National Instruments IMAQ D100DAL Installation Manual

Installation GUIDE
IMAQ D100DAL C
Note Your DALSA camera cable receptacles may appear different from those
illustrated in this guide. Refer to the National Instruments Web site,
http://www.natinst.com/imaq
with your IMAQ device.

What You Need to Get Started

IMAQ ™ is a trademark of National Instruments Corporation. Product and company names mentioned herein are trademarks or trade names of their
respective companies.
371899A-01 © Copyright 1998, 1999 National Instruments Corp. All rights reserved.
ABLE
This guide describes how to attach an IMAQ D100DAL cable to your
image acquisition (IMAQ) device and a DALSA camera. This guide
discusses two possible DALSA camera configurations: one in which the
camera has a combined control/power connector receptacle and one in
which the control connector receptacle and power connector receptacle are
separate.
You can use an IMAQ D100DAL cable to connect your IMAQ device to
your DALSA video camera and four trigger channels. Refer to your IMAQ
device documentation for more detailed information on these external
trigger signals.
, for the latest information on using DALSA cameras
To install your IMAQ D100DAL cable, you will need the following:
IMAQ D100DAL cable
IMAQ D100DAL Cable Installation Guide
Your IMAQ device and documentation
Your computer
Your DALSA camera
IMAQ D2504 cable and documentation (optional)
BNC cables for trigger signal connection (optional)
Trigger signal sources (optional)
May 1999
