.

  • Page 141: Set Free Cdt

    SET FREE CDT STATUS DISPLAY (SURFACE ONLY), information includes (Fig. 129) - > Graphics TIMR and SEt, solid. > TIME symbol and Timer setting (min:sec), colon solid, MINUTE Set Point flashing.  Depressing and holding the S button while the MINUTE Set Point is flashing will scroll through the Set Points at a rate of 4 per second from 0: to 59: in 1 Minute (1:) increments.

  • Page 142: Set Free Alarms (Edt, Fda)

    FREE DIVE EDT (ELAPSED DIVE TIME) ALARM The FREE EDT Alarm is factory set for 30 seconds. When set N, the Alarm will sound 3 short beeps and the message TIME will be displayed momentarily every 30 seconds while the AT M is operating underwater in FREE DIVE Mode. ...
  • Page 143 FREE DIVE DEPTH ALARMS (FDA) The Set Point for the The AT M features 3 FREE Dive DEPTH Alarms that can be Set N RM/GAUG at progressively deeper Depths and turned FF/ N. Depth Alarm does not affect the FREE >...
  • Page 144 SET FREE DEPTH ALARM 1 (FDA1) DISPLAY, information includes (Fig. 132) - > Graphic FDA1. > Set Point N or FF, flashing. > Depth Set Point graphic value, flashing if N is displayed. > Symbols MAX and FT (or M). ...
  • Page 145 SET FREE DEPTH ALARM 2 (FDA2) DISPLAY, The range of avail- information includes (Fig. 133) - able FDA 2 Set > Graphic FDA2. Points begins at the > Set Point N or FF, flashing. next FT/M value > Depth Set Point graphic value, flashing if N is displayed. greater than the >...
  • Page 146 SET FREE DEPTH ALARM (FDA ) DISPLAY, The range of avail- information includes (Fig. 134) - able FDA 3 Set > Graphic FDA3. Points begins at the > Set Point N or FF, flashing. > Depth Set Point graphic value, flashing if N is displayed. next FT/M value greater than the >...

  • Page 147: Free Dive Displays

    FREE DIVE MAIN DISPLAY (DEFAULT), information includes (Fig. 135) - > Graphic FREE > TLBG, if any Nitrogen remaining from previous N RM or FREE Dives conducted within the previous 24 hours. > Temperature with degrees symbol and graphic F (or C) >...
  • Page 148  Pressing and releasing the S button momentarily (< 2 seconds) will toggle between N and FF. If a Time has been set, a toggle from FF to N will start the CD TIMER indicated by the colon flashing (Fig. 137). ...
  • Page 149 FREE DIVE DEPTH ALARM(S) When Depth reaches the FREE DEPTH ALARM 1 Set Point selected, 3 short beeps will sound 3 times, the red LED will flash, and the message DPTH will appear on the display 3 times momentarily (Fig. 139), then revert to the message FREE. The beeps and message will be repeated when Depth reaches the FREE DEPTH ALARM 2 and 3 Set Points selected, if set N.
  • Page 150 When Nitrogen Loading increases to the Caution level indicated by 4 segments displayed as the TLBG and the UP Arrow appear- ing solid, 3 short beeps will sound 3 times, the red LED will flash, and the message UP > HIGH > NI will appear on the display (Fig.
  • Page 151 ADDITIONAL INFORMATION PERTAINING TO FREE DIVE MODE Although breathing apparatus is not utilized for FREE Dive activities, nitrogen tissue loading remains a factor. Nitrogen loading is calculated based upon a fixed FO2 of AIR. Since a user has the option of alternating between NOR (SCUBA) and FREE Dive activities within a 24 hour period, nitrogen calculations and the displayed value of No Deco Dive Time Remaining (NDC Time) are carried over from one operating mode to the other, which permits the user to maintain awareness of nitrogen...

  • Page 152: Reference

    WARNING: Prior to diving with the ATOM, you must also read and understand the Oce- anic Dive Computer Safety and Reference Manual, Doc. No. 12-2262, which provides Important Warnings and Safety Recommenda- tions as well as general product information. REFERENCE...

  • Page 153: Uploading Settings And Downloading Data

    UPLOADING SETTINGS AND DOWNLOADING DATA The AT M is configured with a Data Port located on the back of the left side that enables it to be connected to a PC through a USB port using the special Interface Cable supplied. A USB Driver is provided on the CD as part of the Interface System.
  • Page 154 PC compatibility requirements:  IBM , or compatible, Personal Computer with USB Port  Intel Pentium 200 MHz or better microprocessor  Microsoft Windows 98 Second Edition, ME, NT, 2000, or XP  Super VGA card or compatible video graphics adaptor (256 color or greater) with a minimum 800 X 600 pixel screen area of display settings ...

