Yale YDM2107 User Manual

Digital door lock
Hide thumbs
Table of Contents

Advertisement

Quick Links

Ver. PMU-0808-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YDM2107 and is the answer not in the manual?

Questions and answers

Related Manuals for Yale YDM2107

Summary of Contents for Yale YDM2107

  • Page 1 Ver. PMU-0808-01...
  • Page 2 User Manual YDM2107 / YDM3107 ※The functions and design of this product can be changed without notice for quality improvement.
  • Page 3 Specifications Option 1. Remote control module Identification of Product 2. Remote control 1. Front Body Caution / Note 2. Back Body 1. Emergency power supply How to use 2. Lost key 1. Registering Card / Touch key 3. Product malfunction 2.
  • Page 4 Overview 1. Security code : Use any code number 4-12. 2. Touch key or Proximity card key. 3. Emergency mechanical key : can lock and unlock the door at anytime. 4. Automatic locking locks automatically after 7 seconds. 5. Anti-panic egress : For convenience and in case of emergency, the door automatically unlocked whenever the inner lever is used.

  • Page 5: Important Safety Instruction

    IMPORTANT SAFETY Please read the following safety instructions to prevent any accident, property damage and inconvenience. Children should be well educated in the operation procedure before use. Keep INSTRUCTION this manual in a convenient place so that you can refer to it when necessary. Caution must be followed to protect yourself and your property Note...

  • Page 6: Specifications

    Sold separately dealer. ■ ■ Basic contents □⃞ Option - Remote control - Remote control module Touch keys Mechanical key YDM2107 - User's manual - Installation template Card keys - Battery (8ea) Front Body Front Body Back Body Mortise...

  • Page 7: Identification Of Product

    Identification of Product 1. Front Body - YDM2107 Keypad cover Emergency Power Supply Terminal Reset button Key reader Mechanical key override Keypad (10-key) 9V Emergency battery (sold separately) Lever...
  • Page 8 Identification of Product 1. Front Body - YDM3107 Keypad cover Emergency Power Supply Terminal Reset button Mechanical key override Keypad (10-key) 9V Emergency battery (sold separately) Lever...
  • Page 9 Identification of Product 2. Back Body - YDM2107 / YDM3107 1.5V AA Alkaline Batteries (8EA) Slot for Remote Control Module (Option) Battery cover Auto / Manual Lock button Menu Button Registration Button Volume Control Switch Low battery indicator LED Manual Knob...

  • Page 10: How To Use

    How to Use 1. Registering Touch keys (YDM2107) Press Press Touch key Check the key ➔ ➔ ➔ [Registration Button] [Registration Button] contact operation again Open [Battery Contact all the registration Opening the door Touch keys you Cover] and Press is completed with a with your Key.
  • Page 11 How to Use 1. Registering Card keys (YDM3107) Press Press Card key Check the key ➔ ➔ ➔ [Registration Button] [Registration Button] contact operation again Open [Battery Opening the door Contact all the Press [Registration Cover] and Press with your Key. Card keys you wish Button] again.

  • Page 12: Registering Security Code

    How to Use 2. Registering Security Code Press [Registration] Enter your security code Press [Registration] Check the key ➔ ➔ ➔ button (4-12 digits) button again operation Open [Battery Open [Keypad Once registration is Press [Registration Cover] and Press cover] and enter completed, make it Button] again.

  • Page 13: Locking The Door From Outside

    How to Use 3. Locking the door from Outside Automatic Automatic Manual Within 5 lock mode The automatic lock sensor detects the door seconds closing and locks the door automatically within 5 seconds. “BI-BI-BING”sound Automatic Manual Manual mode The door locks when you slide [Keypad Cover] up and back down again.
  • Page 14 How to Use 4. Unlocking the door from the Outside (YDM2107) Contact the Touch key on [Key Unlocking the reader]. After hearing "BI-BI- door with Touch BING" sound, push the lever down to open the door. Unlocking the Slide [Keypad cover] up. Enter your code and close down [keypad cover] to unlock the door.
  • Page 15 How to Use 4. Unlocking the door from the Outside (YDM3107) Contact the Card key on [Key Unlocking the reader]. After hearing "BI-BI- door with Card BING" sound, push the lever down to open the door. Unlocking the Slide [Keypad cover] up. Enter your code and close down [keypad cover] to unlock the door. If the LED is not turned on with [keypad cover], press * button to turn on the LED, enter your door with code and press button again or slide [keypad cover] down.

