- Page 1 Funkdimmer für Infrarot-Kurzwellen-Heizstrahler | Radio dimmer for short-wave infrared radiant heaters | Gradateur radio pour radiateurs radiants à ondes courtes IR | Afstandsbediende dimmer voor korte golf infrarood straalkachel | Rádiově ovládaný regulátor pro infračervené krátkovlnné zářiče » IA receiver...
-
Page 2: Table Of Contents
Contents Page Dimensions ..............19 General safety instructions ..........20 Explanation of device ............22 Programming the radio transmitter ........24 Programming additional transmitters ....... 26 Switching on the heating system ........27 Switching off the heating system ........28 Switching on the intermediate stage ........ -
Page 3: Dimensions
Dimensions Wall Recommended mounting position - 1 9 -... -
Page 4: General Safety Instructions
• Check the system regularly for wear or damage. N O T E ! The short-wave infrared radiant heater is operated via the IA receiver and the radio remote controls. The short-wave infrared radiant heater can only be switched off completely by unplugging the mains plug on the radiant heater. - Page 5 General information Radiant heaters with rated powers of up to 2 KW can be switched on and off by radio using the IA receiver. There is an additional possibility to switch the radiant heater to 66 % and 50 % of its rated power.
-
Page 6: Explanation Of Device
Explanation of device Explanation of buttons IA remote control 1 UP button 2 STOP button 3 Status indicator 4 DOWN button Rear of the device Programming button P - 2 2 -... - Page 7 Explanation of device Initial operation W A R N I N G ! Receiver becomes hot during operation! Risk of burning! • Ensure that there is sufficient ventilation for the IR Radio dimmer. • Do not use highly flammable materials in the vicinity of the IR Radio dimmer.
-
Page 8: Programming The Radio Transmitter
Programming the radio transmitter Programming the transmitter PE (green/yellow) STAS3 1 = N (blue) 2 = L 3 = L (bridged with 2) Feed cable Consumer PE (green/yellow) STAK3 1 = N (blue) 2 = L (black) 3 = free (brown) C A U T I O N ! Do not connect L to L →... - Page 9 Press the Heating OFF UP button during the (Random duration) programming phase Switch off/on mains. The IA receiver now remains in programming mode for 5 minutes. The radiant heater Briefly press switches between the program- 100 % and 50 % of ming button P.
-
Page 10: Programming Additional Transmitters
Programming additional transmitters Press the ▼ button within the first 2 sec. Heating switches off. of the program- ming phase during the 50 % heating cycle. The transmitter is programmed. Programming additional transmitters Programming possible for max. 16 transmitters. To program further transmitters, proceed as follows: Press the buttons for approx. -
Page 11: Switching On The Heating System
Programming additional transmitters / switching on the heating system Press the ▼ button within Heating switches the first 2 sec. off. of the program- ming phase during the 50 % heating cycle. The transmitter is programmed. N O T E ! If several receivers are connected to the same feed line, then all are simultaneously ready to program. -
Page 12: Switching Off The Heating System
Switching off the heating system / deleting a transmitter Switching off the heating system Press the STOP button. I M P O R T A N T ! The short-wave infrared radiant heater can only be switched off completely by unplugging the mains plug on the radiant heater. -
Page 13: Overtemperature Warning
Overtemperature warning At heat sink temperatures of approx. 90 °C and above, the IA receiver automatically reduces the heating power to 50 %. If the ▲ or ▼ button is pressed while the heating power is reduced, the IA receiver switches to 100 % heating power for 2 seconds, but then drops back to 50 %. -
Page 14: Technical Data
Technical data N O T E ! The IA receiver automatically switches the connected radiant heater(s) off after 12 hours. Technical data Mains voltage 230 V Frequency 50 Hz Max. connected power 2000 W IP Code IP 56 Connector IP Code... -
Page 15: Overview Programming Functions
Overview programming functions - 3 1 -... -
Page 16: Troubleshooting
Troubleshooting Fault Cause Remedy No radio 1. Transmitter is not 1. Program the reception. programmed. transmitter. 2. No power supply. 2. Switch on power supply. Bad radio Unfavourable position of Change position of reception. receiver. receiver or aerial. Heater does 1. -
Page 17: Guarantee
Die Montage, die Elektroinstalla Guarantee / Recycling Fachleute erfolgen. For guarantees please refer to the respective terms and conditions of supply for your country. Der Hersteller übernimmt keiner G U A R A N T E E ! Gerät gehörenden Gebrauchs- u The Installation, electrical connection and first operation of this appliance must be carried out by a qualified installer. - Page 18 Deutschland Verkauf Tel. 05531 702-110 | Fax 05531 702-95108 | info-center@stiebel-eltron.de STIEBEL ELTRON GmbH & Co. KG Kundendienst Tel. 05531 702-111 | Fax 05531 702-95890 | kundendienst@stiebel-eltron.de Dr.-Stiebel-Straße 33 | 37603 Holzminden Ersatzteilverkauf Tel. 05531 702-120 | Fax 05531 702-95335 | ersatzteile@stiebel-eltron.de Tel.
