44" 3-in-1 Console (WMCXL-2)
This item is designed to be 3-in-1 configuration. Please choose which of the 3 options suits your
needs. DO NOT discard any of the hardware or parts that you will not use on your set option, this
will give you the opportunity to use this TV Console for different configurations in case you decide
to upgrade your TV set in the future.
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if you are missing parts, do not return this item to
the Retailer Store. Please call our toll-free customer service number and have your instructions
and parts list ready to provide the model name, part name or factory number:
1-866-942-5362
ONLINE: www.whalenfurniture.com
Whalen Furniture Mfg. Inc.
8:30 a.m. - 4:30 p.m. PST, Monday - Friday
Video Instruction Guides
Go to http://whalen.showuhow.com to view step-by-step instructional
videos for assembling and installing your product. Enter the following
product number on the ShowUhow homepage.
XL-2 or WMCXL-2
LOT NUMBER:
DATE PURCHASED:
With Swinging Floater
EMAIL: parts@whalenfurniture.com
Page 1
Option 1
Factory No. 33-10944
/
/
Advertisement
Related Manuals for Whalen WMCXL-2
Summary of Contents for Whalen WMCXL-2
- Page 1 8:30 a.m. - 4:30 p.m. PST, Monday - Friday ONLINE: www.whalenfurniture.com EMAIL: parts@whalenfurniture.com Video Instruction Guides Go to http://whalen.showuhow.com to view step-by-step instructional videos for assembling and installing your product. Enter the following product number on the ShowUhow homepage. XL-2 or WMCXL-2 Whalen Furniture Mfg.
- Page 2 I M P O R T A N T I N F O R M A T I O N THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. MANUFACTURER: Whalen Furniture CATALOG: 44” 3-in-1 Console (WMCXL-2) DATE OF MANUFACTURE: December, 2010 MADE IN CHINA FITS UP TO MOST 50” FLAT PANEL TV’S MAXIMUM LOAD 135 lb.
- Page 3 Model # WMCXL-2 Parts and Hardware List Please read completely through the instructions and verify that all parts listed are present before beginning assembly. A-Top Shelf Frame (1) B- Middle Shelf Frame (1) C- Bottom Shelf Frame (1) E- Left “L” Shape Leg (1)
- Page 4 Model # WMCXL-2 Parts and Hardware List (2) - 3/4” Bolt (3) - 1 1/4” Bolt (1) - Suction Cup (4) - Hex Nut (20+1 extra) (18+1 extra) (16+1 extra) (4+1 extra) (5) -Black Lock Washer (6) - Zinc Lock Washer (7) – Black Flat Washer (8) - Zinc Flat Washer...
- Page 5 Model # WMCXL-2 Assembly Instructions Note: Please do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make it easier during assembly of unit. 1. Unpack the unit and confirm that you have all the hardware and parts required.
- Page 6 Model # WMCXL-2 Assembly Instructions 5. Choose the option suits your needs. Locate Long Spine (D) or Short Spine (D1) and set back face down on a scratch free surface as shown in detail #2. 6. Align the holes on back rail of 3 Shelf Frames (A, B & C) with the sockets on the Spine.
- Page 7 Model # WMCXL-2 Assembly Instructions 7. Stand the unit upright. 8. Align and attach Left Leg Assembly to the Top Shelf Frame (A) using two 1” Bolts (13) with Zinc Washers (6 & 8) through the pre-drilled holes on inner side rail into the top of both Legs.
- Page 8 Model # WMCXL-2 Assembly Instructions 11. Go back and tighten all bolts with Allen Wrench provided. 12. In case of uneven floor, Floor Levelers are provided at the bottom of both Front Legs (F & H). Simply tilt the unit back and raise or lower floor leveler by hand to correct tilting as shown in detail #4.
- Page 9 Model # WMCXL-2 Assembly Instructions for Table-top 13. Attach 2 Cable Controls (12) onto the backside of Spine (D1) with the 3/4” Bolts (2). Tighten the bolts with the Allen Wrench provided. See detail #5. 14. The Cable Controls (12) enable you to shorten, separate and route cables and cords. Using...
- Page 10 Model # WMCXL-2 Assembly Instructions for Table-top 15. Put Suction Cups (1) firmly into the top holes and corner plates on 3 Shelf Frames (A, B & C) as shown in detail #6. 16. Place Top Glass (I) and Glass Shelves (J & K) in place as shown in detail #6. Make sure the glass is properly centered and the black side of glass is down.
- Page 11 Model # WMCXL-2 Assembly Instructions for Table-top 17. Position the assembled Table-top in your desired location against the wall. Now follow the instructions printed on the plastic bag in order to mount the Tipping Restraint Hardware Kit to the Spine properly. As shown in detail #7.
- Page 12 Model # WMCXL-2 A s s e m b l y I n s t r u c t i o n s f o r O p t i o n 1 : C o n s o l e w i t h S w i n g i n g F l o a t e r attach Swiveling Bracket (L) to the top of Long Spine (D) using six 3/4”...
- Page 13 Model # WMCXL-2 Assembly Instructions for Console with Swinging Floater 20. Hold the flat side of XYZ Mounting Frame (M) onto the Swiveling Bracket (L) ensuring the hook on the side of Mounting Frame is bottom. Align and attach by threading four 3/4” Bolts...
- Page 14 Model # WMCXL-2 Mounting Monitor Bracket to a television with a flat back Note: For televisions with a curved back or recessed back proceed directly to step #24. 21. Determine the correct diameter of the bolt your TV requires by hand threading them into the threaded insert on the back of the TV.
- Page 15 Model # WMCXL-2 Mounting Monitor Bracket to a television with a curved / recess back 24. Determine the correct diameter of the bolt your TV requires by hand threading them into the threaded insert on the back of the TV. If you encounter any resistance, stop immediately. If you are unable to find the correct bolt consult a local hardware store.
- Page 16 Model # WMCXL-2 Assembly Instructions for Console with Swinging Floater MAKE SURE ALL BOLTS ARE TIGHT AND SPINE IS AT A 90 DEGREE ANGLE AND USING A QUALITY LEVEL TO VERIFY THE MOUNTING FRAME IS LEVEL PRIOR TO INSTALLATION OF TV.
- Page 17 Model # WMCXL-2 Assembly Instructions for Option 1: Console with Swinging Floater 29. Repeat steps 13 thru 16 to attach the Cable Controls (12) and install Top Glass (I) and Glass Shelves (J & K) in place. 30. Carefully move the console and position in your desired location against the wall. Now follow the instructions printed on the plastic bag in order to mount the Tipping Restraint Hardware Kit to the Spine and wall properly.
- Page 18 Model # WMCXL-2 The following steps are only for those who wish to mount their TV directly to the wall. If you have already mounted your TV to the Swinging Floater or plan to display your TV on the top surface of the stand, disregard the following steps.
- Page 19 Model # WMCXL-2 Assembly Instruction for installing XYZ Mounting Frame onto BRICK, SOLID CONCRETE OR CONCRETE BLOCK 35. Use the XYZ Mounting Frame (M) as a template, mark six holes location on the wall, three in the top row and three in the bottom row of slots. Make sure that the holes are level and there is at least 6”...
- Page 20 Model # WMCXL-2 Assembly Instructions for Universal Wall Mount 38. Once the Monitor Brackets (N) are attached onto the back of television, ask for assistance to lift the television up to the XYZ Mounting Frame (M). Place the hooks on Monitor Brackets over the Mounting Frame then lower them onto the bars of Mounting Frame.
-
Page 21: Care And Maintenance
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
