- Page 1 PROJECT User Guide Oil-fired condensing boiler GTU C 330 S U S T A I N A B L E C O M F O R T ®...
-
Page 2: Table Of Contents
11 Appendix - Information on the Ecodesign and Energy Labelling Directives......25 16/01/2020 - 300017846-03 GTU C 330... -
Page 3: Safety Instructions
Do not neglect to service the appliance: Contact a close to the appliance. qualified professional or take out a maintenance contract for the annual servicing of the appliance. Install the appliance in frost-free premises. 16/01/2020 - 300017846-03 GTU C 330... -
Page 4: Recommendations
- Explain the installation to the user - If a maintenance is necessary, warn the user of the obligation to check the appliance and maintain it in good working order - Give all the instruction manuals to the user 16/01/2020 - 300017846-03 GTU C 330... -
Page 5: About This Manual
Hs: Higher heating value HHV (Gross) PPS: Polypropylene hardly inflammable. 3CE: Collective conduit for sealed boiler 2.3 Homologations In general In particular for Germany CE identification no: 1312BT175R GTU C 330 boilers comply with Regulation 1. BlmSchV. 16/01/2020 - 300017846-03 GTU C 330... -
Page 6: Technical Description
3. Technical description 3 Technical description 3.1 General description GTU C 330 boilers are intended for central heating using radiators or - Production of domestic hot water can be ensured by a separate hot underfloor heating. These boilers have the following characteristics: water calorifier. -
Page 7: Boiler And Condenser
Recycling kit (Option) Condenser Condenser safety control box. The housing consists of; - 80°C limiter thermostat - Safety thermostat with manual reset, set to 120 °C. This thermostat monitors the temperature of the combustion products. 16/01/2020 - 300017846-03 GTU C 330... -
Page 8: Description Of The S3 Control Panel
(set to 110 °C) The safety thermostat with manual reset ensures that the boiler operates safely. In the event that there is an abnormal rise in the temperature in the boiler 110° C. Advise your installation engineer. 16/01/2020 - 300017846-03 GTU C 330... -
Page 9: Description Of The B3 Control Panel
Set the boiler temperature between 30° C and 90° C using manual setting. 8. Indicator lights up Boiler temperature display 9. Location for flue gas thermometer (optional) 10. Switch for selecting the number of burner stages 16/01/2020 - 300017846-03 GTU C 330... -
Page 10: Description Of The K3 Control Panel
A factory-set stop limits the maximum temperature to 75 °C. The stop may be moved if necessary. See "Moving the thermostat stop". 8. Boiler thermometer. Boiler temperature display. 9. Switch for selecting the number of burner stages 10. Connector for the programming tool 16/01/2020 - 300017846-03 GTU C 330... - Page 11 See "Moving the thermostat stop". 8. Boiler thermometer. Boiler temperature display. 9. Switch for selecting the number of burner stages 10. Connector for the programming tool 14. Boiler heat curve DIEMATIC-m3 regulator 16. Display 16/01/2020 - 300017846-03 GTU C 330...
- Page 12 C, or the activation of the manual summer mode Symbols indicating that the following inputs/outputs are active DHW load pump on Summer mode (Automatic or Manual) Burner on Burner on with 1 stage Burner on with 2 stages 16/01/2020 - 300017846-03 GTU C 330...
- Page 13 If the Day setting for one of the circuits, A, B or C, is above 30°C, you no longer have access parallel offset on this circuit. Adjustment keys • Keys accessible when the flap is open 16/01/2020 - 300017846-03 GTU C 330...
