Summary of Contents for Yale GATEMAN YDR2108

  • Page 2 YDR2108 User Manual Keep this manual safe for future reference The functions and design of this product can be changed without notice for quality improvement.
  • Page 3 This product is designed and manufactured to assure personal safety. Improper use can result in personal damage or property loss. Please observe the procedures for installation, use and servicing. Yale GATEMAN is a precision electronic device. All safety and operating instructions should be read before the product is operated.

  • Page 4: Important Safety Instructions

    Keep this manual in a convenient place so that you can refer to it when necessary. must be followed to protect yourself and your property. explains product functions and features. must observe prohibited Yale GATEMAN digital Clean only with dry cloth. Do attempt When you move door lock is a precision...
  • Page 5 Caution Do not use an Handle the unit with Be careful not to have Do not use water inappropriate tool care. Excessive unauthorized user know and any type of that can cause force, careless of your security code. solvent such as damage or mal- handling may Change your code...
  • Page 6 Overview Floating ID technology Self-checking The iButton key in the product applies Floating ID technology, that The lock checks the system status and alerts you in case of generates new encryption code in every use. malfunction or low battery power. Dual access Heat sensor You can unlock the door using your ibutton key or security code at...

  • Page 7: Basic Operation

    Basic Operation 1. iButton Key Registration 5. Locking / Unlocking the Door from 8. Forced Locking the inside External forced locking Contact the key for more than 5 Press [open / close] Button seconds or press Button for more than seconds after entering the Press button...

  • Page 8: Table Of Contents

    C O N T E N T S Specifications Option 1. Remote control Module Identification of Product 2. Remote control How to use 1. Registering iButton key Cautions 2. Registering security code 3. Locking the Door from the outside 1. Emergency Power Supply 4.

  • Page 9: Specifications

    Specifications Parts Specifications Remarks 19(D) 64.6(W) 160.2(H) Die cast zinc Front Body Operating temperature : -15 ~ 55 36(D) 85(W) 158(H) Glass fiber enforced plastic Back Body iButton Key 4 EA Up to 20 keys registration (sold separately) Battery 4EA 1.5V AA alkaline batteries(Operating voltage: 4.5 ~ 6 V) Lasts up to 1 year (assuming product is used 10 times a day) Remote control Wireless...

  • Page 10: Identification Of Product

    Identification of Product Front ( Front Body, install on the outside of the door ) Keypad Low Battery indicator Jammed Locking bolt Key reader Emergency Power Supply Terminal Reset button Cover (Sold separately)
  • Page 11 Back body (Back Body, install on the inside of the door) Auto / Manual Lock button Volume Controller Open/Close Button 4EA 1.5V AA Alkaline Batteries Deadbolt Manual Knob Remote control module Internal Forced Lock Button Battery Cover Automatic Locking Low battery indicator Sensor Menu Button Register Button...

  • Page 12: Registering Card Keys

    How to use Registering Card Keys Keep the door open while you register a new code to prevent yourself from accidentally being locked out. 4 ibutton keys are provided at purchase Contact your local dealer for additional Basic Key Additional Maximum and you can register up to 20 card card keys.
  • Page 13 Contact all the keys Press Press you wish to register on Check the key [Registration] [Registration] the [card key reader] operation button button one by one Pi-bing Pi-bi-bing If you hear a “pik” The registration is Opening the door with If it takes too long Sound, the card keys complete with a “pi-bi-...

  • Page 14: Registering Security Code

    Registering Security Code Keep the door open while you register the security code to prevent yourself from accidentally getting locked out. Set a code of 4~12 digits using the (4digits) (12digits) number buttons The old code is automatically deleted when registering a new code. If incorrect codes are entered 5 times in a row all functions shut down for about 3 minutes.
  • Page 15 Ex) Changing your code to 3, 5, 4, 6 Press Press Enter your Check your [Registration] [Registration] security code security code Pi-bing button button Press [Registration] button Pi-bing Pi-bi-bing Open [Battery Cover] Enter the code you The registration is Once registration is and Press wish to register.

  • Page 16: Locking The Door From The Outside

    Locking the Door from the Outside The automatic lock sensor detects the door closing and locks the door automatically within 5 seconds. Automatic lock mode Within 5 seconds Di - d i - d i n g The door locks when touch the keypad with the palm Manual lock mode...

  • Page 17: Unlocking The Door From The Outside

    Unlocking the Door from the Outside Contact the Confirming the Unlocking iButton key on door open the door the reader with It is unlocked iButton key with a “pi-bi-bing” sound. Pi-bi-bing Touch the keypad Enter your Touch the keypad Confirming the Security with the palm security code...
  • Page 18 Touch the Security Enter the Touch the Confirming the Press keypad again or security code Code keypad with door open two times in a press button (Exposure the palm -proof) Pi-bi-bing * Exposure-proof function is useful when there is danger of exposing the security code. * All the numbers on the keypad are blinking with every touch when exposure-proof function is in operation.

  • Page 19: Locking The Door From The Inside

    Locking the Door from the Inside When set on automatic lock mode. The automatic lock sensor detects the door closing and locks the door Automatic automatically within 5 seconds. lock mode Di - d i - d i n g Within 5 seconds Use [manual knob] on the back body.

  • Page 20: Unlocking The Door From The Inside

    Unlocking the Door from the Inside Press [open/close] button on the Confirming the door open back body...

  • Page 21: Setting It On Manual Lock Mode Alarm

    Setting it on Manual Lock Mode Alarm In the default setting, manual lock mode doesn't ring off the alarm while using the door. However, the users can change it for their own need. Setting it on Press Button Press Button Press Button Alarm...

