High-Speed 2-Wire Short-Range DSL
CUSTOMER
SUPPORT
INFORMATION
Line Driver
(mDSL Rack Card)
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: info@blackbox.com
NOVEMBER 2001
ME0004C-10BT
ME0004C-G703
ME0004C-RS530
ME0004C-V24
ME0004C-V35
ME0004C-X21