  • Page 16: Locking The Door From The Inside

    How to Use 5. Locking the Door from the Inside Automatic Manual Automatic lock When set on automatic lock mode, the mode Within 5 automatic lock sensor detects the door seconds closing and locks the door automatically within 5 seconds. “BI-BI-BING”sound Manual lock Automatic...

  • Page 17: Unlocking The Door From The Inside

    How to Use 6. Unlocking the Door from the Inside Turn the manual knob to open position or Manual knob or Lever push down the lever on the Back Body. Note This lock features anti-panic egress, which means that the door is automatically unlocked whenever the inner lever handle is used.

  • Page 18: Automatic/Manual Lock Mode

    How to Use 7. Automatic/Manual Lock Mode Automatic locking sensor detects the door closing and automatically locks the door in 5 seconds. Automatic lock mode is a factory default setting. Push up the Button Setting it on Mode. automatic lock mode Manual Mode Automatic Mode...
  • Page 19 The last person to leave the home can set the lock in externally forced lock mode. A burglar who enters through a window will then not e able to exit through the door without setting off an alarm. YDM2107 Contact your Touch key or Card key...

  • Page 20: Break-In/Damage Alarm

    How to Use 9. Break-In/Damage Alarm If the lock is damaged or entry is forced while the door is locked, an 80dB alarm is triggered. Turning off the alarm. Caution If the door didn't lock properly, alarm can ringing. Turning off the alarm Method Method Method...

  • Page 21: Heat Alarm

    How to Use 10. Heat Alarm ❶ What is heat alarm If the lock detects the temperature as high as 60 degrees Celsius (140 degree Fahrenheit). it triggers the alarm and automatically unlocks. The detection temperature can be different depending on the installation circumstance. ❷...

  • Page 22: Volume Control

    How to Use 11. Volume Control This function controls the operating sounds so the lock can be used without any audible beeps. ❶ Mute Set the Volume Button to “ 0 ” ❷ Middle level Set the Volume Button to “ 1 ” ❸...
  • Page 23 How to Use 12. Battery 1.5V AA size alkaline battery ❶ Battery type This product uses 8 1.5V alkaline AA batteries 1:1 actual size Input power : DC 6V ❷ Battery replacement warning Low battery LED Replace all 8 batteries when the low battery warning sound is heard and the LED turns red.

  • Page 24: Remote Control Module

    Option 1. Remote Control Module Remote Control Module should be installed in advance in order to use a Remote Control. Open [Battery Cover] and insert the module into the slot. Proper functioning of the module can be checked by operating a Remote Control . Remote control module Installing Remote control module “DI-RI-RI-RING”...

  • Page 25: Remote Control

    Option 2. Remote control The Remote Control is FM frequency (FSK) type that uses Floating ID encoding system, which continuously changes the wireless code each time you use the Remote Control, so that there is no risk of hacking. It is non-directional and the operational range is up to 10-20m. The photo frame design allows you to create different atmospheres by putting in a photo and hanging the remote control on the wall.

  • Page 26: Deleting Remote Control

    Option 2. Deleting remote control Press[menu]button Press 7, 5 Press [menu] Deleting remote control ➔ ➔ ➔ Press [menu] button buttons button registration Open [Battery cover] Press 7 then 5 Remote control Press [menu] button. registration is cancalled and Press button.

  • Page 27: Caution / Note

    Caution / Note 1. Emergency power supply In case the batteries are completely discharged a 9V battery can be used to supply an electronic charge to the unit. Unlock with the Key or Security Code while contacting a 9V battery as illustration below. Discharged batteries should be replaced immediately.
  • Page 28 Caution / Note 2. Lost key If a key is lost you must re-register all other keys to deactivate the lost one. You should always keep a spare key handy to deactivate a lost registered one. [lost key] [Re-registering key] Note Enter the Security code in case you misplace the key.

  • Page 29: Product Malfunction

    Caution / Note 3. Product malfunction Should you experience any operating of programming problems you can reset the lock to its original factory setting as follows. 1. Press the Reset Button located in the left of [Emergency Power Supply Terminal ]with a pin. Then retry the desired function with the key or code.

  • Page 30: Emergency Mechanical Key Override

    Caution / Note 4. Emergency mechanical key override To lock or unlock the door use the emergency mechanical key. Mechanical Push up the key cover Key hole Caution Keep the mechanical override key in a safe place.
  • Page 31 MEMO...

This manual is also suitable for:

Ydm3107
