Summary of Contents for kincrome K16035
- Page 1 PETROL POST HOLE DIGGER PETROL POST COMPACT LIGHT HOLE DIGGER WEIGHT HIGH INCLUDES METAL 150MM TORQUE PERSON REDUCTION AUGER POWER DRIVE OPERATION HEAD GEARBOX K16035 ED4 July 2019...
- Page 2 Ch 19. Tool Kit 3) P a) Be b) Th c) Us d) Alw Model No: ............................K16035 Description: ..........................Petrol Post Hole Digger e) Do Engine Displacement ........................51.7cc f) Do Rated Output Power: ........................1.3kw/1.7HP g) Us Fuel tank (3) Capacity : ........................
-
Page 3: General Safety Warnings
PETROL POST HOLE DIGGER General Safety Warnings Save all warnings and instructions for future reference. WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. 1) Work Area a) Keep work area clean and well lit. - Page 4 PETROL POST HOLE DIGGER 7) D o) Always operate the machine with two hands. The fo p) DO NOT ever use the Petrol Post Hole Digger for any other purpose than digging post holes. It is designed for this use and any other use may cause an injury.
-
Page 5: Description Of Symbols
PETROL POST HOLE DIGGER 7) Description of Symbols The following symbols could be shown on the tool: e and Read the instruction manual before use. Risk of Explosion Wear Ear Protection Wear Eye Protection lled Warning Wear Safety Gloves dition Wear sturdy non slip footwear Do not smoke or bring any fire near the fuel... -
Page 6: Preparing Engine For Starting
Mixture WARNING: Always use the markings noted as, 30:1 fuel to oil mixing ratio located on the side of the fuel mixing bottle (18) when mixing fuel for the K16035 Petrol Post Hole Digger. FUEL: UNLEADED RATIO... -
Page 7: Operation
PETROL POST HOLE DIGGER 10) Assembly Attaching a Digger to the Drive shaft 1) Detach the clasp from the locking pin (15) and remove from the drive shaft (10) (Fig1). 2) Align the hole located at the top of the Auger Bit’s connection socket with the hole in the drive shaft (10). -
Page 8: Maintenance
PETROL POST HOLE DIGGER 4) App Hot Engine Start 5) Re 1) Push ON/OFF Switch (5) to the ON position (Fig 7). 6) Att 2) Move Choke Lever (16) to “ ” (Fig 8). 3) With right hand push down on the Throttle Lock-Off (7) (Fig 9a), squeeze the Throttle (8) (Fig 9b), then with your left hand push and Spar hold the Throttle Lock-On (9) (Fig 9c) button then release the Throttle (8) (Fig 9b) and throttle Lock-Off (7) (Fig 9a). - Page 9 PETROL POST HOLE DIGGER 4) Apply Castrol Foam Air Filter Oil to the entire filter. 5) Remove excess oil. 6) Attach the filter and air cleaner cover to the engine. Spark Plug 1) Check spark plug every 50 hours of operation. 2) Disconnect the spark plug cap, and clean any debris around the spark plug area.
-
Page 10: Troubleshooting
• Type operation. Choke partially engaged. Turn OFF choke (16). Carburetor out of adjustment. Call Kincrome Customer Service. Engine is hard to start. Old/dirty fuel. Drain fuel and replace with fresh fuel. Spark plug wire loose. Make sure spark plug wire is securely attached to spark plug. -
Page 11: Spare Parts
• For a full list of available spare parts for this item visit the Kincrome website kincrome.com.au for reference. • Type in the model number K16035 and then click on the Spare Parts attachment located in the DOWNLOADS area for a copy of the spare parts diagram and listing. - Page 12 www.kincrome.com.au...
