Summary of Contents for Yale YDR 3111

  • Page 1 YDR 3111 ※ The functions and design of this product can be changed without prior notice for quality improvement. ※ Chinese manual is from 23 page. ISL-1276-10...
  • Page 2: Table Of Contents

    INTRO CONTENTS Thank you for choosing a GATEMAN product. Getting Started Safety Cautions We welcome you to this new door solution world of GATEMAN that is the leading brand in Product Features Simplified Directions the world digital door lock industry. Instructions Please find comfort and security in yourself through perfectly combined digital and analog Components Overview...
  • Page 3: Safety Cautions

    Safety Cautions Product Features Must Read This!!! Please read this carefully for your own safety. 1⃞ Smart Pad Feature A separate lighting method where each keypad number has been separately designed is Do not install the unit in outdoor Do not attempt to disassemble Do not use water and any type of applied so that users may examine intuitively how the selected function is operated and environment.
  • Page 4 Quick Instruction 1⃞ Register Password ➞ ➞ Press Enter Password Press (Registration) (Registration) button (4 to 12 digits) button 2⃞ Register Card key ➞ ➞ Press Press Instructions (Registration) (Registration) Contact all the keys button button you wish to register on one by one Components Overview 3⃞...
  • Page 5: Components Overview

    Components Overview Identification Basic Contents Front (Front Body, install on the outside of the door) The contents of this product may be subject to change without notice for performance or quality improvement. ❶ Keypad (10-Key) 》 Basic Contents ❷ Card Key Reader ❸...
  • Page 6: How To Use

    How to Use How to Use To Use Password To Use Card key Passwords should be selected from 4 to 12 digits. [*] and [#] are not allowed. 》 To Register Password 》 To Register Card key Order Play Description Order Play Description...
  • Page 7: Lock Door

    How to Use How to Use Lock Door Open Door from Inside 》 To Close Door from Outside 》 Press Open/Close button Order Play Description The built-in Auto Lock sensor automatically locks Auto Lock status 5 Sec a door within 5 seconds after closing the door. ➞...
  • Page 8: Settings

    Settings Settings Manual Lock Mode Alarm Forced Lock In the default setting, manual lock mode does not ring off the alarm when it unlocked by manual thumb turn. However, the users can change it for their own security need. 》 Outside Forced Lock Setting - Card key Order Play Description...
  • Page 9: Safety Feature

    Settings Safety Feature Forced Lock Alarm Feature The alarm sound continues for 30 minutes or until it is disarmed. 》 Break-in / Damage Alarm 》 Inside Forced Lock Setting Break-in: When someone tries to Break-in by opening Order Play Description a door when it is locked, the alarm will go off.
  • Page 10: 3-Minute Lock Feature

    Safety Feature 3-minute Lock Feature At 3-minute Lock mode, no button, besides those in the back body, will work. 》 3-minute Lock Mode Display •If a Password or a Card key that is yet to be registered is entered for 5 consecutive times, 3-minute Lock mode is on and nothing will work for 3 minutes.
  • Page 11: Remote Control Module

    Option Option Remote Control Module Remote Control(Option) Buy the Remote control Module and install it to link the remote control. Not only FSK method but also the wireless encryption algorithm has been applied. 》 To Register Remote Control Order Play Description Open the battery cover in the back body.
  • Page 12: Emergency Power

    Emergency Power Emergency Power Supply for Discharged Batteries You may open a door by contacting the 9V battery 》 To Supply Emergency Power Order Play Description 1⃞ Contact the Open the emergency cover. Keep contacting the 9V 9V battery battery onto the emergency power supply terminal. 2⃞...
  • Page 14 ➞ ➞ ➞ ➞...
  • Page 15 ❶ ❷ ❺ ❸ ❻ ❹ ❼ ❽ ❶ ❷ ❸ ❹ ❺ ❻ ❼ ❽ ❾ ❿...
  • Page 17 ➞ ➞...
  • Page 21 Ting-a-ling...
  • Page 23 : DC 6V 23.8(D)×65.2(W)×175.6(H) : -15~55℃ Zinc die-casting : 55℃ 36(D)×85(W)×158(H) Fiber-glass plastic 1.5V...
  • Page 24 MEMO MEMO...
