1 Installing and Configuring the 82351A

Getting Started

PC
interface card installed in PC
2
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
An 82351A GPIB Interface System is defined as a system in
which GPIB instruments are connected via GPIB cables to
an 82351A PCIe- GPIB interface card that is installed in a
Windows PC. Figure 1- 1
GPIB Cable
port on instrument
Figure 1-1 Typical configuration system
Figure 1- 2 shows a suggested sequence of steps to install
and configure an 82351A and to communicate between your
PC and GPIB instruments via the 82351A. Use
a guide as you set up your GPIB system. See
Troubleshooting Guidelines
information on setting up the 82351A or GPIB instruments.
shows a typical system.
Instrument
Instrument
Figure 1- 1
Chapter 2
if you need additional
82351A User's Guide
as
