- Page 1 Multifernbedienung für Infrarot-Kurzwellen-Heizstrahler | Multi remote control for short-wave infrared radiant heaters | Télécommande multifonctions pour radiateurs radiants à ondes courtes IR | Multiafstandsbediening voor korte golf infrarood straalkachel | Multifunkční dálkový ovladač pro infračervené krátkovlnné zářiče » IA remote control...
-
Page 2: Table Of Contents
Contents Page Device explanation ............3 Safety instructions/Exclusion of liability .......4 General safety instructions ..........5 Scope of supply/general information ......6 Intended use ..............6 Instructions for radio operation ........7 Mounting of the wall bracket ..........8 Explanation of functions ..........9 Transmission control light, Select button ....9 Bidirectional / Unidirectional radio system ....10 Status display ............10 Programming the transmitter ........10... -
Page 3: Device Explanation
Device explanation Front of the device Channel display Operating mode display UP button STOP button Status display DOWN button Select button Back of the device Programming button P (under the cover) - 2 1 -... -
Page 4: Safety Instructions/Exclusion Of Liability
Stiebel Eltron GmbH & Co. KG assumes no liability for personal injuries, property damages and financial losses that arise from non- observance of the operating instructions. -
Page 5: General Safety Instructions
General safety instructions C A U T I O N ! Observe the following safety instructions. Failure to observe them can lead to physical injuries! General • Never install or commission devices which are dam- aged. • Only use unmodified original parts. •... -
Page 6: Scope Of Supply/General Information
2 screws (4 x 35) Operating instructions General information The IA remote control has 5 channels, into which a number of receivers can be programmed. This device is characterised by simple operation, large control but- tons and a Select button for channel selection. -
Page 7: Instructions For Radio Operation
N O T E ! The short-wave infrared radiant heater is operated by the IA remote control via the IA receiver. The short-wave infrared radiant heater can only be switched off completely by unplugging the mains plug on the radiant heater. -
Page 8: Mounting Of The Wall Bracket
Mounting of the wall bracket N O T E ! Before installation in the required assembly position, check that the transmitter and receiver are functioning properly. The bracket has to be fixed so that the drill hole does not touch any electrical lines. Mounting of the wall bracket Fix the wall bracket so that the drill holes do not touch any electrical lines! -
Page 9: Explanation Of Functions
Explanation of functions Transmission control light A radio signal is displayed by the lighting up of the transmission control light. The transmission control lamp flashes when transmitting if the bat- tery power is reduced. The transmitting power or the radio range will be reduced through the reduction in the performance of the battery. -
Page 10: Bidirectional / Unidirectional Radio System
Explanation of functions: Radio system Explanation of functions Bidirectional radio system A bidirectional radio system means the transmission of radio signals to radio receivers and optional feedback from the radio receivers to the transmitter. The radio signal can be sent directly to the target receiver. - Page 11 Status display The different colours of the status display have the following meanings: Status display Meaning Flashing orange Channel (transmitter) not programmed in any receiver Orange Channel (transmitter) in bidirectional program- Quick flashing ming mode. Operation of previously programmed receivers not possible. In group programming mode every 3 seconds (even if button is not pressed) Orange then green...
-
Page 12: Programming The Transmitter/Channel
Programming the transmitter/channel P R E R E Q U I S I T E ! The IA receiver must be installed. 1. Disconnect the fuse – and reconnect after a few seconds. The receiver is now in programming mode for approx. 5 minutes. -
Page 13: Programming Additional Transmitters/Channels
If several receivers are connected to the same feed line, then all are simultaneously ready to program. Max. 16 transmitters can be programmed into a receiver (IA receiver). The radiant heater begins to briefly light up ‘at random’. Individual channels/transmitters can now be assigned to the respective receiver. -
Page 14: Switching The Radiant Heater On/Off
The short-wave infrared radiant heater can only be switched off completely by unplugging the mains plug on the radiant heater. N O T E ! The IA receiver automatically switches the connected radiant heater(s) off after 12 hours. - 3 2 -... -
Page 15: Switching On Intermediate Stages
Switching on intermediate stages Switching on intermediate stages P R E R E Q U I S I T E ! The transmitter is now programmed. 1. Briefly press the ▲ button twice in succession. The radiant heater heats with approx. 66 % of its rated power. 2. -
Page 16: Deleting The Transmitter
Deleting transmitter/channels / Technical data Deleting individual channels 1. Press simultaneously: • Programming button P (on the back) • STOP button 2. Hold down this button combination for approx. 6 seconds, until the LED goes out briefly 3x. Deleting the complete transmitter 1. -
Page 17: Changing The Battery
Changing the battery / Cleaning / Disposal Changing the battery N O T E ! • Always replace batteries with an identical type (2 x LR 06; AA). • Dispose of used batteries properly (collection point). 1. Unscrew the device at the bottom and open the housing. -
Page 18: Overview Of Programming Commands
Overview of programming commands - 3 6 -... -
Page 19: Notes On Repair
Notes on repair / Notes on troubleshooting Notes on repair Please contact us if you are unable to eliminate a problem. When contacting our service team, please always state the item description and number from the type plate (back of device). –... - Page 20 Deutschland Verkauf Tel. 05531 702-110 | Fax 05531 702-95108 | info-center@stiebel-eltron.de STIEBEL ELTRON GmbH & Co. KG Kundendienst Tel. 05531 702-111 | Fax 05531 702-95890 | kundendienst@stiebel-eltron.de Dr.-Stiebel-Straße 33 | 37603 Holzminden Ersatzteilverkauf Tel. 05531 702-120 | Fax 05531 702-95335 | ersatzteile@stiebel-eltron.de Tel.
