AR-B1653 User’s Guide AR-B1653 3.5” EBC with VIA Mark Processor, VGA/ LCD/ LAN/ USB CPU Board User’ s Guide Edition: 1.0 Book Number: AR-B1653-07.0701... -
Page 2: Table Of Contents
AR-B1653 User’s Guide Table of Contents 0.PREFACE……………..............................3 0.1 COPYRIGHT NOTICE AND DISCLAIMER .............................3 0.2 WELCOME TO THE AR-B1653 CPU BOARD..........................3 0.3 BEFORE YOU USE THIS GUIDE ..............................3 0.4 RETURNING YOUR BOARD FOR SERVICE..........................3 0.5 TECHNICAL SUPPORT AND USER COMMENTS ........................4 0.6 STATIC ELECTRICITY PRECAUTIONS.. -
Page 3: Preface
0.3 BEFORE YOU USE THIS GUIDE Please refer to the Chapter 2, “System Setting,” in this guide, if you have not already installed this AR-B1653. Check the packing list before you install and make sure the accessories are completely included. -
Page 4: Technical Support And User Comments
You may, of course, continue to use the information you provide. If you have any suggestions for improving particular sections or if you find any errors on it, please send your comments to Acrosser Technology Co., Ltd. or your local sales representative and indicate the manual title and book number. -
Page 5: Introduction
In addition, the AR-B1653 provides on chip VGA. The VGA, which provides up to Ture Color (32 bit) 1024x768. The VGA memory is share main memory (2M, 4M, or 8M). AR-B1653 also has 18-bit LVDS function in the system. The AR-B1653 is loaded with special on-board features that rival full-size systems. It has one network controller on board, uses RealTek RTL8100C LAN controller, a fully integrated 10/100BASE-TX solution with high performance networking functions. -
Page 6: Specifications
Operating Temperature: 0° ~ 60℃ 1.2 PACKING LIST These accessories are included with the system. Before you begin installing your AR-B1653 board, please make sure that the following items have been included inside the AR-B1653 package. The quick setup manual... -
Page 7: Setting Up System
AR-B1653 User’s Guide 2. SETTING UP SYSTEM This chapter describes how to install the AR-B1653. At first, the layout of AR-B1653 is shown, and the unpacking information that you should be careful is described. Overview System Settings 2.1 AR-B1653 OVERVIEW... -
Page 8: System Settings
2.2.2 SDRAM SOCKET 144 PIN (DIMM1) It can assemble 16/32/64/128/256/512MB 144 pin DIMM Module Memory. When you set up 144-pin DIMM Module Memory, AR-B1653 will auto-detect DRAM, and adopt correct save in order to make memory work till the best situation. -
Page 9: Hard Disk (Ide) Connector (Ide1)
AR-B1653 User’s Guide 2.2.3 Hard Disk (IDE) Connector (IDE1) 44 Pin Hard Disk Connector (IDE1) The on-board 44-pin mini-pitched IDE interface is used to let user support either a 3.5" HDD with 44 to 40pin adapter cable. Signal Signal -RESET... -
Page 10: Crt Connector (Vga1)
AR-B1653 User’s Guide 2.2.5 CRT Connector (VGA1) VGA1 is a standard 15-pin D-SUB connector commonly used for VGA. 2.2.6 USB Connector (USB1) The Universal Serial Bus (USB) controller is USB V1.1 and Universal HCI V1.1 compliant. The Universal Serial Bus (USB) standard is a low-to-medium speed interface for the connection of PC peripherals, which gives complete Plug &... -
Page 11: External Buzzer (Bz1)
AR-B1653 User’s Guide 2.2.8 EXTERNAL BUZZER (BZ1) 2.2.9 Serial Port (COM1, COM2) AR-B1653 is equipped with four serial ports. COM1 is a standard RS-232 interface. COM2/ use an adapter cable to interface with external equipment. A. COM1 USED RS232 COM1 B. -
Page 12: Gpio Port (Cn1)
D-type connector. The typical application is a touch screen panel. 2.2.13 26-Pin Audio Connector (AUDIO1) Note: the connector does not contain the GAME (MIDI) port signal. When AR-B1653 audio card is used with this CPU board, the GAME port function is not supported. -
Page 13: Lcd Inverter Connector (Cn2)