  • Page 155: Care And Cleaning

    CARE AND CLEANING Protect your AT M from shock, excessive temperatures, exposure to chemicals, and tampering. Protect the lens against scratches with a Instrument Lens Protector. Small scratches will naturally disappear underwater.  Soak and rinse the AT M in fresh water at the end of each day of diving, and check to ensure that the areas around the Low Pressure (Depth) Sensor (Fig.
  • Page 156 ceanic recommends that you continue to have an inspection performed every year to ensure it is working properly. The costs of annual inspections are not covered under the terms of the 2 year limited warranty. To Obtain Service: Take your AT M system to an Authorized ceanic Dealer or send it to the nearest ce- anic Regional Distributor Facility (page 173).

  • Page 157: Battery Replacement

    BATTERY REPLACEMENT NOTE: The procedures that follow must be closely adhered to. Dam- age due to improper Battery replacement is not covered by the ATOM's 2 year warranty. When replacing the Battery in the ATOM, it is recommended that you also replace the Battery(s) in the Transmitter(s), and vice-versa.
  • Page 158 CAUTION: Damage due to improper Battery replacement is not covered by the product's limited 2 year warranty. ATOM (Watch) Battery Removal  Locate the Battery Compartment on the back of the unit. Fig. 144 - BATTERY HATCH  Rotate the Battery Hatch clockwise 10 degrees using the REMOVAL (Tool) special Battery Hatch Tool provided (Fig.
  • Page 159 WARNING: If damage or corrosion is found, return your ATOM system to an Authorized Oceanic Dealer, and DO NOT attempt to use it until it has received factory prescribed service.  Remove the Battery Hatch -ring(s) and inspect them for any signs of deterioration or deformity.
  • Page 160 Inspection (continued) -  Closely examine the threads of the Battery Hatch(es) and Housing(s) for any signs of damage that might prevent proper threading.  Closely examine the inside of the Battery Compartment(s) for any signs of corrosion indicating entrance of moisture into the unit.
  • Page 161 NOTE: The ATOM's O-ring must be a genuine Oceanic part that can be purchased from an Authorized Oceanic Dealer. Use of any other O- ring will void the warranty.  Carefully place the Battery Hatch (with -ring) into position on the rim of the Battery Compartment, then press it evenly and completely down into place.
  • Page 162  Place a new 3 volt, CR2, Lithium Battery (Duracell model DL- CR2 or equivalent) positive (+) side down into the Battery Battery Compartment with the negative end facing up/out (Fig. (+) ( - ) 153).  Ensure that the Battery is properly oriented and the Hatch -ring is evenly seated around the Battery Hatch.

  • Page 163: Installing A Transmitter On A Regulator

    INSTALLING A TRANSMITTER ON A REGULATOR To install the Transmitter on the Regulator First Stage:  Remove the existing Pressure Gauge and High Pressure Hose, or the High Pressure Port Plug from the Port marked HP using the proper size Hex Key. ...

  • Page 164: Altitude Sensing And Adjustment

    ALTITUDE SENSING AND ADJUSTMENT Prior to the first dive of a series of repetitive dives, ALTITUDE (i.e., Ambient Pressure) is measured upon activation of Dive Surface Mode and every 15 minutes until a dive is made or operation reverts to Main Time after 2 hours. >...

  • Page 165: Charts Of No Decompression Limits At Altitude

    When the Conservative Factor feature is set N, allowable dive times are calculated based upon the next higher 3,000 foot (915 meter) Altitude. All adjustments for Altitudes greater than 11,000 feet (3,355 meters) are then made to allowable dive times for 14,000 feet (4,270 meters). If the Conservative Factor is set N while at Sea Level, calculations are based upon an Altitude of 6,000 feet.

  • Page 166: Chart Of Oxygen Exposure Limits

    METRIC N DEC MPRESSI N LIMITS (H URS:MINUTES) AT ALTITUDE ltitude 916` 1221` 1526` 1831` 2136` 2441` 2746` 3051` 3356` 3661` 3966` (meters) to 915` 1220` 1525` 1830` 2135` 2440` 2745` 3050` 3355` 3660` 3965` 4270` Depth (meters) 4:43 3:37 3:24 3:10 2:58 2:48 2:39 2:31 2:24 2:18 2:12 2:07 2:24 1:52 1:44 1:37 1:30 1:25 1:21 1:17 1:13 1:10 1:07 1:04...