  • Page 22: Automatic/Manual Lock Mode

    Automatic/Manual Lock Mode This product has a sensor which detect the door closing and automatically locks the door in 5 seconds. Setting it on Push up the Button automatic Mode. lock mode Manual Mode Automatic Mode Setting it on Push down the Button manual lock Mode.

  • Page 23: External Forced Lock

    External Forced Lock In external forced lock mode, the door cannot be unlocked from the inside. It is useful to prevent a break-in in case of long absence of the users from the premises. Setting external forced lock mode on with iButton key Setting Contact the iButton Confirming external...
  • Page 24 Press and hold Setting Touch the keypad Enter the security button with the palm code external forced lock mode on with The security code Press and hold button for about 3 seconds until external forced lock mode is set on with 3 beeps. Setting external forced lock mode off To unlock the door from the outside in external forced lock...

  • Page 25: Internal Forced Lock

    Internal Forced Lock The door cannot be unlocked from the outside even by the card key or security code in internal forced lock mode. It enhances the level of security when all users are inside of the premises. Locked Unlocked UNLOCK UNLOCK LOCK...

  • Page 26: Using Manual Knob In Emergency

    Using Manual thumbturn in Emergency In case you Turn [manual thumbturn] to cannot open open the lock. the lock with [open/close] button. (1) It triggers the alarm when you open the door after unlocking the lock with [manual thumbturn]. In order to turn off the alarm, (1) press [open/close] button for 5 seconds, or (2) contact the iButton key, or (3) enter the security code.

  • Page 27: Break-In / Damage Alarm

    Break-in / Damage Alarm The alarm lasts up to 30 minutes or until a verification is made. Break-in alarm If the lock is damaged or entry is forced while the door is locked, a 80dB alarm is triggered. It sounds the alarm to open the lock with [manual thumbturn] while the door is closed.
  • Page 28 Turning the alarm off (Choose one of the three options below.) Contact the card key on the [iButton key reader]. Contact your iButton key Touch the keypad with the palm Enter the Enter the security code security Touch the keypad with the palm again or press button code Press and hold [open/close] button for 5 seconds.

  • Page 29: Heat Alarm

    Heat Alarm The lock triggers the alarm and automatically unlocks if it detects temperature as high as 60ºC(140ºF). The detection temperature can be different depending on the surroundings. [Locked] [Automatically unlocked] The heat alarm can be turned off by removing batteries or entering the iButton key or the security code.

  • Page 30: Wrong-Try Lock-Out

    Wrong-try Lock-out No keypad functions during this wrong-try lock-out delay. The break-in and damage alarm work regardless of this function. If incorrect security codes or unregistered iButton keys are attempted 5 times in a row, it will lock out for 3 minutes with the blinking LED. 5 times Resume the operation automatically after 3 minutes of lock-out, or by pressing [Open/Close]...

  • Page 31: Volume Control

    Volume control This function can control the operating sounds so that the door can be opened and closed without disturbing others. Silent Mode Setting the volume Button on “ 0 ” Normal Mode Setting the volume Button on “ 1 ” Loud Mode Setting the volume Button on “...

  • Page 32: Battery Replacement

    Battery & Replacement Battery life may This product uses 4 1.5V alkaline 1.5V AA size alkaline battery vary due to AA batteries which can be used temperature, Year approximately one year on the moisture, 1:1 actual size condition of 10 times open/close frequency of use and the quality of cycles per day.

  • Page 33: Displaying Operation Status

    17. Displaying operation status (Independent lighting) Low battery External / Internal forced locking Starting from the left column, the LED comes on from left to right to left for twice. In case of emergency Jammed locking bolt The LED keeps coming on to the clockwise. Wrong-try lock-out delay for 3 minutes When registering a security code It shows what the user has just registered in order.

  • Page 34: Remote Control Module

    Option Remote control Module Remote control module should be installed in advance to use remote control. Open [battery cover] and insert the module into the slot. Proper functioning of the module can be checked by operating a remote control . Remote control module : Required for the use of Installing remote control module...

  • Page 35: Remote Control

    Remote Control The remote control is an FM frequency (FSK) type that uses a Floating ID encoding system, which changes the wireless code each time you use It, so that there is no risk of hacking. It is non-directional and the operational range is up to 10~20m. The photo frame design brings you different atmospheres by putting in a photo and hanging the remote control on the wall.
  • Page 36 Deleting the remote control registration Press [menu] Press Press [menu] Deleting remote button buttons button control registration Pi-bing Pi-bing Remote control registration is cancelled with a “di-ri-ri- ring” sound. In case you do not use remote control or lose it, deleting remote control registration may lengthen the battery life.
  • Page 37 How to use the remote control Unlocking the door Locking the door Changing the batteries Press [open] button, and it will unlock within Press [close] button, and it will lock within Open up the battery cover at the back of 2~3 seconds.

  • Page 38: Cautions

    Cautions Emergency power supply In case the batteries are completely discharged, 9V battery can be used to supply electricity to the unit. Unlock with the card key or security code while contacting a 9V battery just like the below instruction. Discharged batteries should be replaced right away. Discharged Holding a 9V iButton key use...

  • Page 39: Lost Key

    Lost iButton key If you lose the iButton key, re-registering remaining keys is required to prevent other people from using the lost card key. Lost iButton key Re-registering iButton key Enter the security code in case you lose the iButton key or you are not carrying it. It is a user’s liability to break the lock because the user did not register a security code.
