General Characteristics

82351A User's Guide
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
All characteristics are typical performance value and are not
warranted. Table 3- 2 shows the general characteristics of
the 82351A.
Table 3-2 General characteristics
General characteristics
Power
Connectors
PCIe Slot
GPIB transfer rate
Maximum instrument connection
Buffering
Configuration
Dimension
(Width x Depth x Height)
Weight
Warranty
Safety and EMC
Specifications and Characteristics
Requirement
Backplane +3.3 V PCIe
Standard 24-pin (IEEE-488)
+1.5 V PCIe
PCIe 1x, PCIe 4x, PCIe 8x
1.4 MB/s
14 instruments – daisy chain via GPIB
Built-in
Plug and Play
120.8 mm (W) x 158.0 mm (D) x 21.6 mm (H)
0.082 kg
1 year
IEC 61010-1:2001 / EN61010-1:2001
IEC 61326:2002/EN61326:1997+A1:1998
+A2:2001+A3:2003
Pollution Degree 2
This product is rated for indoor use only.
