Page 1: User Manual
K R A ME R E LE CT R O N IC S L TD . USER MANUAL MODEL: FC-49 DVI / Audio to HDMI Converter P/N: 2900-000286 Rev 6... -
Page 3: Table Of Contents
Connecting the FC-49 DVI / Audio to HDMI Converter Acquiring an EDID Technical Specifications Default EDID Figures Figure 1: FC-49 DVI / Audio to HDMI Converter Figure 2: Connecting the FC-49 DVI / Audio to HDMI Converter FC-49 – Contents... -
Page 4: Introduction
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11: Sierra Products. Congratulations on purchasing your Kramer TOOLS FC-49 DVI / Audio to HDMI Converter, which is ideal for: ... -
Page 5: Getting Started
Avoid interference from neighboring electrical appliances that may adversely influence signal quality Position your Kramer FC-49 away from moisture, excessive sunlight and dust This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building. -
Page 6: Recycling Kramer Products
Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at http://www.kramerelectronics.com/support/recycling/. -
Page 7: Overview
Overview The Kramer FC-49 DVI / Audio to HDMI Converter is a high−quality format converter and embedder for DVI and audio signals. It converts a DVI signal and embeds an unbalanced stereo, S/PDIF or TOSLINK® audio signal to an HDMI output. -
Page 8: Defining The Fc-49 Dvi / Audio To Hdmi Converter
Defining the FC-49 DVI / Audio to HDMI Converter Figure 1: FC-49 DVI / Audio to HDMI Converter Feature Function 12V DC +12V DC connector for powering the unit AUDIO S/PDIF RCA Connector Connects to the digital audio source INPUTS OPTICAL TosLink®... -
Page 9: Connecting The Fc-49 Dvi / Audio To Hdmi Converter
S/PDIF (digital audio) RCA IN connector (or you can connect the audio source to the ANALOG or OPTICAL audio connector) Note: S/PDIF in the FC-49 supports stereo audio and not 5.1 channel audio. 3. Connect the 12V DC power adapter to the power socket and connect the... -
Page 10: Acquiring An Edid
2. Connect the new output display (or keep it disconnected to acquire the default EDID). 3. Press and hold the EDID CAPTURE button until the green IN LED starts flashing, and then release the button. The EDID is acquired after the IN LED stops flashing. FC-49 – Acquiring an EDID... -
Page 11: Technical Specifications
10% to 90%, RHL non-condensing DIMENSIONS: 12cm x 7.2cm x 2.4cm (4.73" x 2.83" 0.95") W, D, H WEIGHT: 0.3kg (0.6lbs) approx. ACCESSORIES: Power supply, bracket installation kit OPTIONS: RK-3T 19" rack adapter Specifications are subject to change without notice FC-49 - Technical Specifications... -
Page 12: Default Edid
1024 x 768p at 85Hz - VESA STD 800 x 600p at 85Hz - VESA STD 640 x 480p at 85Hz - VESA STD EIA/CEA-861 Information Revision number..3 IT underscan..... Supported Basic audio....Supported YCbCr 4:4:4....Not supported YCbCr 4:2:2....Not supported FC-49 – Default EDID... - Page 13 IEEE registration number. 0x000C03 CEC physical address..1.0.0.0 Maximum TMDS clock..165MHz Report information Date generated... 29/05/2012 Software revision..2.60.0.964 Data source....Real-time 0x0031 Operating system..5.1.2600.2.Service Pack 3 Raw data 00,FF,FF,FF,FF,FF,FF,00,2E,4D,00,00,01,00,00,00,0C,10,01,03,81,46,27,78,0B,D5,7C,A3,57,49,9C,25, 11,48,4B,BF,EF,00,A9,40,81,59,8B,D9,61,59,45,59,31,59,01,01,01,01,01,1D,00,72,51,D0,1E,20,6E,28, 55,00,C4,8E,21,00,00,1E,8C,0A,D0,8A,20,E0,2D,10,10,3E,96,00,C4,8E,21,00,00,18,00,00,00,FC,00,46, 43,2D,34,39,0A,20,20,20,20,20,20,20,00,00,00,FD,00,37,55,1E,5B,10,00,0A,20,20,20,20,20,20,01,58, 02,03,18,C1,45,01,02,03,84,05,23,09,07,07,83,01,00,00,65,03,0C,00,10,00,8C,0A,D0,8A,20,E0,2D,10, 10,3E,96,00,13,8E,21,00,00,18,01,1D,80,18,71,1C,16,20,58,2C,25,00,C4,8E,21,00,00,9E,00,00,00,00, 00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00, 00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,EE FC-49 - Default EDID...
- Page 15 For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com E-mail: info@kramerel.com SAFETY WARNING...