AR-B1653 User’s Guide 2.2.14 LCD Inverter Connector (CN2) Signal +12V +12v ENVEE 2.2.15 LED (LED1) Power LED: External LED connector for Watchdog status indication. LAN LED: External LED connector for 10/100M LAN HDD LED (IDE1): External LED connector for primary IDE channel. -
Page 14: Power Connector (Pwr1)
AR-B1653 User’s Guide 2.2.18 Power Connector (PWR1) The PWR1 is a 4-pin power connector. It’s the standard connector on all Acrosser boards. 2.2.19 PC/104 Connector (PC104) (1) 64 Pin PC/104 Connector A&B (2) 40 Pin PC/104 Connector C&D Note: If the content in setting is inconsistent with the CD-ROM, please refer to the setting as the priority. -
Page 15: 18-Bit Lcd Panel Connector (Lcd1)
2.2.23 Battery Connector (BT1) 3. WATCHDOG TIMER This section describes the use of Watchdog Timer, including disable, enable, and trigger. AR-B1653 is equipped with a programmable time-out period watchdog timer that occupies I/O port 443H. Users can use simple program to enable the watchdog timer. -
Page 16: Watchdog Timer Setting
4. BIOS CONSOLE This chapter describes the AR-B1653 BIOS menu displays and explains how to perform common tasks needed to get up and running, and presents detailed explanations of the elements found in each of the BIOS menus. The... -
Page 17: Bios Setup Overview
AR-B1653 User’s Guide 4.1 BIOS SETUP OVERVIEW The BIOS is a program used to initialize and set up the I/O system of the computer, which includes the ISA bus and connected devices such as the video display, diskette drive, and the keyboard. -
Page 18: Advanced
AR-B1653 User’s Guide Date & Time Setup Highlight the <Date> field and then press the [Page Up] /[Page Down] or [+]/[-] keys to set the current date. Follow the month, day and year format. Highlight the <Time> field and then press the [Page Up] /[Page Down] or [+]/[-] keys to set the current date. -
Page 19: Peripheral
AR-B1653 User’s Guide USB Keyboard Support [Disable] SUPPORT USB KEYBORD Frame Buffer Size [16M] 4.3 PERIPHERALS Peripherals Onboard Serial Port 1 [AUTO] Onboard Serial Port 2 [Auto] Choose serial port 1 to 2 I/O address. Do not set port 1 to 2 to the same... - Page 20 AR-B1653 User’s Guide UART 2 MODE [Standard] Select an operating mode for the second serial port: Normal RS-232C serial port Standard RS-232C serial port IrDA 1.0 Infrared port compliant with IrDA 1.0 specification IrDA SIR IrDA-compliant serial infrared port IrDA MIR...
-
Page 21: Pnp/Pci
AR-B1653 User’s Guide 4.4 PNP/PCI PnP/PCI Reset Configuration Data [Disable] Normally, you leave this field Disabled. Select Enabled to reset Extended System Configuration Data (ESCD) when you exit Setup if you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the operating system cannot boot. -
Page 22: H/W Monitor
AR-B1653 User’s Guide 4.5 H/W MONITOR H/W Monitor CURRENT CPU TEMP. The onboard hardware monitor automatically detects and displays the motherboard and CPU temperatures. CURRENT SYSTEM TEMP. The onboard hardware monitor automatically detects and displays the motherboard and System temperatures. -
Page 23: Boot
AR-B1653 User’s Guide 4.6 BOOT BOOT First/Second/Third Boot Device Boot Other Device [Enabled] Select Your Boot Device Priority... -
Page 24: Bios Exit
AR-B1653 User’s Guide 4.7 BIOS EXIT Exit When you have made all of your selections from the various menus in the Setup program, save your changes and exit Setup. Select Exit from the menu bar to display the following menu. -
Page 25: Appendix B. Interrupt Request (Irq)
AR-B1653 User’s Guide 000A0000-000BFFFF VIA CPU to AGP Controller 000CE000-000CFFFF Motherboard resources 000CE000-000EFFFF PCI bus 000F0000-000F3FFF Motherboard resources 000F4000-000F7FFF Motherboard resources 000F8000-000FFFFF Motherboard resources 00100000-00FFFFFF System board 07000000-FEBFFFFF PCI bus E0000000-E7FFFFFF S3 Graphics Twister+S3Hotkey E0000000-E7FFFFFF VIA CPU to AGP Controller... - Page 26 AR-B1653 User’s Guide VIA Rev 5 or later USB Universal Host Controller Microsoft PS/2 Mouse Numeric data processor Primary IDE Channel Secondary IDE Channel Note: If the content in Setting is inconsistent with CD-ROM, please refer to the setting as priority.
