Summary of Contents for Yale YDR2105

  • Page 1 Ver. PMU-0808-01...
  • Page 2 User Manual YDR2105 ※The function and design of this product may chang without notice.

  • Page 3: Table Of Contents

    Contents Important safety instructions ..............3 Overview ................... 4 Basic contents ................5 Identification of Product ............... 7 Product overview and Specifications How to use ................8 Registering security code ..................10 Registering keys ..................11 Deleting keys ..........12 Unlocking the door from Outside (Security code) ........

  • Page 4: Important Safety Instructions

    Important safety instructions Do not attempt to dismantle or repair product. Please contact your nearest authorised service agent for any repairs or maintenance. When cleaning use only a damp cloth to clean the lock body. Note : Do not use any chemicals when cleaning This product may be damaged by impact.

  • Page 5: Basic Contents

    Basic contents Front Body Front Body Gasket [ YDR2105 ] Back Body Back Body Gasket Back body Bracket Touch keys (4) Rotation-resistant ring Strike Strike packing plate Mechanical key (2)

  • Page 6: Identification Of Product

    Identification of Product 1. Front Body ① Keypad cover ② Emergency Power Supply Terminal ③ Keypad ④ LED ⑤ Key reader ⑥ Emergency override cylinder...
  • Page 7 2. Back Body ① Battery cover ② Auto/Manual Lock switch ③ Registration button ④ Open/close button ⑤ Manual knob ⑥ Automatic locking sensor ⑦ Dead bolt...

  • Page 8: Product Overview And Specifications

    Product overview 1. Convenience 1. Security code: Use any code number from 4-12. 2. Touch key: All keys must be programmed after installation. 3. Emergency mechanical key can lock and unlock the door at any time. 4. Automatic locking locks automatically after 7 seconds. 5.

  • Page 9: Registering Security Code

    Registering security code For security code, it is possible to register one code with 4 - 12 digits but only one code can be registered to use at one time. Caution - When you register or change the security code, check for correct operation with the door in the open position.
  • Page 10 4. Check the Security code operation Once registration is completed, make sure to open the lock with your new security code while the door in the open position. Caution - It is recommended to change your pincode on a regular basis.

  • Page 11: Registering Keys

    Registering keys For key registration, please contact your all Touch keys. (up to 30 keys) 1. Press the registration button (Inside) Open [Battery Cover] and Press the registration button. Note : sound 2. Touch key contact Contact all the Touch keys you wish to register on the [Key reader] one by one.

  • Page 12: Deleting Keys

    Deleting keys 1. Press the registration button (Inside) Open [Battery cover] and press the registration button. Note : sound 2. Press the button Open [Keypad Cover]. Press and hold the button for 5 seconds. The deleting process ins completed with sound. Note : sound...

  • Page 13: Unlocking The Door From Outside (Security Code)

    Unlocking the door from Outside (Security code) 1. Open the keypad cover. Slide the [Keypad cover] up. The fully open position. 2. Enter the security code. Enter your registered security code, then press button to unlock the door. Note : sound Notes - You can only input your security code when the blue light on the keypad is on.

  • Page 14: Unlocking The Door From Outside (Touch Key) / Inside

    Unlocking the door from Outside (Touch key) Open the lock using the Touch key from outside. Contact the Touch key on [Key reader]. Unlocking the door from Inside 1. [Open/Close] button Press the [Open/Close] button on the Back body in the lock status to disable.

  • Page 15: Automatic / Manual Lock Mode

    Automatic / Manual Lock Mode The Automatic locking sensor detects the door closing and automatically locks the door. Automatic lock mode is a factory default setting. 1. Setting Manual mode Open the battery cover on the Back Body and set the automatic/manual lock transition switch to manual.

  • Page 16: Beep Mode

    Beep mode This function controls the operating sounds temporarily, the lock can used without any audible beeps. Slide the [Keypad cover] up. Enter your registered security code, then press button. You can control the volume sound. Higher volume : press "3" Lower volume : press "6"...

  • Page 17: Error Sound

    Error sound Warning beeps (Anti-Tamper functions) 1. Touch key, Security code error Should an unregistered key or invalid security code be entered more than 5 times a warning alarm triggers, the door lock will not operated for 1 minute. Note : Sound ever 8 seconds and a continuous beep will be audible at the end of this warning period.

  • Page 18: Emergency Mechanical Key Override

    Emergency mechanical key override Use the emergency key to lock or unlock the door. - If you forget the security code. - If battery power is depleted.

  • Page 19: Damage Alarm

    Damage alarm This function is activated if the lock is forced open. A sensor will detect force or impact and trigger a continuous warning beep(alarm) for 5 minutes. Note : sound (2 minutes) [Indoor] Disable emergency beep Open the battery cover on the Back Body and either remove the batteries or press the registration button.

  • Page 20: Heat Alarm

    Heat alarm It trigger the alarm and automatically unlocks if the lock detects the tempertature as high 60 degree Celsius (140 degrees Fahrenheit). The detection temperature can be different depending on the installation circumstance. Caution - If the sensor is exposed to the direct ray of sun light for a long time, it will trigger the heat alarm.

  • Page 21: Battery

    Battery 1. When to replace batteries When you use the Touch key or security code to open the door, display lamp flashes red indicating that batteries should be replaced. Replace all batteries within 7 days from initial warning. Note : sound 2.

  • Page 22: Faq

    If the lock is not operating normally, refer to following points. Should the problem continue after following these instructions, contact your nearest service centre. • Security code can not be set. - Be sure to press each digit within 5 seconds the display lamp should be on during the security code setting.
  • Page 23 MEMO...
