Figure 3-3 AC input unit
(1) AC input circuit
breaker
Figure 3-4 AC output unit (German-standard socket and RCD)
(1) German-standard
socket
Table 3-1 describes the AC PDU configurations for the TP48200A-HX09A1.
Table 3-1 AC PDU configurations
Power Grid Mode
Optional: 220 V AC
single-phase
Optional: 220/380 V AC
three-phase, four-wire
Issue 03 (2019-11-15)
(2) AC input terminal (neutral
wire)
(2)
RCD
AC Input AC Surge Protection
Circuit Class
Breaker
One 3-pole 63 Class B. The normal
A circuit current (In) is 30 kA,
breaker and the maximum
current (Imax) is 60 kA.
Copyright © Huawei Technologies Co., Ltd.
(3) AC surge protective device
(SPD)
(3) AC load circuit breaker and neutral wire
terminal
AC Load
Circuit
Breaker
Two 1-pole
10 A circuit
breakers
3 Components
Maintenance
Socket and Its
Protection Mode
German-standard
socket and 10 A
residual current
device (RCD)
