IO -RO 16, IO -RO 16-L
IO-RO16, IO-RO16-L Technical Specifications
Max. current consumption
Typical power consumption
Status indicator
(RUN)
Outputs
Number of outputs
Output type
Type of relay
IO-RO16
IO-RO16L
Isolation
Status Indicators
(O0 to O15)
Output current
Maximum frequency
Contact protection
Outputs' power supply: IO-RO16
Nominal operating voltage
Operating voltage
Maximum current consumption
Outputs' power supply: IO-RO16-L
Nominal operating voltage
Operating voltage
Maximum current consumption
Notes:
1. Each group of 8 outputs share a common signal.
Environmental
Operating temperature
Storage temperature
Relative Humidity (RH)
Dimensions (WxHxD)
Weight
Mounting
6
I / O E x p a n s i o n M o d u l e s
60mA maximum from the adapter's 5VDC
0.18W @ 5VDC
Green LED:
—Lit when a communication link is established between module and OPLC.
—Blinks when the communication link fails.
16 relay ( in two groups)
SPST-NO relay; 230VAC / 12/24 VDC
Fujitsu (Takamisawa) NY-24W-K or NAIS (Matsushita) PA1a-24V
Fujitsu (Takamisawa) NY-12W-K or NAIS (Matsushita) PA1a-12V
By relay
Red LEDs—Lit when the corresponding output is active.
Resistive Load
3A maximum per output
8A maximum total for common. See Note 1.
Inductive Load
1A maximum per output
4A maximum total for common. See Note 1
10Hz
External precautions required (see above: Increasing Contact Life Span)
24VDC
20.4 to 28.8VDC
132mA@24VDC
12VDC
10.2 to 15.6VDC
176mA@12VDC
IP20 / NEMA1
0° to 50°C (32° to 122°F)
-20° to 60° C (-4° to 140°F)
5% to 95% (non-condensing)
80mm x 93mm x 60mm (3.15" x 3.66" x 2.362")
125g (4.25 oz.)
Either onto a 35mm DIN-rail or screw- mounted.
