Johnson Controls METASYS TEC1100 Series Technical Bulletin page 4

Table 2: TEC1100 Series Accessory Ordering Information
Item
Optional Accessories (includes mounting hardware)
Replacement Door for nonprogrammable thermostat (10/box)
Remote or Averaging Indoor Temperature Sensor
Outdoor Air Sensor with Outdoor Air Temperature Communication Module
Duct Mounted Outdoor Air Sensor with Outdoor Air Temperature
Communication Module
4- to 5-wire Conversion Module
Thermostat Wall Plate to conceal existing holes
Replacement Parts
Replacement Outdoor Air Temperature Communication Module
Replacement Outdoor Air Temperature Sensor (includes mounting hardware)
Replacement Duct Mount Outdoor Air Temperature Sensor
(includes mounting hardware)
Repair Parts
3 in. Sensor Probe (use with outdoor air sensor)
8 in. Sensor Probe (use with duct-mount outdoor air sensor)
* See SEN-500-1 Remote Indoor Temperature Sensor Product/Technical Bulletin (LIT-216504).
** See SEN-500-2 and SEN-500-3 Outdoor Air Temperature Sensors Product/Technical Bulletin
(LIT-216179).
*** See ACC-500-1 Conversion Module Product/Technical Bulletin (LIT-216500).
**** See ACC-500-2 Thermostat Wall Plate Product/Technical Bulletin (LIT-216502).
Table 3: Alarm Indicators (TEC1102 Heat Pump and TEC1103 Multistage)
LED Position
)
Right (
Center
(no symbol)
Left ( )
Temperature
Alarm (no LED)
Note: Either binary input (LED 1 or LED 2) can be used as a fan-proving switch for other applications.
4 TEC1100 Series Thermostat Technical Bulletin
Function
Indicates a fault. Controlled by external switch on LED 2, which displays a
wrench icon and reports Change-of-State (COS) to the Metasys system and
causes the Network Dial Modem (NDM) to dial out.
(TEC1102 heat pump only). Indicates when Emergency (Auxiliary) heat
(E ht) is activated. Internally controlled. No COS.
Indicates filter needs changing. Controlled by external switch on LED 1, which
displays the filter icon and reports a COS to the Metasys system and causes
the NDM to dial out.
If the room temperature is more than 1°C (1°F) away from the setpoint after
45 minutes of operation, a COS occurs which causes the NDM to dial out.
Once the temperature reaches the setpoint, the alarm returns to normal.
Product Code Number
TEC10DOOR-NONPROG
SEN-500-1*
SEN-500-2**
SEN-500-3**
ACC-500-1***
ACC-500-2****
SEN-500-603
SEN-500-604
SEN-500-605
SEN-500-601
SEN-500-602
BI
1
N/A
3
2
