AR-M9919/9920
Serial Manual
1. System Setting
The AR-M9919 for AR-B1551 3.5" CPU board provides external ports such as two
serial ports, one Lan port, KB/Mouse Connector and Audio. The Audio here also
included Mic、 Line-in、 Line-out、 and speaker out, DC power jack.
Beside that, the AR-M9920 for AR-B1550 3.5" CPU board also provides external
ports such as one serial port and three Lan port with activity LEDS and DC power
jack.
1.1 Discrimination
AR-M9919A
Description
Utility disks for
CPU Board
AR-B1551
RAM
SDRAM 64 MB SDRAM 128MB 32MB On board 64MB On board
167(w)×109(d)
Dimensions
×52.5(h)mm
1.2 AR-M9919 Main System
(1) Outlet
MIC
LINE
KM
COM1
Page 1 of 4
Version 1.0
AR-M9919B
AR-M9920C
Utility disks for
Utility disks for
Utility disks for
AR-B1551
AR-B1550C
AR-B1550D
167(w)×109(d)
167(w)×109(d)
167(w)×109(d)
×52.5(h)mm
×52.5(h)mm
×52.5(h) mm
LINE
SPK
IN
OUT
OUT
COM2
RST
CRT
LAN1
(2) External Dimension
AR-M9920D
PWR
HDLED
CFLED
P/WLED
AR-M9919/9920