  • Page 167: Specifications

    SPECIFICATIONS TRANSMITTERS CAN BE USED AS • Battery and Pressure check • Watch • Dive Computer (Air or Nitrox) > every 2 minutes when asleep • Digital Depth Gauge/Timer > every 2 seconds when awake • Startup • Free Dive activity •...
  • Page 168 SPECIFICATIONS (CONTINUED) NORM/GAUG SET MODES • Set F Group (FO2 items): Factory Settings: > FO2 GAS1 (Air, 21 to 50%) > Air > FO2 GAS2 (Air, 21 to 100%) > Air > FO2 GAS3 (Air, 21 to 100%) > Air >...
  • Page 169 SPECIFICATIONS (CONTINUED) NORM No Decompression Dive Displays: • Main (default) - TLBG, Pressure, Elapsed Dive Time, Dive Time Remaining, Current Depth • Alternate #1 - TLBG, Tank Identifier, Pressure, Elapsed Dive Time, Air Time Remaining, Max Depth • Alternate #2 - O2BG, Gas Identifier, Current PO2, FO2 Set Point, Current Depth •...
  • Page 170 SPECIFICATIONS (CONTINUED) NUMERIC DISPLAYS: Range: Resolution: • Dive Number 0 to 24 • Current Depth 0 to 330 FT (100 M) 1 FT (.1 M ) • Maximum Depth 330 FT (100 M) 1 FT (.1 M) • Gas 1 FO2 Set Point Air, 21 to 50 % •...
  • Page 171 SPECIFICATIONS (CONTINUED) BAR GRAPH Tissue Loading Bar Graph: segments Oxygen (O2) Bar Graph: segments • No Decompression zone 1 to 4 • Normal zone 1 to 4 • Decompression zone 5 (all) • Danger zone 5 (all) OPERATIONAL PERFORMANCE Function: Accuracy: •...
  • Page 172 SPECIFICATIONS (CONTINUED) OPERATIONAL PERFORMANCE (continued) Power: • ATOM (Watch) Battery 1 - 3 vdc, CR2430, Lithium battery • Transmitter Battery 1 - 3 vdc, CR2, .75 Ahr, Lithium battery (Duracell model DL-CR2 or equivalent) • Shelf life Up to 7 years (when shipped from factory in Deep Sleep mode) •...
  • Page 173 WARNING: If your ATOM stops working for any reason while operating as a Dive Computer, it is important that you have antici- pated this possibility and are prepared for it. This is an important reason for not pushing the no decompression and oxygen expo- sure limits, and a critical reason to avoid entering decompression.

  • Page 174: Full Display

    TIME O2 TIME TAT TIME SURF p. Icon - degrees (Temperature) q. Icon - Daily Alarm, or - Transmitter Link r. Symbol - PSI or BAR (Pressure) s. Icon - Descend Arrow t. Icon - Low Battery ATOM 2.0 FULL LCD...

  • Page 175: Error During A Dive

    ERROR (RESET DURING A DIVE) If for any reason, the AT M 2.0 shuts ff then turns n again for any reason during any Dive, the message will ERR (Error) be displayed with the Up Arrow and current Depth (Fig. 156). If this occurs, it is highly recommended that you terminate the dive and begin a safe ascent to the surface.

  • Page 176: Inspection/ Service Record

    NSPECT ON / SERV CE RECORD ATO 2.0 Serial Number: _________________________________ ATO 2.0 Firmware Revision: _________________________________ Transmitter #1 Serial Number: _________________________________ Transmitter #2 Serial Number: _________________________________ Transmitter #3 Serial Number: _________________________________ Date of Purchase: ____________ Purchased from: __________________________ Below to be filled in by an Authorized ceanic Dealer: Date Service Performed Dealer / Technician...
  • Page 177 Tel: 61 3 5984 4770 Fax: 61 3 5984 4307 Web: www.Oceanic.de Web: www.OceanicAus.com.au E-mail: hello@oceanic.de E-mail: hello@oceanicaus.com.au OCEANIC SOUTHERN EUROPE OCEANIC ASIA - PACIFIC Genova, Italy Singapore Tel: +39 010 8382006 Fax: +39 010 8365360 Tel: +65 6391 1420 Fax: +65 6297 5424 E-mail: hello@oceanicse.it Web: www.Oceanicasia.com.sg...
  • Page 178 AT M 2.0 perating Manual Doc. No. 12-2698-r04 (12/1/08) (cover art to be placed on front/back is provided separately)

Table of Contents
