- Page 1 AR-B1675 User’s Guide AR-B1675 VIA Mark CoreFusion 800MHz, Half Size ,On Board SDRAM,VGA,LVDS with One SDRAM SO-DIMM, built in LAN,CF Type-II Edition: 2.0 Book Number: AR-B1675-06.11.17 AR-B1675...
- Page 2 Trademarks AR-B1675 is registered trademarks X-Fire Acrosser, IBM PC is a registered trademark of International Business Machines Corporation. Pentium is a registered trademark of Intel Technologies, Inc. Award is registered trademarks of Award Software International, Inc.
-
Page 3: Table Of Contents
Contents ..............3 Introduction ............. 5 1.1 Specifications:................5 1.2 What You Have................. 6 Installation .............. 7 2.1 AR-B1675’s Layout..............7 2.2 Power Button Setting ..............9 2.3 CMOS Reset................10 2.4 Jumper description ..............10 Connection............12 3.1 Ultra ATA33 IDE Disk Drive Connector(IDE2)......12 3.2 Serial Ports(COM2) .............. - Page 4 AR-B1675 User’s Guide 3.9 AUDIO Connector(AUDIO1) ........... 17 3.10 SDRAM SODIMM Socket (DIMM1) ........17 3.11 8-BIT GPIO Connector(CN1)..........17 3.12 Parallel port(LPT1)..............18 3.13 LVDS Connector(LVDS1) ............. 18 Award BIOS Setup..........20 4.1 Introduction ................20 4.2 Starting Setup ................. 20 4.3 Using Setup ................
-
Page 5: Introduction
AR-B1675 User’s Guide Introduction 1.1 Specifications: CPU : Onboard VIA Mark CoreFusion 800MHz CPU. Chipset : VIA VT82C686B South Bridge RAM memory : Onboard 128M SDRAM and One SDRAM SO-DIMM Socket support to 1 GB/133MHz. Display Controller: MARK integrated ProSavage 4 3D/2D Graphic Controller. -
Page 6: What You Have
AR-B1675 User’s Guide Operating Temperature : 0 ° ~ 60 ° C Dimension: 122mm(W) X 185mm(L) 1.2 What You Have In addition to this User's Manual, the AR-B1675 package includes the following items: AR-B1675 board Setting Manual Software utility CD... -
Page 7: Installation
AR-B1675 User’s Guide Installation This chapter describes how to install the AR-B1675. At first, the layout of AR-B1675 is shown, and the unpacking information that you should be careful is described. The jumpers and switches setting for the AR-B1675’s configuration 2.1 AR-B1675’s Layout... - Page 8 AR-B1675 User’s Guide Bottom Placement AR-B1675...
-
Page 9: Power Button Setting
AR-B1675 User’s Guide 2.2 Power Button Setting • CN3 : Power Connector DESCRIPTION • PWRON1 : Power Button Connector DESCRIPTION Open Showdown Short Power ON • HDLED1 : HardDisk LED Connector DESCRIPTION HD_LED • RST1 : Reset Button Connector DESCRIPTION... -
Page 10: Cmos Reset
AR-B1675 User’s Guide 2.3 CMOS Reset • CMOS1 : CMOS pin header CMOS1 DESCRIPTION Normal Operation Reset CMOS 2.4 Jumper description • JP2 : Select CF Master or Slave mode DESCRIPTION Short Master Open Slave • JP3 : COM1/2 Select RI is 12V/5V or signal... - Page 11 AR-B1675 User’s Guide • JP1: Select LCD Voltage DESCRIPTION +3.3V • J1 : Inverter Power Connector PIN NO. DESCRIPTION +12V +12V BKLTEN BKLTCTL • Kb_key1: Keyboard Lock Connector DESCRIPTION Short Normal Open Lock • Ms_key1: Mouse Lock Connector DESCRIPTION Short...
-
Page 12: Connection
AR-B1675 User’s Guide Connection This chapter describes how to connect peripherals, switches and indicators to the AR-B1675 board. 3.1 Ultra ATA33 IDE Disk Drive Connector(IDE2) You can attach two IDE( Integrated Device Electronics) hard disk drives to the AR-B1675 IDE controller. -
Page 13: Serial Ports(Com2)
AR-B1675 User’s Guide 3.2 Serial Ports(COM2) The AR-B1675 offers two high speeds NS16C550 compatible UARTs with Read/Receive 16 byte FIFO serial ports. • COM1 : RS-232 Serial port DESCRIPTION DESCRIPTION NDCD NDTR NDSR NRTS NCTS NRIA_12V • COM2: RS-232 with RS-422/485 Serial port(Pin Header) -
Page 14: Usb Port Connector(Usb1~4)
• KB_MS1 : Keyboard Mouse JST Port PIN NO. DESCRIPTION +12V +12V BKLTEN BKLTCTL 3.4 USB Port Connector(USB1~4) The AR-B1675 provides four USB port, four pin header . • USB1/2/3/4: USB Connector(Pin header) DESCRIPTION DESCRIPTION USB- USB+ USB+ USB- 3.5 Fan Connector (FAN1) The AR-B1675 provides one connectors for CPU cooling fan. -
Page 15: Lan Rj45 Connector (J4)
PIN NO. DESCRIPTION 3.7 Compact Flash Storage Card Socket(CF1) The AR-B1675 configures Compact Flash Storage Card in IDE Mode. This type II Socket is compatible with IBM Micro Drive. • CF1 : Compact Flash Storage Card Socket pin assignment DESCRIPTION... -
Page 16: Vga Connector(Vga1)
GROUND Note: If IDE2 & CFD1 both in used, CFD1 must be as “Master” & IDE2 is as “Slave”. 3.8 VGA Connector(VGA1) The AR-B1675 has a built-in 15-pin VGA connector accepting the CRT monitor • VGA1 : 15-pin D-Sub Connector... -
Page 17: Audio Connector(Audio1)
AR-B1675 User’s Guide 3.9 AUDIO Connector(AUDIO1) • AUDIO1 : Audio Pin Header DESCRIPTION DESCRIPTION LINE OUT R LINE OUT L LINE IN R LINE IN L MIC IN 3.10 SDRAM SODIMM Socket (DIMM1) There are one 144-pin SDRAM DIMM slots to accept 3.3V. The max Memory size is 1GB. -
Page 18: Parallel Port(Lpt1)
AR-B1675 User’s Guide 3.12 Parallel port(LPT1) This port is usually connected to a printer. The AR-B1675 cludes an on-board parallel port. • LPT1: Parallel Port Connector DESCRIPTION DESCRIPTION STB- AFD- ERR- INIT- SLIN- ACK- BUSY SLCT 3.13 LVDS Connector(LVDS1) • LVDS1 : LVDS Interface Connector... - Page 19 AR-B1675 User’s Guide DESCRIPTION DESCRIPTION LCDVDD TRXEC- TRXEC+ TRXE2- TRXE2+ TRXE1- TRXE1+ TRXE0+ TRXE0- TRXOC+ TRXOC- TRXO2+ TRXO2- TRXO1+ TRXO1- TRXO0+ TRXO0- LCDVDD LCDVDD AR-B1675...
