Kramer FC-46H2 Quick Start Manual

Scan for full manual
Step 1: Check what's in the box
FC-46H2 4K HDMI Audio De-Embedder
1 Power adapter and cord

Step 2: Get to know your FC-46H2

# Feature
1 PROG Mini USB Port
2 SETUP 4-way DIP-switch
3 AUDIO SOURCE Selector Button
IN LED
OUT LED
4 AUDIO OUT DIGITAL
LEDs
ANALOG
5 ON LED
6 HDMI™ IN Connector
7 HDMI™ OUT Connector
FC-46H2 Quick Start
FC-46H2 Quick Start Guide
This guide helps you install and use your FC-46H2 for the first time.
Go to www.kramerav.com/downloads/FC-46H2
upgrades are available.
4 Rubber feet
1 Quick start guide
Function
Connect to a PC to perform firmware upgrades (via K-Upload) and work with the
EDID Designer.
K-Upload and EDID Designer can be downloaded from our Web site at:
www.kramerav.com/downloads/FC-46H2).
To use the mini USB port, you need to download the Kramer USB driver from our
Web site at:
Set the device behavior.
All the DIP-switches are set to off (up) by default.
# Feature
1 EDID Mode
2 Audio Support
3/4 Analog Audio
Amplification
Amplification Level
Press to route the audio source from HDMI IN or from HDMI OUT (ARC) to the
audio outputs.
Lights green when HDMI IN is selected.
Lights green when HDMI OUT is selected (ARC).
Lights green when a de-embedded audio signal is present on the S/PDIF output.
Lights green when a de-embedded audio signal is present on the ANALOG
audio output.
Lights green when powered.
Connect to an HDMI source.
Connect to an HDMI acceptor.
to download the latest user manual and check if firmware
1 Bracket set
www.kramerav.com/support/product_downloads.asp
DIP-switch Settings
On (down) — EDID locked.
Off (up) — EDID pass-through mode.
When EDID is locked, the audio parameters are set
as defined by DIP-switch 2. In pass-through mode,
the DIP-switch 2 setup is ignored.
On (down) — Limits the audio to 2-channel LPCM.
Off (up) — Passes the audio parameters.
This setup is enabled only after DIP-switch 1 is set
to On (down; EDID locked).
3 Off (up)
4 Off (up)
0dB
P/N:
2900- 300873QS
and install it.
On (down) Off (up) On (down)
Off (up) On (down) On (down)
6dB 12dB 18dB
Rev:
1
