Summary of Contents for DeDietrich CBB Series
-
Page 1: User Guide
Wood-burning boiler User Guide 300008541-001-E... -
Page 2: Table Of Contents
Contents Symbols used ................3 Important recommendations . -
Page 3: Symbols Used
2. Important recommendations Congratulations on your choice of a high quality product. We strongly advise you to read the following instructions in order to guarantee the optimal operation of your appliance. We are sure that it will be entirely to your satisfaction and will meet with all of your expectations. -
Page 4: Maintenance
2. Important recommendations 2.2 Maintenance - The boiler must be serviced and fully cleaned and the flue gas - Regularly check the level of water in the system and top up if conduit swept by a qualified professional at least 2 times per year. required, taking care that cold water is not added suddenly into the - We recommend taking out a maintenance contract. -
Page 5: Description
3. Description 3 Description 3.1 Installing the heating Depending on the heating installation, certain components can be suppressed or added. Get your fitter to explain your installation to you. Désignation Fonction Burns wood in complete safety and protects the environment. Removes the heat from Log-fired boiler with natural the fumes given off by combustion and transfers it to the heating water. -
Page 6: Safety
3. Description Désignation Fonction Adapts the outlet temperature from the boiler to the radiators in such a way as to Motorised mixing valve obtain the desired room temperature, whatever the outside temperature. This is done by mixing the outlet water with the colder heating return water. Pressure gauge Indicates the pressure in the heating circuit. -
Page 7: Boiler
3. Description 3.3 Boiler • CBB 20 • CBB 30 1. Control panel 8. CBB 20: Draught moderator setting CBB 30: Smoke nozzle 2. Loading door 9. Output modulator 3. Secondary air adjustment flap 10. Safety exchanger (To be connected by the fitter) 4. -
Page 8: Control Panel
3. Description 3.4 Control panel 14. General ON 1 / OFF 0 switch (DHW pump) 15. Boiler thermometer 16. Storage tank load pump thermostat (And/or return temperature elevating) 15/09/2008 - 300008541-001-E... -
Page 9: Commissioning And Ignition
4. Commissioning and ignition 4 Commissioning and ignition 4.1 Commissioning Initial commissioning must be done by a qualified professional. 1. Check the water pressure in the installation. Top up with more water if necessary. 3. Carry out the boiler ignition operations (See chapter: Ignition - CBB 20). -
Page 10: Ignition - Cbb 20
4. Commissioning and ignition 4.2 Ignition - CBB 20 4. Close the loading door. 1. Set the On/Off switch to 1. 5. When the wood is well lit (about 20-30 minutes later), continue to 2. Open the loading door. fill the combustion chamber. 3. -
Page 11: Ignition - Cbb 30
4. Commissioning and ignition 4.4 Ignition - CBB 30 1. Set the On/Off switch to 1. 5. Close the loading door. 2. Pull the smoke extraction handle 6. When the wood is well lit (about 20-30 minutes later), continue to fill the combustion chamber. -
Page 12: Cleaning And Regular Servicing
5. Cleaning and regular servicing 5 Cleaning and regular servicing Remove ashes from the boiler every 3 to 7 days depending At the end of the heating season, have the boiler on the quality and quantity of wood used. thoroughly cleaned by a qualified professional. Clean the flue gas collector around 1 time per month. -
Page 13: Cbb 30: Cleaning The Boiler (Every 3 To 7 Days)
5. Cleaning and regular servicing 5.2 CBB 30: Cleaning the boiler (Every 3 to 7 days) Open the loading door. Work the ash removal handle so as to make the ashes fall into the ashtray Sweep the ashes through the slit in the bottom of the combustion chamber. -
Page 14: Cleaning The Flue Gas Collector (Around 1 Time Per Month)
5. Cleaning and regular servicing 5.3 Cleaning the flue gas collector (Around 1 time per month) • CBB 20: Open the inspection hatch and clean using a brush. • CBB 30: Pull out the holding levers. Clean with a brush. Pull out the plate and baffle unit. -
Page 15: Stopping The Boiler
6. Stopping the boiler 6 Stopping the boiler 1. Wait until the logs have stopped burning (Wait 3-4 hours). 2. Set the On/Off switch to 0. Specific precautions Outside the heating period: - Turn on the circulating pumps at least 1 time per month for 2 minutes. -
Page 16: Troubleshooting
7. Troubleshooting 7 Troubleshooting Checks to make before calling your fitter: Faults Probable causes Fault finding The fire has not properly taken (the set Relight the fire. The boiler stops soon after ignition. temperature has not been reached). See chapter: "Ignition" Flue gases are escaping from the Get the fitter to adjust the doors. - Page 17 7. Troubleshooting Warranty You have just purchased one of our appliances and we thank you France for the trust you have placed in our products. The preceding dispositions are not exclusive of benefits for the Please note that your appliance will provide good service for a purchaser of the legal guarantee as stated in Civil Code articles longer period of time if it is regularly checked and maintained.
- Page 18 7. Troubleshooting 15/09/2008 - 300008541-001-E...
- Page 19 7. Troubleshooting 15/09/2008 - 300008541-001-E...
- Page 20 © Copyright All technical and technological information contained in these technical instructions, as well as any drawings and technical descriptions supplied, remain our property and shall not be multiplied without our prior consent in writing. Subject to alterations. 15/09/2008 DE DIETRICH THERMIQUE 57, rue de la Gare F- 67580 MERTZWILLER - BP 30...