-
Page 14: Changing The Settings
4 Changing the settings To change the temperature of the heating water or to change the programming: Refer to the connection instructions supplied with the control panel. Refer to the description of the installation 16/01/2020 - 300017846-03 GTU C 330... -
Page 15: Start The Boiler
25°C. If disgassing has already taken place, press the MODE key to suspend disgassing. See: - Control panel instructions - Burner instructions - Domestic hot water calorifier instructions The boiler starts to operate. 16/01/2020 - 300017846-03 GTU C 330... -
Page 16: Switching Off The Central Heating
Precautions required if the heating is stopped when there is a risk of freezing We recommend the use of a correctly dosed antifreeze agent to prevent to the heating circuit from freezing. If this cannot be done, drain the system completely. 16/01/2020 - 300017846-03 GTU C 330... -
Page 17: Checking And Maintenance
The condenser and the condensates neutralisation station must serviced at least once a year by a qualified professional. The siphon and the condensates evacuation conduit must imperatively be checked and cleaned at least once a year. 16/01/2020 - 300017846-03 GTU C 330... -
Page 18: Troubleshooting
- Type of combustible - Serial no. of the appliance - Burner serial number - Manufacturing date - Manufacturing date 3. Boiler rating plate: - Boiler type - Serial no. of the appliance - Manufacturing date 16/01/2020 - 300017846-03 GTU C 330... -
Page 19: Error Messages
A short circuit has occurred on the reconnecting the power supply to the boiler. AL tc titanium anode or connection Advise the installer. reversed. 8.2.2 K3 control panel No error messages displayed. See DIEMATIC-m3 control panel display. 16/01/2020 - 300017846-03 GTU C 330... - Page 20 Domestic hot water production is shut down and can be restarted using key . The tank is no longer protected. TA-S DISCONNEC The Titan Active System® is on an open circuit. Advise the installer. Switch off the current. TA-S FAILURE Internal problem. Advise the installer. 16/01/2020 - 300017846-03 GTU C 330...
-
Page 21: Incidents And Solutions
• Condenser: Check that the safety thermostat has not triggered: - Unscrew the protection cap - Press the resetting button of the burner Carry out the start-up operations again. Call your fitter. Check the circuit breaker 16/01/2020 - 300017846-03 GTU C 330... -
Page 22: Technical Specifications
(2) as a % of stand-by losses (3) At nominal output (4) Maintenance consumption, as a % of the input - according to the standard EN15034 1 mbar = 10 mmWG = 10 daPa. 16/01/2020 - 300017846-03 GTU C 330... -
Page 23: Energy Savings
- Do not shut down heating completely if you are absent. Lower the thermostat by 3-4°C. - Use the sun's heat as much as possible. - Take showers rather than baths. Use a water-saving shower head. 16/01/2020 - 300017846-03 GTU C 330... - Page 24 Warranty Italy You have just purchased one of our appliances and we thank you for the trust you have placed in our products. Please note that your The duration of our warranty is shown on the certificate delivered appliance will provide good service for a longer period of time if it is with the appliance.
-
Page 25: Appendix - Information On The Ecodesign And Energy Labelling Directives
Appendix Information on the ecodesign and energy labelling directives... - Page 26 Contents Contents Specific information ................. . 3 Recommendations .
- Page 27 1 Specific information Specific information Recommendations Danger Only qualified persons are authorised to assemble, install and maintain the installation. Technical data Tab.1 Technical parameters for boiler space heaters GTU C 334 GTU C 335 GTU C 336 Condensing boiler Low-temperature boiler B1 boiler Cogeneration space heater Combination heater...
- Page 28 1 Specific information GTU C 337 GTU C 338 GTU C 339 elmax Full load 0.556 0.556 1.006 elmin Part load 0.272 0.272 0.493 Stand-by 0.006 0.006 0.006 Other characteristics Standby heat loss 1.182 1.208 1.236 stby Emissions of nitrogen oxides mg/kWh (1) Low temperature means for condensing boilers 30°C, for low temperature boilers 37°C and for other heaters 50°C return temperature (at heater inlet).
- Page 29 1 Specific information 300017846 - ErP01 - 31082015...
- Page 30 1 Specific information 300017846 - ErP01 - 31082015...
