Paradox IMPERIAL DIGIPLEX EVO ACM24D Instructions

ACM24D-EI00
ACM24D 4-Wire Access
Control Module V1.0
Instructions
PARADOX.COM
Printed in Canada - 01/2009
The ACM24D Access Control Module can
control two doors and can support REX devices,
readers, locking devices and door contacts.
Door contacts that are connected to the
ACM24D are programmed using BabyWare
software and can be assigned to zones in the
Imperial system.
Imperial V32
EVO48, EVO192
DGP-848, DGP-NE96, EVO96
Installation
Figure 1: DIN Rail Mounting
The ACM24D is a
standard 35mm
DIN rail module.
Using the
supplied DIN rail,
the ACM24D can
be mounted in any
location.
Release
Alternatively, it
clip
can be mounted in
a standard DIN rail enclosure. To attach the
module, align the top of the DIN rail as shown in
Figure 1 and apply pressure to the module until it
clicks into place. To remove the ACM24D from a
DIN rail, pull the release clip and remove the
module.
To facilitate installation and servicing, the
ACM24D terminals can be detached from the
module. Wires can be labeled using the supplied
tie wraps.
Door contacts connected to the system follow
the control panel's EOL definition. When EOL is
enabled and door contacts are not used, place a
Ω
1k resistor across the and
CT
If EOL is disabled, use a jumper. If the REX
device is not used, place a jumper across the
and terminals.
C
Stand-Alone Mode
The ACM24D stores all access codes and cards
in memory. If panel communication is lost, the
ACM24D will continue to function normally.
Events will be stored in memory. When
communication is restored, events are
automatically uploaded to the panel.
Upgrading the Firmware
Imperial
The firmware of the ACM24D can be in-field
upgraded through the V32's RS485 ACCESS
port using BabyWare.
EVO/DGP
The ACM24D firmware can be upgraded through
WinLoad using the CV4USB RS-485/RS-232
Converter. Refer to the firmware upgrade
instructions found at: paradox.com - Software -
WinLoad - Firmware Upgrade Instructions.
EVO / DGP Programming
When used on an EVO/DGP system, the ACM24 appears in WinLoad as two ACM12 modules.
TM
Serial Numbers
Example: ACM24D = 3500556A ACM12 #1 = 3500556A
Locate Mode
• For Imperial panels, a Module Locate can be started or stopped using BabyWare software
or by pushing the module's LOC button. When a Module Locate is initiated, a flashing
occurs of the module's LEDs (BUS RX and TX flash at 1Hz) as well as the module's
representation in BabyWare.
• For DGP/EVO panels, a Module Locate can be initiated using section [4002] (EVO) or
[952] (DGP-48 / DGP-848). To end a Module Locate, press the LOC button.
Door LED Feedback
DOOR1 and DOOR2 manual control buttons display door status and can override door
programming. Manually unlocked doors remain unlocked for the minimum period
programmed in BabyWare.
35mm
Colour
DIN rail
green on
red on
Reader LED Feedback
red flash
red on
green on
off
Communication LED Feedback
Bus
off
off
red
input terminals. red
C
red
RX
red flash
red flash
blue
blue flash
Power LED Feedback
LED
AC
CHRG
Transformer Sharing
Modules can share a central AC
transformer (16 to 24V
system. Ensure that the total power output
of the transformer is respected.
ACM12 #2 = 3500556B (plus 1 number / letter)
Fuse
Condition
Door unlocked
Door locked
Reader auxiliary power failure
Reader is missing
Readers OK
No reader programmed for this door
RX TX
green - flash green - flash OK (panel communication in progress)
off off
off off
off green
green green
off off
green - flash green - flash Locate mode
--- ---
off off
Colour
green
green
green (less than 4 sec.)
.
Transformer
) throughout the
AC
Detachable Terminals
Pry with screwdriver if
necessary.
Door Labels
Space is provided to label
each door.
- not used
Condition
OK (no data RX/TX)
Short on GRN or YEL
Communication failure / Too many modules on
Multibus
Multibus lines reversed (Green / Yellow)
Bus power too low
Communication with V32 panel / Multibus mode
Firmware upgrade in progress
Condition
AC or DC power is supplied
Battery is low / charging
Battery test
16 / 24 Vac 16 / 24 Vac
ACM24D ACM24D
Connect to other
modules
compatible with
transformer
sharing.