-
Page 20: Award Bios Setup
AR-B1675 User’s Guide Award BIOS Setup 4.1 Introduction This chapter discusses the Setup program built into the BIOS. Setup program allows users to configure the system. This configuration is then stored in battery-backed CMOS RAM so that it retains the Setup information while the power is off. -
Page 21: Using Setup
AR-B1675 User’s Guide 4.3 Using Setup In general, you can use the arrow keys to highlight items, press <Enter> to select, use the PageUp and PageDown keys to change entries, press <F1> for help and press <Esc> to quit. The following table provides more details about how to navigate in the Setup program using the keyboard. -
Page 22: Main Menu
AR-B1675 User’s Guide 4.4 Main Menu The items in Standard CMOS Setup Menu are divided into 8 categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn>... - Page 23 AR-B1675 User’s Guide All, but Keyboard stop POST All, but Diskette process and notify you All, but Disk/Key Base Memory Displays the amount of conventional memory detected during boot up Extended Memory Displays the amount of extended memory detected during boot up...
- Page 24 AR-B1675 User’s Guide Figure 2 IDE Primary Master sub menu Use the legend keys to navigate through this menu and exit to the main menu. Use Table 2 to configure the hard disk. Item Options DESCRIPTION IDE HDD Auto-detection Press Enter Press Enter to auto-detect the HDD on this channel.
-
Page 25: Advanced Bios Features
AR-B1675 User’s Guide means NONE ! Capacity Auto Display Disk drive capacity your disk drive (Approximated). Note that size this size is usually slightly greater than the size of a formatted disk given by a disk checking program. Access Mode... - Page 26 AR-B1675 User’s Guide APIC Mode This item allows use Advanced Programmable Interrupt Controller feature. The Choice: Enabled, Disabled. Quick Power On Self Test This category speeds up Power On Self Test (POST) after you power up the computer. If it is set to Enable, BIOS will shorten or skip some check items during POST.
-
Page 27: Pnp/Pci Configuration Setup
AR-B1675 User’s Guide The Choice: Vbios default, CRT, CRT + LCD, CRT + LVDS. Panel Type This item allows you to choose display panel type and resolution The Choice: 640x480,800x600,1024x768. 4.6 PnP/PCI Configuration Setup Figure 4 PnP/PCI menu Resource controlled by The Award Plug and Play BIOS has the capacity to automatically configure all of the boot and Plug and Play compatible devices. -
Page 28: Peripheral
AR-B1675 User’s Guide IRQ Resources When resources are controlled manually, assign each system interrupt a type, depending on the type of device using the interrupt. IRQ3/4/5/7/9/10/11/12/assigned to This item allows you to determine the IRQ assigned to the ISA bus and is not available to any PCI slot. -
Page 29: H/W Monitor
AR-B1675 User’s Guide Select an address and corresponding interrupt for the first and second serial ports. The choice: 3F8/IRQ4, 2E8/IRQ3, 3E8/IRQ4, 2F8/IRQ3, Disabled Onboard Parallel Port Select 3BC/IRQ7 to enable On Board Parallel Port as first Parallel Interface. The choice: Disable, 378/IRQ7, 278/IRQ5, 3BC/IRQ7. -
Page 30: Boot
AR-B1675 User’s Guide 4.9 Boot Figure 7 Boot menu First/Second/Third/Other Boot Device The BIOS attempts to load the operating system from the devices in the sequence selected in these items. The Choice: Hard Disk ……. [ ] CDROM … …….[ ] USB-FDD .. -
Page 31: Exit Selecting
AR-B1675 User’s Guide Disabled ….. ……[ ] 4.10 Exit Selecting Figure 8 Exit menu Save & Exit Setup Load Optimized Defaults Exit Without Saving Set Password Save & Exit Setup Pressing <Enter> on this item asks for confirmation: Save to CMOS and EXIT (Y/N)? Y Pressing “Y”... - Page 32 AR-B1675 User’s Guide The next time you boot your computer, the BIOS configures your system according to the Setup selections stored in CMOS. After saving the values the system is restarted again. Load Optimized Defaults Use this menu to load the BIOS default values that are factory settings for optimal performance system operations.
